Option List for the SIPLACE X-Series

Available options X4 X3 X2 Notes

MTC2 – X X On the X3, in placement area 2 only

Not possible on the X4

The MTC2 cannot be used with the 20-nozzle

Collect & Place head.

Manual tray – X X SIPLACE HF component changeover table

SIPLACE X component changeover table X X X

SIPLACE HF component changeover table X X X Not in combination with the C&P20 head

Fixed SIPLACE X component table X X X

Nozzle changer (according to the head) X X X

6-nozzle Collect&Place head X X X

12-nozzle Collect&Place head X X X

TwinHead – X X On the X3, in placement area 2 only

Not possible on the X4

20-nozzle Collect&Place head X X X In the two-gantry area, only in combination with

another 20-nozzle Collect & Place head

Camera type 29 (for C&P12) X X X

Stationary camera, type 25 – X X For the TwinHead only

Coplanarity module – X X For the TwinHead only

Dip module X X X For SIPLACE HF CO changeover tables only

Not for the C&P20 head

Smart Scan X X X

SIPLACE PCB barcode X X X

Further PCB barcode scanners X X X

Single conveyor, fixed side on the right X X X

Single conveyor, fixed side on the left X X X

Dual conveyor, fixed side on the right X X X

Dual conveyor, fixed side on the left X X X

Long board option X X X

PCB alignment, single conveyor X X X

PCB alignment, dual conveyor X X X

Productivity lift X X X Max. PCB width

- Single track 460 mm

- Double track 216 mm

Max. CO height 17 mm on the underfloor section

If the Productivity lift is installed at location 4,

then no MTC2 may be attached to the SIPLACE X2.

Transport height (900, 930, 950) X X X

Vacuum pump X X X Not on the 20-nozzle Collect & Place head

Not on the TwinHead
