2 Componen t Forms 35 Nozzle Type s 39 Possible Machine C onfiguration 42 SMD High Speed Placement System SIPLACE S-23 HM 12-Nozzle Revolver Head X-/Y- Portal System Fixed Component Supply Fixed PCB Placement Prin ciple …
1
Subject to change
without notice.
Edition 2
1199-S-23 600-e
Machine Description 3
Line Design 4
Placement Heads 5
12-Nozzle Revolver Head for High Speed
Nozzle Changer for 12-Nozzle Revolver Head (Option)
PCB Conveyor 7
Single Conveyor
Dual Conveyor
Ceramic Substrate Centering (Option)
PCB Bar Code for Production-Controlled Manufacturing (Option)
Component Supply 11
Changeover Table
Tape Feeder
Bulk Case Feeder, Stick Magazine Feeder
Dummy Feeder
Component Bar Code Scanner for Set-Up and Refill Check (Option)
External SIPLACE Set-Up Station (Option)
Vision Sensor Technology 17
PCB Vision Module
PCB Position Recognition
Recognition of Faulty PCBs via Ink Spots
Position Recognition of Feeder
Component Vision Module on the 12-Nozzle Revolver Head
Algorithms to Determine the X-/Y-Position and the Placement Angle
Machine Criteria 22
Placement Accuracy
Placement Reliability and Placement Speed
Mapping (Option)
SIPLACE Software Architecture 25
System Architecture
Line Computer / Station Computer
Creation of Placement Programs
Machine Data Management System
Data Interface SECS II / GEM (Option)
Remote Support (Option)
Technical Data 31
Signal Interfaces
Connections
Dimensions and Set-Up Conditions
SMD High Speed Placement System
SIPLACE S-23 HM
2
Component Forms 35
Nozzle Types 39
Possible Machine Configuration 42
SMD High Speed Placement System
SIPLACE S-23 HM
12-Nozzle Revolver Head
X-/Y- Portal System
Fixed Component Supply
Fixed PCB
Placement Principle SIPLACE S-23 HM
3
Technical Data
Procedure Collect & Place
Component spectrum 0402 (0201*) to 18.7 x 18.7 mm
Benchmark placement rate
12-nozzle revolver heads
Cycle time at revolver head
23,000 cph (25,000 cph option)
140 ms regardless of component type
Angle accuracy
Placement accuracy
± 0.525° / 3 σ, 0.70° / 4 σ, 1.05° / 6 σ
± 67.5 µm/ 3 σ, 90 µm/ 4 σ, 135 µm/ 6 σ
PCB dimensions 50 x 50 mm to 460 x 460 mm
(optional 460 x 508 mm)
Feeding capacity 40 feeder locations
Feeder module types Tapes, stick magazines, Bulk Cases
Operating system Microsoft Windows / RMOS
Connection In line or stand alone
Space required 4 m² / module
* SIPLACE S-23 HM is capable of handling 0201, if optional set up for it (Please contact Siemens).
Description
The high-speed SMD placement
system SIPLACE S-23 HM com-
bines high placement speed with
flexibility and accuracy. In contrast
to classic chipshooters, a Collect &
Place procedure is applied here.
SIPLACE S-23 HM placement ma-
chines are equipped with two X-Y-
main gantries. Each gantry fea-
tures a star-shaped 12-nozzle
revolver placement head. The
placement heads alternately pick
up components from the station-
ary component feeder and place
components on the PCB which is
also motionless. This has distinct
advantages:
Components are refilled and
tapes are spliced with no idle
times during the placement run.
The feeding of components with
no vibrating enables a reliable
pick-up of even the smallest
components (e.g., 0402 chips).
Thanks to the flexible 12-nozzle
revolver heads - whose ideal
nozzle set-up is automatically
specified - the travel can be
minimized and the sequence of
placement optimally adjusted.
As the PCB is motionless, the
components cannot shift posi-
tions.
Speed coupled with economic ef-
ficiency and set-up reliability is the
SIPLACE S-23 HM recipe for suc-
cess. The first components are al-
ready being picked up while the
PCB is being moved in. Path-
optimized teamwork then ensures
high performance: While one re-
volver head is placing components,
the other one is picking compo-
nents up.
The product range is rounded off
by optional add-on products such
as component bar code scanner,
automatic nozzle changer or
changeover tables which can be
set up outside the machine and
exchanged in a matter of minutes.
Machine Description
