GL-541E PARTS LIST
1.Y軸テーブル(1)(BTPT)
1.Y axis table(1)(BTPT)
1 - 2
1.Y軸テーブル(1)(BTPT)
1.Y axis table(1)(BTPT)
ﾀﾃx173.205
Ref.31-1
Ref.31-1
Ref.31-1
Ref.33-7
C
A
C
B
B
A
B
A
LOCTITE242
LOCTITE242
LOCTITE242
3.33N･m
1.Y軸テーブル(1)(BTPT)
1.Y axis table(1)(BTPT)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
材質
No. Drg.No. & Code No. QTY Description Rating Remarks
Materials
1 BTPT0420 2 BKT, STOPPER BKT ｽﾄｯﾊﾟ FE
2 PPT0660 2 DAMPER ﾀﾞﾝﾊﾟ PL
3 NPA0190 2 COLLAR ｶﾗｰ FE
4 BTPT0502 1 SLIDE, Y-AXIS ｽﾗｲﾄﾞ Y軸  AL
5 BTPT1011 1 BALL SCREW ﾎﾞｰﾙﾈｼﾞ OT
6 BTPT1021 2 GUIDE, RAIL ｶﾞｲﾄﾞ ﾚｰﾙ OT
7 BTPT0532 1 BKT, MOTOR BKT ﾓｰﾀ FE
8 BTPT0540 1 COVER ｶﾊﾞｰ FE
9 BTPT0550 1 BKT, SW BKT SW FE
10 BTPT0560 1 BKT, SW BKT SW FE
11 BTPT0571 1 DOG ﾄﾞｯｸﾞ FE
12 BTPT0580 2 DOG ﾄﾞｯｸﾞ FE
13 BTPT0880 1 RETAINER, BARING 押え FE
14 BTPT0931 1 BKT BKT FE
15 PPT1371 1 COLLAR ｶﾗｰ FE
16 N1025T 1 NUT, LOCK ﾅｯﾄ ﾛｯｸ ZM017 FE
17 BTPT1031 1 COUPLING ｶｯﾌﾟﾘﾝｸﾞ OT
18 SAM1501 1 MOTOR ﾓｰﾀ OT
19 H4157T 1 BEARING ﾍﾞｱﾘﾝｸﾞ 17TAC47B-DBC8PN7A Set parts FE
20 H4181A 1 BEARING ﾍﾞｱﾘﾝｸﾞ 6003ZZ FE
21 PPT1060 1 COLLAR ｶﾗｰ FE
22 S1036A 1 CIR-CLIP ｻｰｸﾘｯﾌﾟ STW17 FE
23 GPT0792 26 RETAINER 押え FE
24 S4040W 1 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SPX305-W2A OT
25 K5256H SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M3X12L FE
26 K52565 SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M4X6L FE
27 H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L FE
28 H5299A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L FE
29 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L FE
30 H5301A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X18L FE
31 H5311A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X60L FE
32 H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X15L FE
33 H5324A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X20L FE
34 H5343A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X30L FE
35 H5349T BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X65L FE
36 W1021A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
37 W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
GL-541E PARTS LIST
1 - 3
1.Y軸テーブル(1)(BTPT)
1.Y axis table(1)(BTPT)
1.Y軸テーブル(1)(BTPT)
1.Y axis table(1)(BTPT)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
材質
No. Drg.No. & Code No. QTY Description Rating Remarks
Materials
38 W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
39 W1024A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
40 W1012A WASHER, CONICAL ﾜｯｼｬ 皿 M-5-L FE
42 W1014A WASHER, CONICAL ﾜｯｼｬ 皿 M-8-H FE
43 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
44 PPT1040 1 HOLDER ﾎﾙﾀﾞ FE
45 K1068A 1 COVER, SCREW ｶﾊﾞｰ ｽｸﾘｭｳ 030-0500-050 OT
46 BTPT0991 1 HOLDER ﾎﾙﾀﾞ FE
47 K5357T
SCREW,HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿 M3X8L FE
48 K5361T
SCREW,HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿 M5X12L FE
49 K2009H 26 CAP ｷｬｯﾌﾟ C06 OT
50 S4040Y 2 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SPX405-W2A ･ OT
GL-541E PARTS LIST
1 - 4
1.Y軸テーブル(1)(BTPT)
1.Y axis table(1)(BTPT)
