User Manual SIPLACE X-Series 3 Technical data for the machine
From software version SR.605.xx 07/2008 EN Edition 3.1 Performance data
103
3 Technical data for the machine
3.1 Performance data
3
3
3
3
Types of placement
head
20-segment Collect&Place head (C&P20A)
12-segment Collect&Place head (C&P12)
6-segment Collect&Place head (C&P6)
SIPLACE TwinHead (TH)
PLEASE NOTE IPC value (comp./h)
According to the vendor-neutral conditions of the IPC 9850 standard published
by the Association of Connecting Electronics Industries.
SIPLACE Benchmark value (comp./h)
The SIPLACE benchmark value is measured during the machine acceptance
tests. It corresponds to the conditions set out in the SIPLACE scope of service
and supply.
Theoretical maximum output value (comp./h)
The theoretical maximum output value is calculated from the most favorable con-
ditions for each machine type and setting, and corresponds to the theoretical
conditions normally used in the industry.
SIPLACE X4 placement system
Number of gantries 4
Placement area 1 Placement area 2 IPC value Benchmark value Theoretical value
C&P20 / C&P20 C&P20 / C&P20 81,000 90,000 124,000
C&P20 / C&P20 C&P12 / C&P12 65,000 71,400 102,500
C&P20 / C&P20 C&P12 / C&P6 60,300 65,300 94,000
C&P20 / C&P20 C&P12 / TH 57,500 63,800 89,000
C&P20 / C&P20 C&P6 / C&P6 56,900 63,300 85,000
C&P20 / C&P20 C&P6 / TH 53,100 59,400 80,000
C&P20 / C&P20 TH / TH 47,800 52,500 75,000
C&P12 / C&P12 C&P12 / C&P12 49,000 52,800 81,500
C&P12 / C&P12 C&P12 / C&P6 44,300 46,700 72,500
C&P12 / C&P12 C&P12 / TH 41,500 45,200 67,500
C&P12 / C&P12 C&P6 / C&P6 40,900 44,700 64,000
C&P12 / C&P12 C&P6 / TH 37,100 40,800 59,000
C&P12 / C&P12 TH / TH 31,800 33,900 53,500
C&P12 / C&P6 C&P12 / C&P6 39,600 40,600 64,000
C&P12 / C&P6 C&P12 / TH 36,800 39,100 59,000
C&P12 / C&P6 C&P6 / C&P6 36,200 38,600 55,000
C&P12 / C&P6 C&P6 / TH 32,400 34,700 50,000
C&P12 / C&P6 TH / TH 27,100 27,800 45,000
C&P12 / TH C&P12 / TH 34,000 37,600 53,500
3 Technical data for the machine User Manual SIPLACE X-Series
3.1 Performance data From software version SR.605.xx 07/2008 EN Edition
104
3
C&P12 / TH C&P6 / TH 29,600 33,200 45,000
C&P12 / TH TH / TH 24,300 26,300 40,000
C&P6 / C&P6 C&P6 / C&P6 32,800 36,600 46,000
C&P6 / C&P6 C&P6 / TH 29,000 32,700 41,000
C&P6 / C&P6 TH / TH 23,700 25,800 36,000
C&P6 / TH C&P6 / TH 25,200 28,800 36,000
C&P6 / TH TH / TH 19,900 21,900 31,000
TH / TH TH / TH 14,600 15,000 26,000
SIPLACE X3 placement system
For the placement head configuration and the placement rate see the note on page 103
.
Number of gantries 3
Placement area 1 Placement area 2 IPC value Benchmark value Theoretical value
C&P20 / C&P20 C&P20 62,200 69,500 93,000
C&P20 / C&P20 C&P12 53,600 59,000 82,500
C&P20 / C&P20 C&P6 49,200 54,800 73,500
C&P20 / C&P20 TH 44,800 50,000 68,500
C&P12 / C&P12 C&P12 37,600 40,400 61,000
C&P12 / C&P12 C&P6 33,200 36,200 52,500
C&P12 / C&P12 TH 28,800 31,400 47,000
C&P12 / C&P6 C&P6 28,500 30,100 43,500
C&P12 / C&P6 TH 24,100 25,300 38,500
C&P12 / TH TH 21,300 23,800 33,500
C&P6 / C&P6 C&P6 25,100 28,100 34,500
C&P6 / C&P6 TH 20,700 23,300 29,500
C&P6 / TH TH 16,900 19,400 24,500
TH / TH TH 11,600 12,500 19,500
SIPLACE X2 placement system
For the placement head configuration and the placement rate see the note on page 103
.
