GEM Manual for DEK Printers Equipment Variables
Issue 1.6 January 22, 2018 Page 120 of 171
Process
Parameters
Front Pressure The front squeegee / Proflow process defined pressure value (not actual – SPC Data
contains actual)
Rear Pressure The rear squeegee process defined pressure value (not actual – SPC data contains
actual).
Front Print Speed The process defined front print speed (i.e. the rate the front squeegee moves when
performing the print stroke). The SPC data contains the actual value.
Rear Print Speed The process defined rear print speed (i.e. the rate the rear squeegee moves when
performing the print stroke). The SPC data contains the actual value.
Print Front Limit The maximum limit the front print stroke can be started from
Print Rear Limit The maximum limit the rear print stroke can be started from
Forward X Offset The offset applied in X to the screen when performing the forward print stroke
Reverse X Offset The offset applied in X to the screen when performing the rear print stroke
Forward Y Offset The offset in Y applied to the screen during the front print stroke
Reverse Y Offset The offset in Y applied to the screen during the rear print stroke
Reverse Theta Offset The angle at which the screen is positioned for the reverse print stroke
Forward Theta Offset The angle at which the screen is positioned for the forward print stroke
Separation Speed The rate at which the board is separated from the screen/stencil.
Separation Distance The distance the separation speed applies to before separating normally.
Print Gap The gap left between the board and stencil/screen when printing.
Clean Rate 1 /
Cyclone Clean Rate /
Blue Clean Rate
The number of print cycles that the clean 1, cyclone or blue cleaner operation occurs.
Clean Rate 2 The number of print cycles that the clean 2 operation occurs.
Vortex Clean Rate The number of print cycles that the Vortex clean operation occurs.
Paste While Clean Indicates if a dispense operation is performed when a clean operation occurs.
Paste Dispense Rate The number of prints that occur before the paste dispenser performs a dispense
operation.
Alternative Dispense
Rate
The number of prints that occur before the alternative dispense operation is
performed.
Proflow System
Pressure
The pressure that was applied to the Proflow unit when printing
Ball Place App Speed The rate at which the ball placement applicator moves
Ball Place App Dist The distance the ball placement applicator moves
Ball Place Tbl Dwn
Speed
The rate at which the table moves down when using ball placement
Ball Place Hopper
Pressure
The pressure applied to the ball placement hopper
GEM Manual for DEK Printers Equipment Variables
Issue 1.6 January 22, 2018 Page 121 of 171
SPC X Pre Align Dev Deviation in the x axis for the pre print alignment
Y Pre Align Dev Deviation in the y axis for the pre print alignment
Theta Pre Align Dev Deviation in the theta angle for the pre print alignment
Board Stretch The board length.
Pre Board Stretch Deviation in the pre print board length stretch
Pre Fid 1 X Align
Dev
Pre fiducial 1 deviation in the x alignment
Pre Fid 1 Y Align
Dev
Pre fiducial 1 deviation in the y alignment
Pre Fid 2 X Align
Dev
Pre fiducial 2 deviation in the x alignment
Pre Fid 2 Y Align
Dev
Pre fiducial 2 deviation in the y alignment
Pre Fid 3 X Align
Dev
Pre fiducial 3 deviation in the x alignment
Pre Fid 3 Y Align
Dev
Pre fiducial 3 deviation in the y alignment
X Align Dev Deviation in the X axis alignment
Y Align Dev Deviation in the Y axis alignment
Theta Align Dev Deviation in the theta alignment
Board 1 Fid Score The score of the first defined fiducial on the board.
Screen 1 Fid Score The score of the first defined fiducial on the screen.
Board 2 Fid Score The score of the second defined fiducial on the board.
Screen 2 Fid Score The score of the second defined fiducial on the screen.
Board 3 Fid Score The score of the third defined fiducial on the board.
Screen 3 Fid Score The score of the third defined fiducial on the screen.
Front X Act Rel
Move
Front X actuator relative movement
Rear X Act Rel Move Rear X actuator relative movement
Act Y Rel Move Y Actuator relative movement
Actual Front Pressure The measured front squeegee / Proflow pressure.
