6 Station extensions User manual SIPLACE E 6.8 Power Supply COT E From software version SC 708.0 12/2014 Ed ition 300 6 PLEASE NOTE Connection to the SIPL ACE Setup Center  Only one PowerSupply COT E with Chang e o ver …

100%1 / 308
User manual SIPLACE E 6 Station extensions
From software version SC 708.0 12/2014 Edition 6.8 Power Supply COT E
299
6.8 Power Supply COT E
Item no. 03114427-xx Power Supply COT E
6
Fig. 6.8 - 1 Power Supply COT E
(1) Harting connection
(2) D-sub connection
(3) Power connection
Harting connection
The PowerSupply COT E provides 25V 10A power output to the E series changeover table (COT)
through the Harting connector. Data transfer is also available through this connection, so commu-
nication with the feeders on the changeover table is possible.
D-sub connection
The D-sub connector is used to connect to the Setup Centre through the CAN bus cable. This al-
lows the user to program and setup the feeders on the changeover table at a remote location,
away from the placement machine.
Power connection
The module comes with 2 power cords for connection to wall outlet. Depending on the type of wall
socket available in your region, please choose the correct power cords. The AC inlet accepts a
wide range of voltages and frequencies (100-240 VAC, 50-60 Hz).
After powering on the module, the green LED on the top cover of the module will light up.
(3)
(2)
(1)
6 Station extensions User manual SIPLACE E
6.8 Power Supply COT E From software version SC 708.0 12/2014 Edition
300
6
PLEASE NOTE
Connection to the SIPLACE Setup Center
Only one PowerSupply COT E with Change over table is to be connected to SIPLACE
Setup Center for feeder setup.
When using the CAN Bus Cable 03040465-xx with SIPLACE Setup Center, the ter-
minal resistor at the bus system end to the SIPLACE Setup Center must be acti-
vated.The terminal resistor at the bus system end to the PowerSupply COT E and
Change over table must NOT be activated.
The CAN ID for the PowerSupply COT E with Change over table in standalone mode
is 0x0518.
User manual SIPLACE E 7 Maintenance
From software version SC 708.0 02/2015 Edition 7.1 Safety Information
301
7 Maintenance
7
7.1 Safety Information
Please ensure all safety information in this section.
7
7
PLEASE NOTE
Maintenance - Further information
For further information on how to complete the tasks please visit the experience area on
the website: www.e-by-siplace.com
CAUTION
Only qualified personnel
These cleaning and checking tasks may only be carried out by appropriately qual-
ified personnel.
Caution, as used in this user manual, means that slight injury or damage to equipment
may occur if the caution instructions are not followed.
CAUTION
Filter elements
The cleaning and checking intervals given for inspecting and replacing the filter
elements only apply to the specified compressed air quality (see
Section 3.2.4 on
page 103
). If other qualities are used, the intervals should be shortened accord-
ingly.
