3 Important preparations prior to installation (Sof tware configuration) Installation Manual Edition 03/2010 US SIPLACE Pro 8.0 13 3 Import ant prep arations prior to inst allation (Sof tware configuration) All computers…

Installation Manual 2 System components and configurations

SIPLACE Pro 8.0 Edition 03/2010 US

2.2 System configurations

There are various configurations for the SIPLACE Pro installation depending on your production

environment. 2

2.2.1 "Stand alone" configuration

Install all software components on one computer. This computer then functions as both server and

client. If installing on one computer, we recommend using a computer with at least 512 MB disk

space; a high-performance computer is advantageous. 2

2.2.2 "Client/Server" configurations

If installing on separate computers, you work with one computer as the dedicated server and one

or more other computers as clients. 2

Example of a client/server configuration:

MS SQL Server, SIPLACE Pro Database, Line Control Server and SIPLACE Pro Server are in-

stalled on the server computer. One or more clients can work with this server computer. SIPLACE

Pro Desk, SIPLACE Pro Interface and Line Control GUI are installed on the client computers. 2

Note

This configuration is not mandatory. For example, you can also install Line Control Server on a

client computer or a separate computer.

It is also possible to change the configuration subsequently. 2

Warning:

Installation on separate computers cannot be performed via the network. Install the individual

components on separate computers by calling up the setup function for the components locally on

each destination computer. 2

3 Important preparations prior to installation (Software configuration) Installation Manual

Edition 03/2010 US SIPLACE Pro 8.0

3 Important preparations prior to installation

(Software configuration)

All computers must have been set up and prepared appropriately in advance for the complete in-

stallation of SIPLACE Pro to function correctly. 3

These preparatory measures demand knowledge about the administrative functions of Windows

and SQL Server. Please contact your system administrator for assistance if required. 3

This installation guide only describes the procedure for a installation configuration called "stand

alone installation" and "standard configuration". 3

Important:

For more detailed information which software is essential and has to be sucessfully installed

before conducting the installation of SIPLACE Pro please refer to the Support Media DVD and the

respective manual.

Furthermore, you require Windows administrative rights for all computers on which you are in-

stalling SIPLACE Pro.

Before installing SIPLACE Pro make sure you use Prerequisite Analyzer of Support Media and

select SIPLACE Pro as planned Product to install all required missing prerequisites for SIPLACE

Pro (e.g. License Manager, Operation Manager, Error Reporter, .Net Framework). 3

Æ Network access rights must have been set up in order to permit data exchange with the

UNIX line computer.

Installation Manual 3 Important preparations prior to installation (Software configuration)

SIPLACE Pro 8.0 Edition 03/2010 US
