GEM Manual for DEK Printers Equipment Variables
Issue 1.6 January 22, 2018 Page 122 of 171
Actual Front Print
Speed
The measured print speed variation for the front squeegee.
Actual Rear Print
Speed
The measured print speed variation for the rear squeegee.
Hawkeye Area Error The number of Hawkeye sites in error
Hawkeye Area
Warning
The number of Hawkeye sites in warning
Hawkeye Feat Error The number of Hawkeye features in error
Hawkeye Feat
Warning
The number of Hawkeye features in warning
Verification
Data
Product Index The name of the verification index that passed the product identifier validation
Screen ID The value of the identifier (barcode) that is currently being used for the stencil or
screen.
Stencil Screen Index The name of the verification index that passed the screen or stencil identifier
validation
Print Medium ID The value of the identifier (barcode) that is currently being used for the print medium
(manual paste etc..)
Print Medium Index The name of the verification index that passed the Print Medium identifier validation
Print Medium
Cartridge ID
The value of the identifier (barcode) that is currently being used for the print medium
cartridge (paste dispenser etc..)
Print Medium
Cartridge Index
The name of the verification index that passed the Print Medium Cartridge identifier
validation
Tooling ID The value of the identifier (barcode) that is currently being used for the tooling
(magnetic, custom etc..)
Tooling Index The name of the verification index that passed the Tooling identifier validation
Vortex Cassette ID The value of the identifier (barcode) that is being used for the vortex cassette.
Vortex Cassette
Index
The name of the verification index that passed the Vortex Cassette identifier
validation
Cleaner Solvent ID The value of the identifier (barcode) that is currently being used for the cleaner
solvent.
Cleaner Solvent
Index
The name of the verification index that passed the Cleaner Solvent identifier
validation
Cleaner Paper ID The value of the identifier (barcode) that is currently being used for the cleaner paper.
Cleaner Paper Index The name of the verification index that passed the Cleaner Paper identifier validation
Front Squeegee
Holders ID
The value of the identifier (barcode) that is currently being used for the front
squeegee holders.
Front Squeegee
Holders Index
The name of the verification index that passed the Front Squeegee Holders identifier
validation
Rear Squeegee
Holders ID
The value of the identifier (barcode) that is currently being used for the rear squeegee
holders.
Rear Squeegee
Holders Index
The name of the verification index that passed the Rear Squeegee Holders identifier
validation
Front Squeegee
Blades ID
The value of the identifier (barcode) that is currently being used for the front
squeegee blades.
Front Squeegee
Blades Index
The name of the verification index that passed the Front Squeegee Blades identifier
validation
Rear Squeegee
Blades ID
The value of the identifier (barcode) that is currently being used for the rear squeegee
blades.
Rear Squeegee
Blades Index
The name of the verification index that passed the Rear Squeegee Blades identifier
validation
Proflow Cassette ID The value of the identifier (barcode) that is currently being used for the Proflow
cassette.
Proflow Cassette
Index
The name of the verification index that passed the Proflow Cassette identifier
validation
Proflow Head ID The value of the identifier (barcode) that is currently being used for the Proflow head.
Proflow Head Index The name of the verification index that passed the Proflow Head identifier validation
GEM Manual for DEK Printers Equipment Variables
Issue 1.6 January 22, 2018 Page 123 of 171
6.4.4 Failed Verification Items Data
The traceability data is a list of items structured as follows:
Structure: L, m ; m = number of failed items
1. L,1
1. Item name ; Type A
The list of possible items is the same as for Traceability Data, category Verification Data
.
6.5 Variables for Limits Monitoring
Name SVID
DVID CEID LIMITMIN LIMITMAX Type
Humidity 1008 31008 0 % 100 F4
Temperature 1016 31016 0 100 F4
batch_count 1020 31020 0 99999 U4
measured_cycle_time 2004 32004 0 3200000 F8
throughput_cycle_time 2005 32005 0 3200000 F8
front_print_pressure 2008 32008 0 20 F8
rear_print_pressure 2009 32009 0 20 F8
print_speed 2010 32010 2 300 F8
table_separation_speed 2011 32011 0.1 20 F8
board_stretch_error 2012 32012 -5.0 mm 5.0 mm F8
Xerr 2013 32013 -5.0 mm 5.0 mm F8
Yerr 2014 32014 -5.0 mm 5.0 mm F8
theta_err 2015 32015 -1000 sec +1000 sec F8
board_fiducial_1_score 2021 32021 0 1000 U4
board_fiducial_2_score 2022 32022 0 1000 U4
board_fiducial_3_score 2023 32023 0 1000 U4
screen_fiducial_1_score 2024 32024 0 1000 U4
screen_fiducial_2_score 2025 32025 0 1000 U4
screen_fiducial_3_score 2026 32026 0 1000 U4
ProflowPastePressure 2031 32031 0 20 F8
GEM Manual for DEK Printers Equipment Variables
Issue 1.6 January 22, 2018 Page 124 of 171
6.6 Process Attributes
Name OBJID
SOFTWARE VERSION 1
PRODUCT BARCODE 2
SCREEN BARCODE 3
SCREEN ADAPTOR 4
SCREEN IMAGE 5
BOARD WIDTH 10
BOARD LENGTH 11
BOARD THICKNESS 12
FRONT PRINT SPEED 13
FLOOD SPEED 14
FLOOD HEIGHT 15
FRONT PRESSURE 16
REAR PRESSURE 17
PRINT GAP 18
SEPARATION SPEED 19
PRINT MODE 20
PRINT DEPOSITS 21
ALTERNATE DISP 27
ALTERNATE DISP RATE 28
PASTE DISPENSE RATE 30
PASTE DISPENSE SPEED 31
PASTE START 32
PASTE STOP 33
PASTE KNEAD PERIOD 34
KNEAD DEPOSITS 35
KNEAD BOARDS 36
CLEAN AFTER KNEAD 37
BOARD COUNT 38
PASTE WHILE CLEAN 39
SCREEN CLEAN RATE 1 40
SCREEN CLEAN MODE 1 41
SCREEN CLEAN RATE 2 42
SCREEN CLEAN MODE 2 43
KNEAD AFTER DISPENSE 45
STOP AFTER IDLE 46
ALIGNMENT MODE 50
FIDUCIAL 1 X 51
FIDUCIAL 1 Y 52
FIDUCIAL 2 X 53
FIDUCIAL 2 Y 54
FIDUCIAL 3 X 55
FIDUCIAL 3 Y 56