Actual Rear Pressure The measured rear squeegee pressure.
Actual Separation
Speed
The measured separation speed when performing the print operation.
Actual Temperature The measured internal temperature
Actual Humidity The measured relative humidity
Cycle Time The number of seconds taken to perform the print operation.
Table Position The height of the table when at print position.
Post Fid 1 X Align
Dev
Post fiducial 1 deviation in the x alignment
Post Fid 1 Y Align
Dev
Post fiducial 1 deviation in the x alignment
Post Fid 2 X Align
Dev
Post fiducial 2 deviation in the x alignment
Post Fid 2 Y Align
Dev
Post fiducial 2 deviation in the y alignment
Post Fid 3 X Align
Dev
Post fiducial 3 deviation in the x alignment
Post Fid 3 Y Align
Dev
Post fiducial 3 deviation in the y alignment
Front X Act Pos Front X actuator absolute position
Rear X Act Pos Rear X actuator absolute position
Act Y Pos Y actuator absolute position
GEM Manual for DEK Printers Equipment Variables
Issue 1.6 January 22, 2018 Page 122 of 171
Actual Front Print
Speed
The measured print speed variation for the front squeegee.
Actual Rear Print
Speed
The measured print speed variation for the rear squeegee.
Hawkeye Area Error The number of Hawkeye sites in error
Hawkeye Area
Warning
The number of Hawkeye sites in warning
Hawkeye Feat Error The number of Hawkeye features in error
Hawkeye Feat
Warning
The number of Hawkeye features in warning
Verification
Data
Product Index The name of the verification index that passed the product identifier validation
Screen ID The value of the identifier (barcode) that is currently being used for the stencil or
screen.
Stencil Screen Index The name of the verification index that passed the screen or stencil identifier
validation
Print Medium ID The value of the identifier (barcode) that is currently being used for the print medium
(manual paste etc..)
Print Medium Index The name of the verification index that passed the Print Medium identifier validation
Print Medium
Cartridge ID
The value of the identifier (barcode) that is currently being used for the print medium
cartridge (paste dispenser etc..)
Print Medium
Cartridge Index
The name of the verification index that passed the Print Medium Cartridge identifier
validation
Tooling ID The value of the identifier (barcode) that is currently being used for the tooling
(magnetic, custom etc..)
Tooling Index The name of the verification index that passed the Tooling identifier validation
Vortex Cassette ID The value of the identifier (barcode) that is being used for the vortex cassette.
Vortex Cassette
Index
The name of the verification index that passed the Vortex Cassette identifier
validation
Cleaner Solvent ID The value of the identifier (barcode) that is currently being used for the cleaner
solvent.
Cleaner Solvent
Index
The name of the verification index that passed the Cleaner Solvent identifier
validation
Cleaner Paper ID The value of the identifier (barcode) that is currently being used for the cleaner paper.
Cleaner Paper Index The name of the verification index that passed the Cleaner Paper identifier validation
Front Squeegee
Holders ID
The value of the identifier (barcode) that is currently being used for the front
squeegee holders.
Front Squeegee
Holders Index
The name of the verification index that passed the Front Squeegee Holders identifier
validation
Rear Squeegee
Holders ID
The value of the identifier (barcode) that is currently being used for the rear squeegee
holders.
Rear Squeegee
Holders Index
The name of the verification index that passed the Rear Squeegee Holders identifier
validation
Front Squeegee
Blades ID
The value of the identifier (barcode) that is currently being used for the front
squeegee blades.
Front Squeegee
Blades Index
The name of the verification index that passed the Front Squeegee Blades identifier
validation
Rear Squeegee
Blades ID
The value of the identifier (barcode) that is currently being used for the rear squeegee
blades.
Rear Squeegee
Blades Index
The name of the verification index that passed the Rear Squeegee Blades identifier
validation
Proflow Cassette ID The value of the identifier (barcode) that is currently being used for the Proflow
cassette.
Proflow Cassette
Index
The name of the verification index that passed the Proflow Cassette identifier
validation
Proflow Head ID The value of the identifier (barcode) that is currently being used for the Proflow head.
Proflow Head Index The name of the verification index that passed the Proflow Head identifier validation
