5.5 Changing the set-up
5.5.1 Printing out the conversion instructions before changing the set-up
Before a change of set-up, print out the conversion instructions on the printer for the SIPLACE Pro
computer as described in the "SIPLACE Pro" manual or in the online help.
5.5.2 What you should note when changing the feeder modules
Æ Handle the feeder modules carefully when you insert them into or remove them from the com-
ponent feeder table. Make sure that the feeder modules do not bump against the CO table
edges.
Æ Vacuum the supporting surfaces of the feeders and clean the surface of the component
feeder table when necessary according to the instructions in the Preventive Maintenance
Manual.
CAUTION
Avoid removing components from the magnetic rail of the component table with your fingers.
You may hurt yourself with tiny splinters of metal. 5
Æ Remove loose components using a brush or a vacuum cleaner with a suitable nozzle.
User manual SIPLACE HF series 5 Tasks on the machine
Software Version SR.50x.xx 01/2006 US Edition 5.6 Avoiding track errors
237
5.6 Avoiding track errors
5.6.1 General
Æ Make sure that the areas around the feeder modules are clean and that there are no loose
components in the feeder area or under the feeder modules.
Æ Ensure that the supporting surfaces of the feeder modules, and particularly the magnetic rails
of the component feeder tables, are clean and level.
Æ Refill promptly with components.
Æ Splice the tapes early. This generally means that you are to prepare the splicing material
when there is still approximately 1.5 m of tape on the reel.
Æ Handle the feeder modules carefully when you insert them into or remove them from the com-
ponent feeder table as these are high-precision devices.
Æ Close the flaps of the feeder modules because they can be easily damaged when open.
Æ Check that the pick-up position is set correctly for the components on the S feeder modules.
Æ Check to see if all the plugs of the S feeder modules are plugged in to the correct sockets.
5.6.2 Avoiding track errors with the tape container
Æ Insert the separating plates correctly (see Fig. 5.3 - 2).
Æ Tape reels with a diameter of 15" (381 mm) or more should be stored on spindles.
5 Tasks on the machine User manual SIPLACE HF series
5.6 Avoiding track errors Software Version SR.50x.xx 01/2006 US Edition
238
5.6.3 Component coordinate system and pick-up angle
5
Fig. 5.6 - 1 Position of the component and its pick-up angle
Special
component
Stick
magazine:
Chip-
components
with polarity
0402
2220
The anode must be
aligned with the +X
coordinate.
Package form
type
Coordinate system
Position in the feeder
Pick-up angle/
nozzle angle
Tape:
SOT 23
Stick
magazine:
Tape:
Tape:
SO-IC
DIL-IC
SOT 194
Tape:
Holes
Y
X
Y
X
Y
X
Y
X
Y
X
90°
90°
0°
90°
-90°
0°
