GEM Manual for DEK Printers Equipment Variables
Issue 1.6 January 22, 2018 Page 114 of 171
6.4 Discrete Data Variables
The discrete data variables are defined in the table below:
Name DVID
Limits
Monitor
Description Type Value Range
GemAlarmId 2001 No Identity of alarm transition. U4 See chapter 6.
pp_old_file_name 2002 No Name of process program being
changed.
A68 Any characters valid in a
Windows filename.
pp_change_status 2003 No Type of process program change. U1 1 = Load process program
2 = Rename process
program
3 = Erase process program
measured_cycle_time 2004 Yes The duration in seconds of the
most recent machine cycle.
F8 0 = no data
to 3.2 million seconds
throughput_cycle_time 2005 Yes
The average duration in seconds of
the machine cycle time. Averaged
over the last 1 to 50 cycles.
F8 0 = no data
to 3.2 million seconds
Reserved 2006 No
ecid_changed 2007 No VID of changed equipment
constant.
U4
front_print_pressure 2008 Yes Front squeegee pressure of last
cycle.
F8 0-20 Kg
rear_print_pressure 2009 Yes Rear squeegee pressure of last
cycle.
F8 0-20 Kg
print_speed 2010 Yes Speed measured during the last
print stroke.
F8 2-300 mm/s
table_separation_speed 2011 Yes Speed of board and screen
separation measured during last
print cycle.
F8 0.1-20 mm/s
board_stretch_error 2012 Yes Difference between board and
screen fiducials measured after the
print cycle.
F8
5.0 mm
Xerr 2013 Yes X alignment accuracy. F8
0.025 mm
Yerr 2014 Yes Y alignment accuracy. F8
0.025 mm
theta_err 2015 Yes Theta alignment accuracy. F8 arcsec
Squeegee 2016 No Squeegee used to perform the last
print.
U1 0 = No action.
1 = Front squeegee.
2 = Rear squeegee.
current_screen_bar_code
2017 No The barcode of the current screen
as scanned when the screen was
loaded.
The default is “NO CODE”.
A32
Up to a 32 character string.
The actual length is
determined by the barcode.
old_time 2018 No The previous value of the clock
before it was last changed.
A12
A16
Yymmddhhmmss
Yyyymmddhhmmsscc
new_time 2019 No The time that the clock was last
changed.
A12/
A16
Yymmddhhmmss
Yyyymmddhhmmsscc
product_bar_code 2020 No The most recent barcode scanned
by the product barcode reader. The
default is “NO CODE”.
A32
Up to a 32 character string.
The actual length is
determined by the barcode.
board_fiducial_1_score 2021 Yes The acceptance score of board
fiducial 1.
U4 0-1000
board_fiducial_2_score 2022 Yes The acceptance score of board
fiducial 2.
U4 0-1000
GEM Manual for DEK Printers Equipment Variables
Issue 1.6 January 22, 2018 Page 115 of 171
board_fiducial_3_score 2023 Yes The acceptance score of board
fiducial 3.
3 fiducial mode must be selected.
U4 0-1000
screen_fiducial_1_score 2024 Yes The acceptance score of screen
fiducial 1.
U4 0-1000
screen_fiducial_2_score 2025 Yes The acceptance score of screen
fiducial 2.
U4 0-1000
screen_fiducial_3_score 2026 Yes The acceptance score of screen
fiducial 3.
3 fiducial mode must be selected.
U4 0-1000
LimitVariable 2027 No This variable contains the VID for
the variable whose value changed
monitoring zones.
U4 See list of VID’s for limits
monitoring.
EventLimit 2028 No This variable contains the
LIMITID of the limit reached or
crossed by LimitVariable. Since
multiple zone transitions for a
variable may occur simultaneously,
EventLimit has been defined to
allow for a list of LIMITIDs.
List of U1 1-7
TransitionType 2029 No This variable defines the direction
of the zone transition that has
occurred.
B
1 byte
0 = Transition from lower
zone to upper zone.
1 = Transition from upper
zone to lower zone.
RemoteBarCode 2030 No Product bar code string provided
by the serial bar code reader.
The default is “NO CODE”.
A32
Up to a 32 character string.
The actual length is
determined by the barcode.
ProflowPastePressure 2031 Yes Actual Paste Pressure used by the
Proflow paste mechanism.
F8 0-20 Kg
Reserved 2032 No Not used by the 265.
Traceability Data 2033 No List of traceability data for the last
processed product.
Variable See <Traceability Data>
Failed verification item 2034 No List of the items that last failed
verification
Variable See <Failed Verification
Items>
Reserved 2083 -
2085
No Not Used
front_print_speed 2086 Yes Speed measured during the last
front print stroke.
F8 2-300 mm/s
rear_print_speed 2087 Yes Speed measured during the last
rear print stroke.
F8 2-300 mm/s
Modified Parameters 2088 No This variable contains the
parameter ID, name, old value and
new value for the parameters
whose value changed at
instrument.
Modified
Parameter
List
See <Modified Parameter
List>
PrintDeposits 2090 No This variable contains the number
of print deposits during a print
cycle.
U1 1-10
PrintSpeedDeposit1 to
PrintSpeedDeposit10
2091 to
2100
No These variables contain the print
stroke speeds for their
corresponding print deposit during
a print cycle.
F8 2-300 mm/s
GEM Manual for DEK Printers Equipment Variables
Issue 1.6 January 22, 2018 Page 116 of 171
CleanRate1 2151 No This variable contains the 1st rate
at which a clean takes place during
a print cycle.
U4 0-200
CleanRate2 2152 No This variable contains the 2nd rate
at which a clean takes place during
a print cycle.
U4 0-200
LastCleanType 2153 No This variable contains the last
clean type that took place.
A32 Up to a 32 character string
representing the clean type.
Cyclone Duo Clean Rate
1
2154 No This variable contains the 1st rate
at which a clean takes place during
a print cycle with a Cyclone Duo
cleaner
U4 0-200
Cyclone Duo Clean Rate
2
2155 No This variable contains the 2nd rate
at which a clean takes place during
a print cycle with a Cyclone Duo
cleaner.
U4 0-200
