User manual SIPLAC E HF series 2 Operational safety Software Vers ion SR.50x.xx 01/2006 US Edition 2.2 Warning labels 45 2.2.8 W arning label W207 2 Pos. W2 07 in Fi gs. 2.2 - 1 1 and 2.2 - 12 , item no. 030 09346-01 (nu…
2 Operational safety User manual SIPLACE HF series
2.2 Warning labels Software Version SR.50x.xx 01/2006 US Edition
44
2
Pos. H in Fig. 2.2 - 10 (number per power supply unit: 2)
2.2.7 Warning label W on the cover over the main power supply for the servo
amplifier
2
Fig. 2.2 - 10 Warning label W on the cover over the main power supply for the servo amplifier
2
Pos. W in Fig. 2.2 - 11 (number per power supply unit: 8) see Fig. 2.2 - 10 too
User manual SIPLACE HF series 2 Operational safety
Software Version SR.50x.xx 01/2006 US Edition 2.2 Warning labels
45
2.2.8 Warning label W207
2
Pos. W207 in Figs. 2.2 - 11 and 2.2 - 12, item no. 03009346-01
(number per placement system: 2 for the HF, 3 for the HF/3)
2.2.8.1 Warning label W207 on the axis unit
2
Fig. 2.2 - 11 Warning label W207 on the axis unit Macrolon panel
Pos. W207, item no. 03009346-01
2
2
MAIN POWER VOLTAGE!
Switch off the main power switch and wait 30 seconds until the
capacitors have discharged.
NAFTA region: RISK OF ELECTRIC SHOCK OR BURN!
2 Operational safety User manual SIPLACE HF series
2.2 Warning labels Software Version SR.50x.xx 01/2006 US Edition
46
2.2.8.2 Warning label W207 on the inrush current limitation for the main power supply
2
Fig. 2.2 - 12 Warning label W207 on the inrush current limitation for the main power supply
Pos. W207, item no. 03009346-01
PCB1 Board, inrush current limiter - transformer
PCB2 Board, inrush current limiter - servo unit
PCB2
PCB1
