SW 703 Option MTC - Magnets Under The Carrier :
96
Magnets Under The C arrier
1. Physically check if there are magnets from the bottom
carrier stuck underneath the carrier above.
WARNING! Magnets under the tray could result
in a crash! Take care to avoid this!
SW 703 Option MTC - Locking Of The Leaf Springs (Towers 1 & 2) :
97
Locking Of Th e Leaf Springs (T owers 1 & 2)
1. Leaf Springs are often found unlocked due to
improper loading of the carriers
WARNING! A crash could occur if the carriers
are not loaded correctly and the leaf springs are not
closed.
SW 703 Option MTC - Filling MTC :
98
Filling MTC
1. Location 2 (Matrix Tray Changer).
2. Locations menu icon – click here to enter the feeder
menu.
