M3_PartsList - 第34页
LC2-0302 Exterior , etc 10 1 Exterior , etc N o . Part No. Part Name Q'ty Remarks N o . Part No. Part Name Q'ty Remarks 1 KM6-M6514-00X CIRCUIT PROTECTOR, 4 1 39 2 KM5-M6554-10X MAIN SWITCH 1 40 3 LC2-M6561-00X…
LC2-0302
Controller
9
1
Controller
No. Part No. Part Name Q'ty Remarks No. Part No. Part Name Q'ty Remarks
1 KGN-M4510-00X MOTHER BOARD ASSY 1 3 9
2 KGN-M5840-01X SERVO BOARD ASSY 1 4 0
3 KW3-M4209-10X SYSTEM UNIT ASSY 1 4 1
4 KGN-M5810-00X DRIVER BOARD ASSY 1 4 2
5 KGJ-M441H-00X VISION BOARD ASSY 1 4 3
6 KGN-M4530-00X INTERFACE BOARD ASSY 1 4 4
7 KGN-M5880-00X D. POWER BOARD ASSY 1 4 5
8 KW3-M4256-00X CD-ROM DRIVE 1 4 6
9 KW3-M4230-00X FLASH BOARD ASSY 1 4 7
1 0 KGN-M4255-00X FLASH DISK 1 4 8
11 KV1-M5303-01X SW POWER DC5 1 4 9
12 KV1-M5303-11X SW POWER DC12 1 5 0
1 3 KGA-M4185-10X FAN MOTOR ASSY 2 5 1
14 52
15 53
16 54
17 55
18 56
19 57
20 58
21 59
22 60
23 61
24 62
25 63
26 64
27 65
28 66
29 67
30 68
31 69
32 70
33 71
34 72
35 73
36 74
37 75
38 76
LC2-0302
Exterior, etc
10
1
Exterior, etc
10
15
316 1
13 2 8 4
9 7 11, 12 6 5 14
LC2-0302
Exterior, etc
10
1
Exterior, etc
No. Part No. Part Name Q'ty Remarks No. Part No. Part Name Q'ty Remarks
1
KM6-M6514-00X CIRCUIT PROTECTOR, 4 1
39
2
KM5-M6554-10X MAIN SWITCH 1
40
3
LC2-M6561-00X POWER SUPPLY 1 1
41
4
KGA-M6185-00X FAN MOTOR ASSY 1
42
5
KG7-M530H-01X FLOPPY DISK DRIVE 1
43
6
KH1-M5138-00X SWITCH EMG ASSY 1
44
7
KGN-M4570-00X I/O BOARD HEAD ASSY 1
45
8
LC2-M6530-00X OPERATION PANEL ASSY 1
46
9
LC2-M5109-10X MONITOR 15 COLOR" 1
47
10
KU8-M65F5-00X VGA ADAPTER 1
48
11
KW3-M5150-00X KEYBOARD J 1
49
12
KW3-M5150-10X KEYBOARD E 1
50
13
KW3-M5169-00X MOUSE 1
51
14
KGA-M13B6-00X MOUSE POCKET 1
52
15
KV7-M4888-10X LIGHT 1 (L=300) 1
53
16 KH4-M668R-00X HERNESS, 8-11 (SW COVER) 2 5 4
17 55
18 56
19 57
20 58
21 59
22 60
23 61
24 62
25 63
26 64
27 65
28 66
29 67
30 68
31 69
32 70
33 71
34 72
35 73
36 74
37 75
38 76
