User Manual SIPLACE X-Series 4 Setting up and commissioning
From software version SR.605.xx 07/2008 EN Edition 4.3 Setting up the placement machine
265
4.3.6 Fitting the output conveyor
4.3.6.1 Tools
– Allen keys, DIN 911, set
– Phillips screwdriver, size 1
4.3.6.2 Assembly
4
Fig. 4.3 - 7 Output conveyor - dual conveyor
(1) Rail, output conveyor
(2) Rail, processing conveyor 2
(3) Cable cover 20 x 200
(4) Countersunk screw, ISO 7046, M3x6, 2x per cable cover
(5) Cable cover 20 x 310
(6) Fillister head screw DIN 912, M3x5, 1x per cable cover
(7) Fillister head screw DIN 912, M6x16, and washer, 4x per rail
(8) Guide for hexagonal shaft
(9) Hexagonal shaft (single conveyor: one, dual conveyor: two)
(10) Drive unit
4 Setting up and commissioning User Manual SIPLACE X-Series
4.3 Setting up the placement machine From software version SR.605.xx 07/2008 EN Edition
266
→ Remove the cable covers (items 3 and 5 in Fig. 4.3 - 7, page 265) from the rails (item 1 in Fig.
4.3 - 7
, page 265) of the output conveyor.
→ Carefully place the rail (item 1 in Fig. 4.3 - 7
, page 265) against the rail on the processing
conveyor (item 2 in Fig. 4.3 - 7
, page 265).
CAUTION 4
Be careful not to cut through any of the light barrier or drive motor cables.
→ Fix each rail using 4 fillister head screws M6x16 and the associated washers (item 7 in Fig.
4.3 - 7
, page 265).
→ Connect the power cable to the light barriers and drive motors.
→ Fix the cable covers in place (item 3 and 5 in Fig. 4.3 - 7
, page 265).
→ Introduce the hexagonal shaft (item 9 in Fig. 4.3 - 7
, page 265) into the drive unit (item 10 in
Fig. 4.3 - 7
, page 265).
→ Make sure that the hexagonal shaft guide (item 8 in Fig. 4.3 - 7
, page 265) always points to-
wards the conveyor side wall to which the drive unit (item 10 in Fig. 4.3 - 7
, page 265) is fixed.
4.3.7 Fitting the extension kit on the PCB output side
4.3.7.1 Tools
– Allen keys, DIN 911, set
– Machine key
User Manual SIPLACE X-Series 4 Setting up and commissioning
From software version SR.605.xx 07/2008 EN Edition 4.3 Setting up the placement machine
267
4.3.7.2 Assembly
4
Fig. 4.3 - 8 Fitting the extension kit on the PCB output side
(1) Extension kit
(2) Door
(3) Fillister head screw DIN 912, M6x16 and washer
(4) Ground connection point
(5) Conveyor cover
(6) Side panel, detached
(7) Drawer unit rail
(8) Axis unit, gantries 1 and 3 (X2), axis unit, gantry 3 (X3) or axis unit, gantries 2 and 3 (X4)
