KHY/KJV-1111
4
2
Y-axis
Moving-axis
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q'ty Remarks Rev. Rank Level No. Part No. Part Name Q'ty Remarks Rev. Rank Level
1
KHY-M2671-00 BALL SCREW 2
A
r
39
2
KHY-M2648-00 DAMPER 2
/
40
3
KHY-M652A-00 SENSOR,Y ORG ASSY 1
B
Í
41
4
KHY-M652F-00 SENSOR,Y OT ASSY 1
B
Í
42
5
KHY-M2682-00 DOG,ORIGIN 1
/
Í
43
6
KHY-M2683-00 DOG,SECOND LIMIT 2
/
Í
44
7
KHY-M2691-00 BRACKET,SENSOR 1
/
Í
45
8
KHW-M224A-A0
SUPPORT UNIT 2
/
Í
46
9
KHW-M2654-00 PLATE , DAMPER
2
/
47
10
KHN-M224J-00 COLLAR A 4
/
48
11
KHN-M224K-00 COLLAR B 4
/
49
12
90990-26J008 BEARING 4 Cf.list of parts
/
Í
50
13
KGS-M2256-00 GRIP 1
/
51
14
KV7-M2651-00 DAMPER,STOPPER 2
/
52
15
KG2-M9173-00 LOCK NUT 2
/
Í
53
16
KM0-M2220-00 COUPLING,X-AXIS 2
/
Í
54
17
90K63-611F04 AC SERVO MOTOR 2
B
Í
55
18
KHW-M2656-00 SPACER 4
/
56
19
KHY-M26C1-01 COVER TOP,BALL SCREW 1 Old is 12 holes
/
57
20
KHY-M26C8-01 COVER TOP L,BS 1 Old is 12 holes
/
58
21
KHY-M266A-00 PLATE,PIPE R 1
/
Í
59
22
KHY-M266B-00 PLATE,PIPE L 1
/
Í
60
23
KHY-M266C-00 BLOCK,JOINT 2
/
Í
61
24
KHY-M266D-00 JOINT 2
/
Í
62
25
KHY-M266E-00 JOINT 2
/
Í
63
26
KHN-M22AD-00 GREASE NIPPLE 2
/
Í
64
27
91312-03006 BOLT HEX.SOCKET HEAD 4 M3X6
65
28
91312-05008 BOLT HEX.SOCKET HEAD 20 M5X8
66
29
91312-04008 BOLT HEX.SOCKET HEAD 21 M4X8
67
30
91312-04025 BOLT HEX.SOCKET HEAD 4 M4X25
68
31
91312-05010 BOLT HEX.SOCKET HEAD 14 M5X10
69
32
91312-06018 BOLT HEX.SOCKET HEAD 8 M6X18
70
33
92902-05200 WASHER PLAIN 31
71
34
92902-05600 WASHER PLAIN 10
72
35 73
36 74
37 75
38 76
