SITEST for WPC4
SITEST Inputs/Outputs Restoring WPC Machine Data
106 Service Manual SIPLACE WPC4
Menu field: Inputs/outputs ,
To the left of the function designation for an input or output, you will see an LED, which changes from
gray to red when the status of the input or output is read.
Menu field: Inputs (Hex)
Shows the hexadecimal state of all inputs in the assembly.
