No te Rank A : T he func tio ns of these p ar ts g radually d eterio rate wit h oper ating ti me. Rank B : T he machin e stops imm ediately i f the fun cti ons of the se par t s are dis abled. Rank C : The machin e still…
Safety.
To replace the purchased parts safely, be sure to comply with the following items.
However the following cannot cover all items regarding safety in detail. So it is
extremely important that the worker or person handling the machine make correct
decisions regarding safety.
CAUTION Machine operation of operator•Work is limited to maintenance and
safety skill.
Be sure to turn off the machine’s power supply before doing the exchange work.
Be sure to push the emergency stop SW, and do adjustment work under the
emergency stop condition.
Refer to the manual for the replacement work of each consumable part.
*
Safety alert symbols and signal words
CAUTION
Indicates a potentially hazardous situation which, if not avoided, may result in minor
injury, or material loss or damage to the machine. These points are important for
protecting the safety of the machine and data, etc.
安全について
お買い上げいただいたパーツを安全に交換していただくために、下記の事項は必ず守って作
業を行ってください。しかしながら、下記に全ての安全性に関する項目を細部にわたり網羅
することは困難です。従って作業者自身の安全に対する正確な判断が非常に大切な要素とな
りますことをご留意ください。
注意 作業者は本機の動作・メンテナンスに習熟していて安全に作業を行える方に限り
ます。
①交換作業は、マシンの電源を切ってから必ず行ってください。
②調整作業は、非常停止 SW を押し、非常停止状態で必ず行ってください。
③消耗品の交換、各メンテナンス作業についてはマニュアルをご参照ください。
※安全標記の 注意は取り扱いを誤った場合、傷害に至る可能性または物的損害の発生
が想定される内容を示しています。本体およびデータなどの損傷を防ぐために重要な注
意事項です。
Note
Rank A : The functions of these parts gradually deteriorate with operating time.
Rank B : The machine stops immediately if the functions of these parts are disabled.
Rank C : The machine still operates even if the functions of these parts are disabled,
because there are many parts.
Rank E : The functions of consumable part gradually deteriorate with operating time.
/ : Maintenance is excluded (The screws are also equal, display is omitted)
Level
: Aims to undergo basic maintenance training and have the capability to do the
job.
Level
r
: Yamaha Corp. aims to render exclusive training
Level
Í
: Yamaha Corp. Service Engineering
Rev.
: It had a change without the compatibility. Please be careful at the time of the
parts ordering.
Level column
Make use of these as reference, “
•
r
•×”, as mentioned in the Level column.
“
” It is based on taking the basic maintenance training, and being able to do
equal work.
“
” Please contact our company service when it is judged that the customer’s
condition difcult.
From the problem that arises from these, we cannot assume responsibility such as
accidents.
NOTE
RankA: 機能が徐々に失われる可能性のある部品。
RankB: 機能を失うとマシンの即停止に繋がる部品。
RankC: 機能を失っても複数あるのでマシンの即停止とはならない部品。
RankE: 機能が徐々に失われていく消耗部品。
／ :メンテナンス対象外（ネジ類も同等、但し表示省略）
Level
: 基礎メンテナンストレーニングを受けた方、又は同等の作業ができる方が対象。
Level
r
:ヤマハの専用トレーニングを受けた方が対象です。
Level
Í
: ヤマハのサービスマンが対象です。
Rev.
:過去に互換性の無い変更が入った部品。部品発注時は注意してください。
Level 欄について
Level 欄に記載されている
“
•
r
•×”
はご参考としてご活用ください。
“
”
は基礎メンテナンストレーニングを受けた方、又は同等の作業ができる方を
基準にしております。
“
”
であってもお客様が難しいとご判断された時は弊社サービスまでご連絡ください。
これらに起因する不具合、事故等についての責任は負いかねます。
Contents
7
Conveyor Section
Push-Up ................................................................7-1
Stopper (Exit / Sub / Main) ...................................7-2
Clamp Board .........................................................7-3
Main Conveyor (Front STD) .................................7-4
Main Conveyor (Rear STD) ..................................7-5
Sensor ..................................................................7-6
8
Blow Station Section
Blow Station ..........................................................8-1
9
FDR Section
Set Up ST on MC .................................................9-1
FDR Power ST .....................................................9-2
FDR Stand Type144 .............................................9-3
Dust Box ...............................................................9-4
10
Controller Section
Control Box .........................................................10-1
11
Exterior, etc. Section
Exterior, etc. ........................................................11-1
12
Head Accessories Section
Head Accessories ...............................................12-1
13
Tools Section
Tools ...................................................................13-1
1
Base Section
Base .....................................................................1-1
2
Cover Section
Cover ....................................................................2-1
3
Feeder Holder Section
Feeder Holder 60..................................................3-1
Reel Holder ...........................................................3-2
Feeder Floating Detection YS ..............................3-3
Feeder Floating Detection YG ..............................3-4
4
Moving-axis Section
X-axis ....................................................................4-1
Y-axis ....................................................................4-2
5
Head Section
Body Head ............................................................5-1
Shaft Head Sub Assy ...........................................5-2
Scan Camera ........................................................5-3
6
Nozzle Section
Nozzle ...................................................................6-1
Nozzle Changer ....................................................6-2
