4.2.7 Setup Type – SIPLACE Pro Server
This setup type contains the "Server" portion of SIPLACE Pro, i.e. the server program and the
database. The "SIPLACE Pro Server" setup type is designed to be used if you want to separate
server and client in order to improve performance. 4
4
Fig. 4 - 24 Components – SIPLACE Pro Server
Step 1
Æ Run through the steps in ”Starting installation – first steps” from page 15.
Æ Select the SIPLACE Pro Server setup type.
Æ Then click Next.
The installation routine now checks whether: 4
– there is a connection to the SQL Server,
– whether a SIPLACE Pro database exists.
The subsequent steps are identical to the SIPLACE Pro complete system. 4
Step 2
Æ Continue by running through the steps described in ”Setup Type – SIPLACE Pro Complete
System” from page 23.
4
4
MS SQL Server pre-installed
Client computer with
SIPLACE Pro Desk or
Line Control GUI
SIPLACE Pro
Database
SIPLACE Pro
Interface
SIPLACE Pro
Server
Setup
COM+
COM+
OLE-DB
Resource
Manager
4 Installation of SIPLACE Pro and possible Setup Types Installation Manual
Edition 03/2010 US SIPLACE Pro 8.0
41
4.3 Steps to perform after installation
Note
After a new installation of the database, it is necessary to import the standard shape library in
SIPLACE Pro desk go to Tools-->Import-->Standard Shape Library... This step is required any-
way for you to use SIPLACE Pro and it ensures that data is available to be used for reporting.
After having upgraded the database from a previous version (see chapter 5 below) it is not nec-
essary to import data from the component shape library. 4
