GEM Manual for DEK Printers Equipment Variables Issue 1.6 January 22, 2018 Page 108 of 171 6.2 Equipment Constants The equipment constants are defined in the table below: Note: Default values are shown bold . NAME ECI D …

GEM Manual for DEK Printers Equipment Variables

Issue 1.6 January 22, 2018 Page 107 of 171

6.1 Introduction

A set of variable definitions is provided to enable the host to monitor and sometimes alter, the

behaviour of the equipment. These are known as machine variables.

Machine variables are divided into the following three categories.

Equipment Constants: Allow the host to modify certain aspects of the equipment’s

behaviour. See section 5.5 for a discussion on the use of EC’s.

Status Variables: As the name suggests, these variables track continuous system

status values. The host can interrogate the equipment at any time

and can programme the equipment to transmit values on a

regular schedule. The host cannot change these values.

See section 5.2 for a discussion on data collection methods.

Discrete Data Variables: Are similar to Status Variables except that their values are valid

only when specific events occur. The host should not interrogate

these values, but should include them in reports linked to

collection events.

See section 5.2 for a discussion in on data collection methods.

Process Attributes: These variables are used to request name and value information

about the currently loaded printer product.

The machine variables are listed by category in the following sections.

GEM Manual for DEK Printers Equipment Variables

Issue 1.6 January 22, 2018 Page 108 of 171

6.2 Equipment Constants

The equipment constants are defined in the table below:

Note: Default values are shown bold.

NAME ECI

DESCRIPTION Type Value Range S2F15

Compatible

GemConfigConnect 1 Select establish communications

type.

U1 1 = S1F13 Yes

DeviceName 2 Equipment name as defined by the

host.

A20 20 characters Yes

GemEstabCommDelay 3 Time between each S1F13 poll. U2 0-60-1800 s Yes

GemPollDelay 4 Time between each S1F1 poll. U2 0-60-1800 s Yes

GemInitCommState 5 Initial communications state. U1 1 = Enable

0 = Disable

Yes

GemInitControlState 6 Initial control state. U1 1 = OFF-LINE

2 = ON-LINE

Yes

GemOfflineSubstate 7 Set default control sub-state when

equipment is OFF-LINE.

1 = Equipment Off-

Line

2 = Attempt On-Line

3 = Host Off-Line

Yes

GemOnlineFailed 8 Default sub-state following ON-

LINE failure.

1 = Equipment Off-

Line

2 = Host Off-Line

Yes

GemOnlineSubstate 9 Default sub-state when entering ON-

LINE state.

4 = Local

5 = Remote

Yes

received_mode 10 Set System Mode. This constant is

volatile and defaults to Auto on

machine power up.

1 = Auto

3 = Pass Through

Yes

InspectRate 11 Number of print cycles between

board inspections. 0 indicates no

inspection

F8 0 – 100 Yes

BatchLimit 12 Number of boards to be printed in a

production batch. O indicates no

batch limit

U4 0 - 99999 Yes

process_adjustments 13 Enables/disables adjustment of the

current printing process while the

machine is running.

0 = Enabled

1 = Operator disabled

2 = Remote

command disabled

3 = Both disabled

Yes

MaxSpoolTransmit 14 The maximum number of messages

that the equipment will transmit from

the spool in response to a

S6F23”Transmit spooled Messages”

request. If MaxSpoolTransmit is set

to zero, no limit is placed on the

messages sent from the spool. Multi-

block inquire/grant messages are not

counted in this total.

Minimum = 0

Maximum = value of

SpoolCountActual

Yes

OverWriteSpool 15 Tells the printer to overwrite data in

the spool area or stop spooling

whenever the spool area limits are

exceeded.

1 = TRUE to

overwrite spooled

data

0 = FALSE to stop

spooling when limits

are exceeded.

Yes

GEM Manual for DEK Printers Equipment Variables

Issue 1.6 January 22, 2018 Page 109 of 171

spooling_enabled 16 Allows the equipment to default to a

condition where spooling is disabled

completely. This is provided for older

Hosts that do not support S6F23. This

EC is set to TRUE = 1 on receipt of

S2F43 defining messages to be

spooled.

0 = FALSE spooling

disabled

If the Host sets this

EC to FALSE any

data in the spool will

be purged.

Yes

Reserved 17-

Not used by the 265.

TimeFormat 40 The setting of this ECV controls

whether the equipment shall send the

Data Items STIME and TIME in 12-

byte or 16-byte format. It also

controls the format of

START_TIME. to be 6 or 7 bytes.

B1 0 = 12 byte format

1 = 16 byte format

>1 reserved

Yes

RunGEMRemote 41 Allows control of the Run With GEM

Remote parameter. When enabled,

only the host can start the printer and

the operator is given an appropriate

message.

0 = Disable

1 = Enable

Yes

CompoundProductFiles 46 Controls whether Compound Product

functionality is enabled or disabled.

0 = Disable

1 = Enable

Yes

Make 50 Printer make. Always returns “DEK” A20

“DEK”

Model 51 The model of the printer A20 For example

“Galaxy”

StencilCleaningSystem 53 The currently selected cleaner

module

0 = None

1 = Blue

2 = Vortex

3 = Cyclone

4 = Cyclone Duo

ApplicatorType 54 The currently selected applicator

module

0 = Squeegees

1 = ProFlow (classic)

2 = Ball Placement

3 = ProFlow Tx

4 = ProFlow ATx

ConveyorType 55 The fitted conveyor type U1

0 = Standard

1 = HTC

2 = RTC

TransportMode 56 The current rail transport mode U1

0=LeftToRight

1=RightToLeft

2=RightToRight

3=LeftToLeft

4=NoTransfer/Shuttle

Yes

MachineUnits 57 The current machine units U1

0=Metric

1=Imperial

Yes

UplineProtocol 58 The current up-line FMI protocol U1

0=NoFMI

1=MIU

2=Manual

Yes

DownlineProtocol 59 The current downline FMI protocol U1

0=NoFMI

1=MIU

2=Manual

Yes

TransferPeriod 60 FMI transfer period (s) U2 0 – 999, 20 Yes

PasteDispensePosition 61 The position the paste dispenser uses U1 0=Front

1=Rear

2=Auto

Yes
