7.12.4 Overview
7.12.4.1 Analysis unit
The coplanarity laser module consists of two components: the analysis unit with its control section,
and the laser module. The analysis unit is located in the computer unit (see Fig. 7.12 - 4
). The
operating state is indicated by three green LEDs on the front panel of the analysis unit:
7
Press the RESET key to initialize the coplanarity laser module.
7.12.4.2 Laser module
The laser module is fixed to a supporting frame (see Fig. 7.12 - 5).
Two red LEDs and one green LED signal the operating states of the laser module:
7
LED (see Fig. 7.12 - 4)On Off
1 green 5 operating voltage No voltage
2 green 12V operating voltage No voltage
3 green Laser module in use Laser module switched off
LED (see Fig. 7.12 - 5)On Off
4 red
OUT OF RANGE
(outside the measuring range)
–
5 red
POOR TARGET
(component is insufficiently reflective)
–
6 green Laser module in use Laser module switched off
User manual SIPLACE HF series 7 Station extensions
Software Version SR.50x.xx 01/2006 US Edition 7.12 Coplanarity laser module
347
Fig. 7.12 - 4 Coplanarity laser module overview
(1) Green LED: 5V operating voltage
(2) Green LED: 12V operating voltage
(3) Green LED: laser module switched on
(4) RESET key
(5) SUB-D plug, 9-pin, COM2: to the machine controller
(6) SUB-D plug, 15-pin: to the laser module
(7) Analysis unit with control section
(8) Computer unit
7 Station extensions User manual SIPLACE HF series
7.12 Coplanarity laser module Software Version SR.50x.xx 01/2006 US Edition
348
7
Fig. 7.12 - 5 Coplanarity module
(1) Laser module
(2) Connecting cable
(3) Red LED: OUT OF RANGE
(4) Red LED: POOR TARGET
(5) Green LED: LASER ON
(6) ’Laser class 3B’ sticker, see Fig. 7.12 - 2
