Installation Manual 1 Introduction
SIPLACE Pro 8.0 Edition 03/2010 US
6
1.3.1 Computer
1
1
Server / Database Computer System
Software (required) Hardware (recommended)
– Preferred:
Windows Server 2008 SP 2 (32 Bit)
– Compatible:
Windows Server 2003 SP2 (32 Bit)
Windows Server 2003 SP2 (64 Bit)
Windows Server 2008 SP2 (64 Bit)
Windows Server 2008 SP 2 (32 Bit)
Windows Server 2008 SP 2 (64 Bit)
– Preferred:
Microsoft SQL Server 2008 SP1 /
Express Edition SP1 (32 Bit)
– Compatible:
Microsoft SQL Server 2005 SP1 /
Express Edition SP1 (32 Bit)
Microsoft SQL Server 2005 SP1 /
Express Edition SP1 (64 Bit)
Microsoft SQL Server 2008 SP1 /
Express Edition SP1 (64 Bit)
– Microsoft .NET Framework 3.5 SP1
– Intel Dual-/Quad-Core® Xeon™ 5200/5400
or higher
– 4096 MB RAM (2048 MB at least),
depending on the complexity of the data
content.
– >= 300 GB hard disk(s)
– Optional Backup drive (e.g. DAT, DVD)
– 21" monitor (19" monitor at least)
– Optional: Uninterruptible power supply
1 Introduction Installation Manual
Edition 03/2010 US SIPLACE Pro 8.0
7
1
1.3.2 Resource Requirements
1
Client Computer System
Software (required) Hardware (recommended)
– Preferred:
Windows Vista SP 2 (32 Bit)
– Compatible:
Windows 7 (32 Bit)
Windows 7 (64 Bit)
Windows Vista SP2 (64 Bit)
Windows XP SP3 (32 Bit)
Windows XP SP3 (64 Bit)
– Microsoft .NET Framework 3.5 SP1
– Intel ® Core™ 2 Duo CPU E8500 @
3.16GHz, 2 Cores, 2 Logical Processors or
better.
Note:: The SiCluster Professional GUI
e. g. uses multi core processors during
parallel optimization. 1
– 4096 MB RAM (2048 MB at least),
depending on the complexity of the data
content.
– 250 GB hard disk
– 21" monitor (19" at least) with a screen
resolution of at least 1024 x 1280 pixel
(small fonts)
Hard disk Main Memory
– Windows and program files:
= ~4000 MB
– Database and Backup:
= ~Number of optimized recipes x 20 MB
– Windows:
= ~200 MB.
– SQL Server:
= typically 500 MB (RAM requirement
depends on the data volume)
– LineControl Server:
= ~100 MB
– For every client (Desk, LineControl GUI,
Optimizer Toolkit) each:
= ~100 MByte + number of recipes x
number of placement positions / 1000 MB
Installation Manual 1 Introduction
SIPLACE Pro 8.0 Edition 03/2010 US
8
1.3.3 Products Compatible with SIPLACE Pro 8.0
1
1
Former SIPLACE Pro Versions 1
SIPLACE Pro 8.0 is compatible with SIPLACE Pro 1.x, 2.x, 3.x, 4.x, 5.x, 6.x, 7.x including all
released Hotfixes and Service Packs. 1
Note:
SIPLACE Pro installations from version 5.2 onwards are automatically de-installed when installing
SIPLACE Pro 8.0.
For installations before version 5.2 a corresponding message is displayed stating that SIPLACE
Pro has to be de-installed manually using the Control Panel. 1
Note:
During the installation, your SIPLACE Pro databases are automatically updated to the SIPLACE
Pro 8.0 data format.
Data model export files of previous SIPLACE Pro versions (from SIPLACE Pro 2.0 onward) can
be imported. 1
Information on the SIPLACE Pro Interface (SPI.NET) 1
SIPLACE Pro version 8.0 will be the last version supporting the SIPLACE Pro Interface (SPI.Net).
From SIPLACE Pro version 9.0 the SIPLACE Pro Interface (SPI. NET) will be replaced by
SIPLACE OIB. 1
You will find further details on the internet under http://www.siplace.com/, or you can as well
send an e-mail to partnersiplace.de@siemens.com. Thanks a lot for your interest. 1
Products Version
SIPLACE OIS/SIS 1 8.0 1
SIPLACE UNIX/LINUX Line Computer 1 402.01 – 503.xx 1
SIPLACE Explorer 1 2.7 1
SIPLACE EDM 1 1.8 1
SIPLACE Setup Center 1 3.3 1
SIPLACE CAD 1 4.1 SP2 1
