Placement head C+P20
Page 22 / 24 24.11.2021
Pos. Item no. Description Part marking
91 03042518-01 ISO 4762 - M 1,6 X 8-A2-70 STANDARD PARTS
92 03042532-01 ISO 4762 - M 2,5 X 5-A2-70 STANDARD PARTS
93 03042534-01 ISO 4762 - M 2,5 X 8-A2-70 STANDARD PARTS
94 03042542-01 ISO 4762 - M 3 X 8-A2-70 STANDARD PARTS
95 03042544-01 ISO 4762 - M 3 X 12-A2-70 STANDARD PARTS
96 03043114-01 ISO 4762 - M 3 X 35-A2-70 STANDARD PARTS
97 03042553-01 ISO 4762 - M 4 X 12-A2-70 Spare Part
98 03042558-01 ISO 4762 - M 4 X 40-A2-70 STANDARD PARTS
99 00303338-01 DIN 6325 - 1,5M5 X 5-ST
00308458-01 CABLE TIES B=2.5MM, L=102MM
PANDUIT
STANDARD PARTS
03029045-01 PACKAGING, COMPLETE
03020832-02 PACKAGING, C+P, PLASTICS
03028417-01 INNER PACKAGING MST ITEM 4903
03028418-02 CORRUGATED CARD BOARD BOX
485X395X280
105 03003426S05 BE CAMERA C+P (TYPE 23) 6X6
DIGITAL RK
SPARE PART
106 03042532-01 ISO 4762 - M 2,5 X 5-A2-70 STANDARD PARTS
107 03042534-01 ISO 4762 - M 2,5 X 8-A2-70 STANDARD PARTS
108 03023228-01 ISO 7046-2-M2,5 X 6-A2-70-H STANDARD PARTS
109 03013195-01 ILLUMINATION 80 DEGREE
COMPLETE
110 00325452-01 DIN 125-A 2,5-140HV-A2
03073100S02 ROUND CABLE SET: C+P-CAMERA
(TYPE23)
*
03075147S01 CABLE CUFF SPARE PART
03078496-01 NECK SCREW TORX M2,5X12.3 ST.
NICKEL
114 03075393-01 CABLE HOLDER SST23 IX03
00308458-01 CABLE TIES B=2.5MM, L=102MM
PANDUIT
STANDARD PARTS
116 00312509-01 DIN912-M3 X 12-A2-70
03049177-02 UPGRADE KIT / C&P20 X-SERIES
03012097-04 CABLE SET C+P20 SPARE PART
117 03002870-04 BOARD: HEAD ADAPTER C+P20 SPARE PART
118 03002397-03 CARD DC-DC CONVERTER, DP SPARE PART
Placement head C+P20
Page 23 / 24 24.11.2021
Pos. Item no. Description Part marking
119 00353445S04 SERVO AMPLIFIER SDS120/2,5S1 SPARE PART
120 03002143-01 SERVO AMPLIFIER SDS60/2.5Z1 SPARE PART
121 03055787-01 NOZZLE STATION CPLT. C+P20 /
D=1
WEAR PART
122 03005195-01 CABLE SUPP. HEAD ADAP. P+P /
C+P20 CPLT.
SPARE PART
123 03048638-02 BOX SPARE PART
03011720-01 SEALING HEAD MOUNT PLATE / VHS
03051467-01 PIPING OF NOZZLE STATION / WITH
VALVE
SPARE PART
03055785-01 VALVE FOR NOZZLE STATION CPLT.
03055792-01 QSY-6H-4 Y-STECKVERB. MIT
STECKHUELSE
STANDARD PARTS
00330249-01 BLANKING PLUG QSC-4H STANDARD PARTS
03056097-01 PUN-CM 4X0.75 / 125MM
03056096-01 PUN-CM 4X0.75 / 200MM
03040941-03 PIPING C+P20 / X-SERIES SPARE PART
03016216-01 HOSE / PRESSURE VALVE C+P 20
03070202-01 ESD-TUBE / RETAINING CIRCLE
C+P20
126 03006777-01 COOLING AIR TUBE X-MOTOR
127 00330249-01 BLANKING PLUG QSC-4H STANDARD PARTS
128 00337891-01 PLUG QSC-6H
129 03010908-01 PLUG QSC-8H
130 03006728S01 PVC CAP TYP D DI8,0 H 15 10X SPARE PART
03052349-01 PUSH-IN L CON. W. PUSH-IN SLEEVE
QSL-12H
SPARE PART
00119762-01 20 SEGM. C+P HEAD RECONFIG. KIT
X-SERIES
*
03008827-04 PLACEMENT HEAD C+P20
03040940-04 PARTS SET FOR RE-CONFIG X-
SERIES/C&P20
03049177-02 UPGRADE KIT / C&P20 X-SERIES
03011694-01 STENCIL VHS *
03039042-02 COMPONENT REJECT BOX - 6X6 SPARE PART
03049954-01 COMPONENT REJECT BOX UP TO
6X6
SPARE PART
03015210-01 STOPFEN QSC-12H
Placement head C+P20
Page 24 / 24 24.11.2021
Pos. Item no. Description Part marking
00318199-01 LOCKING VARNISCH GREY CONSUMABLE
03014437-01 CABLEHOLDER/ C+P SPARE PART
03041412-02 TUBE/ HOLDING CIRCLE C+P20
03051799-01 L-TYPE QUICK-RELEASE FASTENER
QSL-8
03052399-01 RECEPTACLE REDUCING QSH-12-8
03045404-01 PIPING OF NOZZLE STATION C+P20 SPARE PART
03043753-02 NOZZLE STATION CPLT. C+P20 SPARE PART
03076646-01 REJECT BIN X-SERIE / MTC