Number of gantries 2
Placement area 1 Placement area 2 IPC value Benchmark value Theoretical value
C&P20 C&P20 43,400 49,000 62,000
C&P20 C&P12 34,800 38,500 51,000
C&P20 C&P6 30,400 34,300 42,500
C&P20 TH 26,000 29,500 37,500
C&P12 C&P12 26,200 28,000 40,500
C&P12 C&P6 21,800 23,800 32,000
C&P12 TH 17,400 19,000 26,500
C&P6 C&P6 17,400 19,600 23,000
C&P6 TH 13,000 14,800 18,000
TH TH 8,600 10,000 13,000
User Manual SIPLACE X-Series 3 Technical data for the machine
From software version SR.605.xx 07/2008 EN Edition 3.1 Performance data
105
Placement posi-
tions
6,000 / gantry for the Collect&Place heads
2,000 / gantry for the TwinHead
Component range 0.4 x 0.2 mm² (01005), 0.6 x 0.3 mm² (0201)
to 85 x 85 mm² / 125 x 10 mm²,
max. 200 x 125 mm² (with restrictions)
Component
height
C&P20A: 4 mm
C&P12: 6 mm
C&P6: 8.5 mm
TH: 25 mm (larger heights available on request)
a
Placement accu-
racy
C&P20A ± 41 μm (3σ), ± 55 μm (4σ) CO camera, type 23 (6 x 6)
C&P12 ± 45 μm (3σ), ± 60 μm (4σ) CO camera, type 28 (18 x 18)
C&P12 ± 41 μm (3σ), ± 55 μm (4σ) CO camera, type 29 (27 x 27)
C&P6 ± 45 μm (3σ), ± 60 μm (4σ) CO camera, type 29 (27 x 27)
TH ± 26 μm (3σ), ± 35 μm (4σ) CO camera, type 33 (55 x 45)
TH ± 22 μm (3σ), ± 30 μm (4σ) CO camera, type 25 (16 x 16)
Angular accuracy C&P20A ± 0.5° (3σ), ± 0.7° (4σ) CO camera, type 23 (6 x 6)
C&P12 ± 0.5° (3σ), ± 0.7° (4σ) CO camera, type 28 (18 x 18)
C&P12 ± 0.5° (3σ), ± 0.7° (4σ) CO camera, type 29 (27 x 27)
C&P6 ± 0.2° (3σ), ± 0.3° (4σ) CO camera, type 29 (27 x 27)
TH ± 0.05° (3σ), ± 0.07° (4σ) CO camera, type 33 (55 x 45)
TH ± 0.05° (3σ), ± 0.07° (4σ) CO camera, type 25 (16 x 16)
Component feed-
ing
(component
trolley
X-series)
4 component trolleys with tape reel holder and integral waste tape container
40 x 8 mm X feeder module locations per component trolley or
matrix tray changer in place of component trolleys at locations 2 and 4
Feeder module
types (X-series)
Component tapes, waffle-pack trays
Feeding capacity
(component
trolley
X-series)
160 tracks Width: 8 mm 8 mm X feeder modules
80 tracks Width: 12 mm 12 mm X feeder modules
52 tracks Width: 16 mm 16 mm X feeder modules
5
2
tracks Width: 24 mm 24 mm X feeder modules
40 tracks Width: 32 mm 32 mm X feeder modules
32 tracks Width: 44 mm 44 mm X feeder modules
24 tracks Width: 56 mm 56 mm X feeder modules
20 tracks Width: 72 mm 72 mm X feeder modules
16 tracks Width: 88 mm 88 mm X feeder modules
Component feed-
ing
(CO trolley
HF-series
b
)
4 component trolleys with tape reel holder and integral waste tape container
15 x 30 mm wide locations per component trolley or
MTC in place of component trolleys at locations 2 and 4 (X4, X3, X2) or
WPC at location 2 (X3) or
WPC at locations 2 and 4 (X2)
Feeder module
types
(HF-series
b
)
Tapes, bulk cases, stick magazines, application-specific OEM feeder modules,
surftape feeder modules (8, 12, 16 mm), waffle-pack trays
