GL-541E-09 PART LIST - 第60页
11.カバー(上)(BTPK) 11.Cover(Upper)(BTPK) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質 No. Drg.No. & Code No. QTY Description Rating Remarks Materials 50 H5296C BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X45L FE 51 H5296A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角…
11.カバー(上)(BTPK)
11.Cover(Upper)(BTPK)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
材質
No. Drg.No. & Code No. QTY Description Rating Remarks
Materials
1 BTPK0012 1 FRAME ﾌﾚｰﾑ FE
2 BTPK0021 1 RAIL, LOWER ﾚｰﾙ 下 AL
3 BTPK0030 1 RAIL, UPPER ﾚｰﾙ 上 AL
4 BTPK0040 3 BKT BKT FE
5 BTPK0054 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ FE
7 BTPK0085 1 COVER ｶﾊﾞｰ FE
8 BTPK0092 1 COVER ｶﾊﾞｰ FE
9 BTPK0100 1 COVER ｶﾊﾞｰ FE
10 BTPK0112 2 COVER ｶﾊﾞｰ FE
11 BTPK0120 1 COVER ｶﾊﾞｰ FE
12 BTPK0131 1 FRAME ﾌﾚｰﾑ FE
13 BTPK0140 1 FRAME ﾌﾚｰﾑ FE
14 BTPK0150 4 COVER ｶﾊﾞｰ FE
15 BTPK0160 1 COVER ｶﾊﾞｰ FE
16 BTPK0172 1 BKT BKT FE
17 BTPK0181 2 BKT, CONNECTING BKT ﾂﾅｷﾞ FE
18 BTPK0190 1 FRAME ﾌﾚｰﾑ FE
19 BTPK0200 1 FRAME ﾌﾚｰﾑ FE
20 NPK0230 1 HOLDER ﾎﾙﾀﾞ FE
22 NPK3150 2 PLATE ﾌﾟﾚｰﾄ FE
23 NPK3160 2 PLATE ﾌﾟﾚｰﾄ FE
26 S31970 2 SW, LIMIT SW ﾘﾐｯﾄ XCS-A501 OT
27 T5001T 2 HANDLE 取手 A-5-1 OT
30 NPK3261 2 GUIDE, RAIL ｶﾞｲﾄﾞ ﾚｰﾙ FE
31 T4058A TAPE, TEFLON ﾃｰﾌﾟ ﾃﾌﾛﾝ ASF-110T=0.23W=13 OT
32 T4064T TARE, DOUBLE-SIDED ﾃｰﾌﾟ 両面 666W=12.7 OT
33 NPK3272 4 BKT, STOPPER BKT ｽﾄｯﾊﾟ FE
34 NPK3281 4 BKT, STOPPER BKT ｽﾄｯﾊﾟ FE
35 ANPK3620 8set BEARING UNIT ﾍﾞｱﾘﾝｸﾞﾕﾆｯﾄ OT
36 BTPK0361 6 BKT, COVER BKT ｶﾊﾞｰ FE
37 NPK3340 2 STOPPER, MOVABLE ｽﾄｯﾊﾟ 移動 PL
38 NPK3350 1 STOPPER, MOVABLE ｽﾄｯﾊﾟ 移動 PL
41 K4004H 1 CABLE ｹｰﾌﾞﾙ A-40-01(UL) OT
44 H5275A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 N3X8BL FE
47 H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L FE
48 H5288A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L FE
49 H5290A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X15L FE
GL-541E PARTS LIST
11 - 3
11.カバー(上)(BTPK)
11.Cover(Upper)(BTPK)
11.カバー(上)(BTPK)
11.Cover(Upper)(BTPK)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
材質
No. Drg.No. & Code No. QTY Description Rating Remarks
Materials
50 H5296C BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X45L FE
51 H5296A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X40L FE
52 K5208A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M4X6L FE
53 K5257E SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M4X10L FE
54 H5297A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X8L FE
55 H5299A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L FE
56 K5213Z SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M5X5L FE
57 H5321A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X12L FE
58 H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X15L FE
59 W1021A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
60 W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
61 W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
62 W1024A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
63 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3 FE
64 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
65 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
66 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6 FE
69 N1011T 2 NUT ﾅｯﾄ GPM GL13.5 FE
70 K5049S 2 CONNECTOR ｺﾈｸﾀ STR13.5 OT
71 BTPZ2010 1 VALVE, SOL ﾊﾞﾙﾌﾞ SOL OT
72 H5293A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X25L FE
73 S2010M 1 ILLUMINATION LAMP 照明灯 FT-11001-GL16 (60Hz) OT
74 S2010H 1 ILLUMINATION LAMP 照明灯 FT-11001-GL15 (50Hz) OT
75 H3084G 1 BUSHING, RUBBER ﾌﾞｯｼｬ ｺﾞﾑ NG-79-K OT
76 H3074N 1 BUSHING, RUBBER ﾌﾞｯｼｭ ｺﾞﾑ NG-79-N OT
77 H3068A 3 BUSHING ﾌﾞｯｼｭ KG-032 2.2M OT
79 BTPZ0081 1 NAMEPLATE 銘板 IEC･ PL
80 BTPK0321 1 BKT BKT FE
81 BTPK0331 1 BKT BKT FE
82 BTPK0341 1 BKT BKT FE
83 BTPK0351 1 BKT BKT FE
84 H5298A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X10L FE
85 BTPK0370 2 DOOR 扉 PL
86 M1010E 2 MAGNET CATCH ﾏｸﾞﾈｯﾄｷｬｯﾁ TL-71S OT
87 H5274A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X6L FE
88 S31971 2 SW, LIMIT SW ﾘﾐｯﾄ XCS-Z01 OT
89 AMPA8100 1 COVER, ACRYLIC ｶﾊﾞｰ ｱｸﾘﾙ OT
GL-541E PARTS LIST
11 - 4
11.カバー(上)(BTPK)
11.Cover(Upper)(BTPK)
11.カバー(上)(BTPK)
11.Cover(Upper)(BTPK)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
材質
No. Drg.No. & Code No. QTY Description Rating Remarks
Materials
90 BTPK0380 1 COVER ｶﾊﾞｰ FE
91 BTPK0390 1 COVER ｶﾊﾞｰ FE
92 BTPK0400 1 COVER ｶﾊﾞｰ FE
93 BTPK0421 1 BKT BKT FE
94 H30124 2 FAN ﾌｧﾝ 109P1224H1021 OT
95 K1141T 4 GUARD, FIN ｶﾞｰﾄﾞ ﾌｨﾝ 109-019C OT
96 KPA0890 2 SEAL ｼｰﾙ PL
97 KPA0900 2 NAMEPLATE, CAUTION 銘板 注意 和文.英文（選択部品) PL
98 KPA0920 2 NAMEPLATE, CAUTION 銘板 注意 仏文.英文（選択部品) PL
99 BTPZ2101 1 VALVE, SOL ﾊﾞﾙﾌﾞ ｿﾚﾉｲﾄﾞ Board Flow Changeover manual OT
100 BTPK2010 1 BKT BKT FE
101 BTPK2020 2 COVER ｶﾊﾞｰ FE
102 H3066A 2 BUSHING ﾌﾞｯｼﾕ KG-016 ･ OT
GL-541E PARTS LIST
11 - 5
