9.インコンベア(BTQC)
9.In conveyor(BTQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
材質
No. Drg.No. & Code No QTY Description Rating Remarks
Materials
42 H4440A 4 BEARING, MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ L-1910ZZ FE
43 IQC5413 2 HOUSING ﾊｳｼﾞﾝｸﾞ FE
44 IQC5920 2 COLLAR ｶﾗｰ FE
45 IQC5931 2 COLLAR ｶﾗｰ FE
46 IQC5110 1 COLLAR ｶﾗｰ FE
47 NQC3160 1 BKT BKT FE
48 NQC0330 2 SHAFT ｼｬﾌﾄ FE
49 H4445A 6 BEARING, MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ LF-1050ZZ FE
50 JQC0781 3 COLLAR ｶﾗｰ FE
51 S1022A 3 CIR-CLIP ｻｰｸﾘｯﾌﾟ ST-EW-4 FE
52 NQC4031 1 BKT BKT HELPS FE
53 NQC0300 1 BKT BKT FE
54 S3122A 1 SW, PHOTOELECTRIC SW 光電 E3S-LS3C1D HELPS OT
55 S3122A 1 SW, PHOTOELECTRIC SW 光電 E3S-LS3C1D OT
56 S3122Z 1 SW, PHOTOELECTRIC SW 光電 E3S-LS3RC4 OT
57 IQC8101 1 BKT BKT HELPS FE
58 GVC1060 1 PLATE ﾌﾟﾚｰﾄ HELPS FE
59 S4040X 2 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SPX306-W2A HELPS OT
61 MQC3293 2 COVER, CONVEYOR ｶﾊﾞｰ ｺﾝﾍﾞｱ OT
62 MQC3901 8 SPACER ｽﾍﾟｰｻ FE
63 MQC3501 2 PULLEY ﾌﾟｰﾘ FE
66 NQC3130 1 STOPPER ｽﾄｯﾊﾟ FE
67 NQC3090 1 STOPPER ｽﾄｯﾊﾟ FE
68 NQC0290 2 BOLT, STOPPER ﾎﾞﾙﾄ ｽﾄｯﾊﾟ FE
69 NQC0370 1 NUT ﾅｯﾄ FE
70 NQC3100 1 STOPPER ｽﾄｯﾊﾟ OT
71 NQC3140 1 PLATE, STOPPER ﾌﾟﾚｰﾄ ｽﾄｯﾊﾟ FE
72 NQC0380 1 COLLAR ｶﾗｰ FE
73 NQC3150 1 BKT, CYLINDER BKT ｼﾘﾝﾀﾞ FE
74 S2097E 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CDJ2B10-35R-C73 OT
75 K5325A 2 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ M4R-M5-0 OT
76 H4277A 1 BEARING, SLIDE ﾍﾞｱﾘﾝｸﾞ ｽﾗｲﾄﾞ SMK8WUU FE
77 NQC0390 1 BAR, GUIDE ﾊﾞｰ ｶﾞｲﾄﾞ OT
78 NQC0442 1 PIN ﾋﾟﾝ FE
79 R5022A 1 ROLLER, NEEDLE ﾛｰﾗ ﾆｰﾄﾞﾙ 5゜X27.3L OT
80 NQC0320 1 KNUCKLE ﾅｯｸﾙ FE
81 NQC0220 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ OT
GL-541E PARTS LIST
9 - 4
9.インコンベア(BTQC)
9.In Conveyor(BTQC)
9.インコンベア(BTQC)
9.In conveyor(BTQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
材質
No. Drg.No. & Code No QTY Description Rating Remarks
Materials
82 A4088A 2 ELBOW, UNIVERSAL ｴﾙﾎﾞ ﾕﾆﾊﾞｰｻﾙ UEF-4BU OT
83 NQC4040 1 BKT, SW BKT SW HELPS FE
84 NQC4060 1 NUT ﾅｯﾄ HELPS FE
85 S3132T 1 SW, PHOTOELECTRIC SW 光電 PS-58 HELPS OT
86 MQC3441 8 WASHER ﾜｯｼｬ FE
87 IQC6062 18 NUT ﾅｯﾄ FE
88 IQC6072 28 NUT ﾅｯﾄ FE
89 IQC6291 4 NUT ﾅｯﾄ FE
90 IQC6301 6 NUT ﾅｯﾄ FE
91 NQC0431 4 NUT ﾅｯﾄ FE
93 H5275A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X8L FE
94 H5276A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X10L FE
95 K5173A SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M3X10L FE
96 H5292A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X20 FE
97 H5288A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X10L FE
98 H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L FE
99 H5290A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X15L FE
100 H5296Z BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X100L FE
101 K5257A SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M4X8L FE
102 K5359A
SCREW,HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿 M4X6L FE
103 N4027A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M4X5L FE
104 N4028A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M4X6L FE
105 H5297A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X8L FE
106 H5298A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X10L FE
107 H5299A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L FE
108 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L FE
109 H5309A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X50L FE
111 K5261A SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M5X10L FE
113 H5321A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X12L FE
114 H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X15L FE
115 H5323A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X18L FE
116 H5326A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X25L FE
117 H5327A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X30L FE
118 H5342A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X25L FE
119 W1021A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
120 W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
121 W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
GL-541E PARTS LIST
9 - 5
9.インコンベア(BTQC)
9.In Conveyor(BTQC)
9.インコンベア(BTQC)
9.In conveyor(BTQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
材質
No. Drg.No. & Code No QTY Description Rating Remarks
Materials
122 W1024A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
123 W1025A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M FE
124 W1026A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 10M/M FE
125 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3 FE
126 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
127 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
128 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6 FE
129 W1010A WASHER, CONICAL ﾜｯｼｬ 皿 M-3-L FE
130 W1011A WASHER, CONICAL ﾜｯｼｬ 皿 M-4-L FE
131 W1012A WASHER, CONICAL ﾜｯｼｬ 皿 M-5-L FE
132 W1013A WASHER, CONICAL ﾜｯｼｬ 皿 M-6-H FE
133 N1080A NUT, HEX ﾅｯﾄ 六角 M4 P=0.7 FE
134 N1085A NUT, HEX ﾅｯﾄ 六角 M6 P=1.0 FE
135 N1092A NUT, HEX ﾅｯﾄ 六角 M10 P=1.5 FE
136 NQC3300 1 BKT BKT FE
137 NQC4510 2 BKT, MOTOR BKT ﾓｰﾀ FE
138 NQC4520 2 BKT BKT FE
139 M5063H 2 MOTOR, REVERSIBLE ﾓｰﾀ ﾘﾊﾞｰｼﾌﾞﾙ RM-H6AZMR244 OT
141 JQC2640 1 PLATE ﾌﾟﾚｰﾄ FE
142 MQC1490 1 PLATE, RETAINING ﾌﾟﾚｰﾄ 押え FE
143 K52565 SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M4X6L FE
144 IQC6072 4 NUT ﾅｯﾄ FE
145 IQC6072 6 NUT ﾅｯﾄ HELPS FE
146 MQC1470 1 PLATE, RETAINING ﾌﾟﾚｰﾄ 押え HELPS FE
148 JPQ1010 1 BKT, TERMINAL BKT ﾀｰﾐﾅﾙ HELPS FE
149 H4001T 2 HEAD, GEAR ﾍｯﾄﾞ ｷﾞﾔ 6GHA7.5A-Y-1 OT
150 N4045H 4 SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M6X6L . FE
GL-541E PARTS LIST
9 - 6
9.インコンベア(BTQC)
9.In Conveyor(BTQC)
