GEM Manual for DEK Printers Equipment Variables
Issue 1.6 January 22, 2018 Page 112 of 171
6.3 Status Variables
The status variables are defined in the table below:
Name SVID
Limits
Monitor
Description Type Value Range
GemAlarmsEnabled 1001
No
List of alarms that are enabled. List A list of “n” ALID’s.
GemAlarmsSet 1002
No
List of alarms that are set. List A list of “n” ALID’s.
See chapter 6 for ALID’s.
GemAlarmState 1003
No
State of last alarm transition. U1 0 = OFF
1 = ON
clock 1004
No
Host view of equipment time.
(centisecond precision)
A12/A16
Yymmddhhmmss
Yyyymmddhhmmsscc
GemControlState 1005
No
Current GEM Control State. U1 1 = Equipment Off-Line
2 = Attempt On-Line
3 = Host Off-Line
4 = Local
5 = Remote
process_state 1006
No
Current Equipment Process State. U1 0 = Equipment Ready
1 = Equipment Waiting
2 = Equipment Running
3 = Equipment Setup
4 = Equipment Down
5 = Equipment Recovery
6 = Equipment Maintenance
GemEventsEnabled 1007
No
List of collection events enabled. List A list of “n” CEID’s.
See chapter 7.
humidity 1008 Yes Current humidity in print area. F4 0-100 %
model_number 1009
No
Model number. A6 String
previous_command 1010
No
Last command received from operator
or host.
A See appendix A.
GemPreviousControlState
1011
No
Control state prior to last transition. U1 See GemControlState.
last_process_state 1012
No
Process state before last transition. U1 See process_state.
GemPreviousCeid 1013
No
CEID of last collection event to occur.
U4 See chapter 7.
Reserved 1014
No
software_version 1015
No
Software revision 6 char ASCII. A6 See chapter 4. (SOFTREV)
temperature 1016 Yes Current temperature in the print area. F4 0 -100 (Celsius)
current_time 1017
No
Host view of equipment time.
(1 second precision)
A12/A16
Yymmddhhmmss
Yyyymmddhhmmsscc
system_mode 1018
No
The current machine mode. U1 0 = Step
1 = Auto
2 = Single
3 = No Print
PPExecName 1019
No
Name of cu
rrent process program. A68
batch_count 1020 Yes
Number of Boards printed.
U4 0-99999
Reserved 1021
No
time_last_print 1022
No
Time of the last print. A12/
A16
Yymmddhhmmss/
Yyyymmddhhmmsscc
GEM Manual for DEK Printers Equipment Variables
Issue 1.6 January 22, 2018 Page 113 of 171
spc_data_mode 1023
No
Reporting mode of the SPC. U1 0 = Serial
1 = Disk
2 = Invalid
3 = None
screen_status 1024
No
The position of the screen in the
printer chase.
U1 1 = No screen.
2 = Screen loaded.
3 = Unloaded at front.
4 = Unloaded at rear.
5 = Screen in chase, but not
loaded.
software_version_param 1025
No
The software version to be stored in
the process program file that indicates
the version of software that last
modified the file.
A20 SSS Version MM.mm
SSS = Source machine type.
MM = Major version level.
mm = Minor version level.
SpoolCountActual 1026
No
Used to keep a count of the messages
actually contained in the printer's
spool area. Multi-block inquire/grant
messages are not
spooled and not included in this count.
U4 0 to 2000 (absolute maximum)
SpoolCountTotal 1027
No
Used to keep a count of the total
number of primary messages directed
to the spool, regardless of whether
placed or retained in the
spool. Multi-block inquire/grant
messages are not spooled and not
included in this count.
U4 0 to 0xFFFFFFFF
SpoolFullTime 1028
No
Contains the timestamp from the time
the spool last became full. If the spool
was not filled during the last spooling
period, this will contain a time value
prior to the current SpoolStartTime
.
A12/A16
Yymmddhhmmss
Yyyymmddhhmmsscc
SpoolStartTime 1029
No
Contains the timestamp from the time
spooling last became active.
A12/A16
Yymmddhhmmss
Yyyymmddhhmmsscc
Reserved 1030 -
1049
Not used by the 265.
PPChangeName 1050
No
The name of the last process program
changed (created, modified or deleted)
A68
PPChangeStatus 1051
N
o The change operation last performed U1 1 = Load
2 = Rename
3 = Erase
64 = Created
65 = Renamed
PPError 1052
No
Details of any failed product
validation after up/download
U1 0 = None
PPFormat 1053
No
The format of DEK process programs
U1 Always 1 - Unformatted
GEM Manual for DEK Printers Equipment Variables
Issue 1.6 January 22, 2018 Page 114 of 171
6.4 Discrete Data Variables
The discrete data variables are defined in the table below:
Name DVID
Limits
Monitor
Description Type Value Range
GemAlarmId 2001 No Identity of alarm transition. U4 See chapter 6.
pp_old_file_name 2002 No Name of process program being
changed.
A68 Any characters valid in a
Windows filename.
pp_change_status 2003 No Type of process program change. U1 1 = Load process program
2 = Rename process
program
3 = Erase process program
measured_cycle_time 2004 Yes The duration in seconds of the
most recent machine cycle.
F8 0 = no data
to 3.2 million seconds
throughput_cycle_time 2005 Yes
The average duration in seconds of
the machine cycle time. Averaged
over the last 1 to 50 cycles.
F8 0 = no data
to 3.2 million seconds
Reserved 2006 No
ecid_changed 2007 No VID of changed equipment
constant.
U4
front_print_pressure 2008 Yes Front squeegee pressure of last
cycle.
F8 0-20 Kg
rear_print_pressure 2009 Yes Rear squeegee pressure of last
cycle.
F8 0-20 Kg
print_speed 2010 Yes Speed measured during the last
print stroke.
F8 2-300 mm/s
table_separation_speed 2011 Yes Speed of board and screen
separation measured during last
print cycle.
F8 0.1-20 mm/s
board_stretch_error 2012 Yes Difference between board and
screen fiducials measured after the
print cycle.
F8
5.0 mm
Xerr 2013 Yes X alignment accuracy. F8
0.025 mm
Yerr 2014 Yes Y alignment accuracy. F8
0.025 mm
theta_err 2015 Yes Theta alignment accuracy. F8 arcsec
Squeegee 2016 No Squeegee used to perform the last
print.
U1 0 = No action.
1 = Front squeegee.
2 = Rear squeegee.
current_screen_bar_code
2017 No The barcode of the current screen
as scanned when the screen was
loaded.
The default is “NO CODE”.
A32
Up to a 32 character string.
The actual length is
determined by the barcode.
old_time 2018 No The previous value of the clock
before it was last changed.
A12
A16
Yymmddhhmmss
Yyyymmddhhmmsscc
new_time 2019 No The time that the clock was last
changed.
A12/
A16
Yymmddhhmmss
Yyyymmddhhmmsscc
product_bar_code 2020 No The most recent barcode scanned
by the product barcode reader. The
default is “NO CODE”.
A32
Up to a 32 character string.
The actual length is
determined by the barcode.
board_fiducial_1_score 2021 Yes The acceptance score of board
fiducial 1.
U4 0-1000
board_fiducial_2_score 2022 Yes The acceptance score of board
fiducial 2.
U4 0-1000
