User Manual SIPLACE X-Series 3 Technical data for the machine From software version SR.605.xx 07/2008 EN Edition 3.2 Ratings 107 3.2 Ratings 3.2.1 Electrical ratings 3 3.2.2 Pneumatic ratings and compressed air specifica…
3 Technical data for the machine User Manual SIPLACE X-Series
3.1 Performance data From software version SR.605.xx 07/2008 EN Edition
106
3
Feeding capacity
(CO trolley
HF-series
b
)
180 tracks Width: 8 mm 60 S feeder modules, 3 x 8 mm
120 tracks Width: 8 mm 60 S feeder modules, 2 x 8 mm
60 tracks Width: 12 or 16 mm 60 S feeder modules, 12/16 mm
40 tracks Width: 24 or 32 mm 40 S feeder modules, 24/32 mm
28 tracks Width: 44 mm 28 S feeder modules, 44 mm
24 tracks Width: 56 mm 24 S feeder modules, 56 mm
20 tracks Width: 72 mm 20 S feeder modules, 72 mm
16 tracks Width: 88 mm 16 S feeder modules, 88 mm
PCB formats
(LxW)
Single conveyor
50 x 50 mm² to 450 x 508 mm²
Maximum dimensions: 685 x 610 mm²
Dual conveyor
50 x 50 mm² to 450 x 250 mm²
Maximum dimensions: 610 x 250 mm²
Dual conveyor in Single conveyor mode
50 x 50 mm² to 450 x 450 mm²
Maximum dimensions: 610 x 450 mm²
PCB thickness 0.3 to 4.5 mm (thicker PCBs available on request)
a) The specified component height may be reduced on the TwinHead in the placement area with two gantries
and a combination of Collect&Place head and TwinHead.
b) The HF-series component changeover table and feeder modules cannot be used together with the 20-seg-
ment Collect&Place head.
User Manual SIPLACE X-Series 3 Technical data for the machine
From software version SR.605.xx 07/2008 EN Edition 3.2 Ratings
107
3.2 Ratings
3.2.1 Electrical ratings
3
3.2.2 Pneumatic ratings and compressed air specification
3.2.2.1 Pneumatic ratings
3
Supply voltage 3 x 200 VAC ± 5 %; 50/60 Hz (Japanese version)
a
a) Connection at terminals 3 x 204 VAC on transformer T1
3 x 208 VAC ± 5 %; 50/60 Hz (U.S.A. version)
a
3 x 230 VAC ± 5 %; 50/60 Hz
3 x 380 VAC ± 5 %; 50/60 Hz
3 x 400 VAC ± 5 %; 50/60 Hz (Europe version)
3 x 415 VAC ± 5 %; 50/60 Hz
Fuses 3 x 32 A (3 x 200 VAC)
3 x 32 A (3 x 208 VAC)
3 x 32 A (3 x 230 VAC)
3 x 16 A (3 x 380 VAC)
3 x 16 A (3 x 400 VAC)
3 x 16 A (3 x 415 VAC)
Nominal apparent power 4.7 kVA (SIPLACE X4)
4.1 kVA (SIPLACE X3)
3.3 kVA (SIPLACE X2)
Rated current consumption 11.3 A / 3 x 400 VAC (SIPLACE X4)
9.7 A / 3 x 400 VAC (SIPLACE X3)
8.1 A / 3 x 400 VAC (SIPLACE X2)
Compressed air pressure
p
min
p
max
0.5 MPa = 5.0 bar
1.0 MPa = 10 bar
Compressed air connection R 3/4" internal thread (pipe thread) with 1/2" hose connector
Compressed air consumption
a
in relation to the placement
head configuration
b
SIPLACE X4
C&P20A/C&P20A/C&P20A/C&P20A 990 Nl/min
C&P20A/C&P20A/C&P12/C&P12 970 Nl/min
C&P20A/C&P20A/C&P6/C&P6 970 Nl/min
C&P20A/C&P20A/C&P6/C&P12 970 Nl/min
SIPLACE X3
C&P20A/C&P20A/C&P20A/ 780 Nl/min
C&P20A/C&P20A/C&P12 760 Nl/min
C&P20A/C&P20A/C&P6 760 Nl/min
3 Technical data for the machine User Manual SIPLACE X-Series
3.2 Ratings From software version SR.605.xx 07/2008 EN Edition
108
3.2.2.2 Compressed air specification
3
3
3
3.2.3 Ambient conditions
3
3
3
3.2.4 Ambient conditions for the packaging, transportation and storage
3
SIPLACE X2
C&P20A/C&P20A 570 Nl/min
C&P20A/C&P12 560 Nl/min
C&P20A/C&P6 560 Nl/min
Operating pressure 0.48 MPa ± 0.025 MPa (4.8 bar ± 0.25 bar)
a) Under normal atmospheric conditions at 20°C and 1013 hPa
b) Average air consumption during placement
Maximum particle size by density, based on ISO/DIS 8573-1 (class 1)
Particle size 0.1 µm
Particle density 0.1 mg/m³
Maximum oil content (class 1) Particle density 0.01 mg/m³
Pressure dewpoint (class 4) Dewpoint +3°
Temperature range Between 15°C and 35°C
Relative atmospheric humidity Between 30% and 90% at 20°C
Ambient pressure > 750 mbar (corresponds to 2,500 m above mean sea level)
Temperature range Between -25°C and 55°C
Relative atmospheric humidity Up to 95%
Ambient pressure Up to 3000 m height without pressure equalization
