Æ Screw the thread of the middle machine foot into the hole on the underside of the spacer.
Æ Align the two spacers on the underside of the machine as follows:
– The opening in the spacer on the pneumatic unit side points in the direction of PCB trans-
port (see point 4 in Fig. 4.4 - 3
on page 180).
– The opening in the spacer on the power supply side points against the direction of PCB
transport (see point 3 in Fig. 4.4 - 3
on page 180).
Æ Fix each spacer using four hexagon socket head screws M12x80 (see point 4 in Fig. 4.4 - 4)
using the size 10 mm screwdriver bit.
Setting the PCB transport height to 930 mm and 950 mm 4
You will also need the spacer for PCB transport heights of 930 mm and 950 mm.
Æ Align the spacer so that the 122.5 mm side is vertical and the hole for the middle machine foot
points downwards.
4
Fig. 4.4 - 5 Alignment of the spacer for transport heights of 930 and 950 mm
4
(1) Spacer height 122.5 mm
(2) Middle machine foot
(3) M24 lock nut
(4) Hexagon socket head screw M12x80, 4x
122.5 mm
User manual SIPLACE HF series 4 Setting up and commissioning
Software Version SR.50x.xx 01/2006 US Edition 4.4 Setting up the placement machine
183
Æ Screw the thread of the middle machine foot into the hole on the underside of the spacer.
Æ Align the two spacers as follows:
– The opening in the spacer on the pneumatic unit side points in the direction of PCB trans-
port (see point 4 in Fig. 4.4 - 3
on page 180).
– The opening in the spacer on the power supply side points against the direction of PCB
transport (see point 3 in Fig. 4.4 - 3
on page 180).
Æ Fix each spacer using four hexagon socket head screws M12x80 (see point 4 in Fig. 4.4 - 5)
using the size 10 mm screwdriver bit.
4.4.4.2 Presetting the height of the outer machine feet
4
Fig. 4.4 - 6 Presetting the height of the machine feet
(1) Machine foot - 2 versions
(2) M24x90 hexagon socket head screw
(3) M24x2x120 adjusting screw
4 Setting up and commissioning User manual SIPLACE HF series
4.4 Setting up the placement machine Software Version SR.50x.xx 01/2006 US Edition
184
Æ Use the 19 mm bit to loosen the two hexagon socket head screws M24x90 (item 4 in Fig.
4.4 - 6
), and allow the machine foot (item 5 in Fig. 4.4 - 6) to slide down slowly.
Æ Insert the correct machine foot for the required PCB conveyor height.
There are two versions of the outer machine feet: 4
– outer machine foot for the PCB conveyor height of 830 mm, length 369 mm,
item no. 03041008-01 (item 1 in Fig. 4.4 - 3
, page 180)
– outer machine foot for the PCB conveyor heights of 900, 930 and 950 mm,
length 439 mm, item no. 03000890-02 (item 2 in Fig. 4.4 - 3
, page 180)
Æ Preset the height for each of the outer machine feet.
The distance between the underside of the machine foot and the bottom edge of the machine
frame should be as follows:
Æ Use the size 36 fork wrench to turn the adjusting screw M24x2x120 (item 3 in Fig. 4.4 - 6)
until you obtain the distance values given in the above table for the particular transport height.
Æ Now use the fork-lift to carefully lower the placement machine until the machine feet touch
the floor evenly. There should always be a second person present to ensure that the machine
remains stable while it is being lowered. It may be necessary to loosen the outer machine feet
clamps slightly.
Æ Continue carefully lowering the machine until the outer machine feet touch the screws
M24x2x120 (item 3 in Fig. 4.4 - 6
) for adjusting the height.
Æ Make sure that the middle machine feet (see point 2 in Fig. 4.4 - 3, page 180) do not yet touch
the floor. If necessary, screw the middle machine feet into the machine or spacer slightly.
PLEASE NOTE 4
A description of how to definitively adjust the machine can be found in section 4.4.15
on page
219.
PCB transport height
Distance from underside of machine foot
to bottom edge of machine frame
830 mm 120 mm
900 mm 190 mm
930 mm 220 mm
950 mm 240 mm
