Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE MODEL TCM-X210 0306-001 214 MA-8 745 630 000 8920 SET SCREW 4 801MA-1 10-745 746 41 1 002 2600 SCR FL T 3X6 4 801MA-1 10-746 747 630 000 7510 BOL T ,HEX-SCT 4 801MA-1 10-7…
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
MODEL TCM-X210
0506-002
213
MA-8
701 630 116 0283 COVER 1 801MA-110-701
702 630 118 2889 MECH PARTS(COVER) 1 801MA-110-702
702 -01 630 119 3106 MECH PARTS(FRAME) 1
702 -02 630 119 3113 MECH PARTS(FRAME) 1
702 -03 630 119 1942 MECH PARTS(FRAME) 1
702 -04 630 119 1959 MECH PARTS(FRAME) 1
702 -05 630 119 3250 COVER 1
702 -06 630 119 2147 MECH PARTS(CAP) 4
702 -07 630 118 1646 BRACKET 1
702 -08 630 119 3267 MECH PARTS(HOLDER) 1
702 -51 630 000 7763 BOLT,HEX-SCT 2
702 -52 630 065 2499 BOLT,HEX-SCT 8
702 -53 411 008 2109 WASHER SPR 5 2
702 -54 630 029 1391 WASHER 2
704 630 013 8986 MECH PARTS(RUBBER CUSHION 2 801MA-110-704
705 630 065 2376 MECH PARTS(MAGNET CATCHE) 2 801MA-110-705
706 630 115 4206 PIN,HINGE 2 801MA-110-706
707 630 008 1985 RING 4 801MA-110-707
711 630 115 4183 SUPPORT 2 801MA-110-711
714 630 119 8651 SUPPORT 2 801MA-110-714
715 630 115 4190 SUPPORT 2 801MA-110-715
716 630 038 9715 PIN,HINGE 2 801MA-110-716
717 630 089 3694 COLLAR 2 801MA-110-717
718 630 096 9344 MECH PARTS(URETHANES) 2 801MA-110-718
719 630 119 6770 PLATE 1 801MA-110-719
720 630 003 5032 HANDLE 1 801MA-110-720
721 630 133 4738 BRACKET 1 801MA-110-721
722 630 133 4745 BRACKET 1 801MA-110-722
723 630 137 9777 SWITCH,LIMIT 1 SQ8,21052 801MA-110-723
724 630 137 9784 PLATE 1 801MA-110-724
725 630 119 6756 BRACKET 2 801MA-110-725
726 630 096 9023 SUPPORT 2 801MA-110-726
727 630 115 4411 SUPPORT 2 801MA-110-727
728 630 104 4507 HINGE 2 801MA-110-728
729 630 029 1391 WASHER 4 801MA-110-729
730 630 000 7763 BOLT,HEX-SCT 8 801MA-110-730
731 630 000 7756 BOLT,HEX-SCT 6 801MA-110-731
732 630 000 7619 BOLT,HEX-SCT 2 801MA-110-732
733 630 000 7695 BOLT,HEX-SCT 2 801MA-110-733
734 630 000 7626 BOLT,HEX-SCT 6 801MA-110-734
735 630 000 7763 BOLT,HEX-SCT 10 801MA-110-735
736 411 140 7406 SCR FLT 5X20 2 801MA-110-736
737 411 113 7501 SCR TRS 4X10 2 801MA-110-737
738 411 113 9109 SCR TRS 5X10 8 801MA-110-738
739 630 001 0213 WASHER 4 801MA-110-739
740 411 141 2905 WASHER SPR 4 8 801MA-110-740
741 411 141 4008 WASHER V 4X9X0.8 4 801MA-110-741
742 411 141 6705 WASHER SPR 5 24 801MA-110-742
743 411 141 4107 WASHER V 5X10X1 18 801MA-110-743
744 630 001 0220 WASHER 2 801MA-110-744
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
MODEL TCM-X210
0306-001
214
MA-8
745 630 000 8920 SET SCREW 4 801MA-110-745
746 411 002 2600 SCR FLT 3X6 4 801MA-110-746
747 630 000 7510 BOLT,HEX-SCT 4 801MA-110-747
748 411 141 2806 WASHER SPR 3 4 801MA-110-748
749 411 141 3902 WASHER V 3X7X0.5 4 801MA-110-749
