GEM Manual for DEK Printers Equipment Variables
Issue 1.6 January 22, 2018 Page 123 of 171
6.4.4 Failed Verification Items Data
The traceability data is a list of items structured as follows:
Structure: L, m ; m = number of failed items
1. L,1
1. Item name ; Type A
The list of possible items is the same as for Traceability Data, category Verification Data
.
6.5 Variables for Limits Monitoring
Name SVID
DVID CEID LIMITMIN LIMITMAX Type
Humidity 1008 31008 0 % 100 F4
Temperature 1016 31016 0 100 F4
batch_count 1020 31020 0 99999 U4
measured_cycle_time 2004 32004 0 3200000 F8
throughput_cycle_time 2005 32005 0 3200000 F8
front_print_pressure 2008 32008 0 20 F8
rear_print_pressure 2009 32009 0 20 F8
print_speed 2010 32010 2 300 F8
table_separation_speed 2011 32011 0.1 20 F8
board_stretch_error 2012 32012 -5.0 mm 5.0 mm F8
Xerr 2013 32013 -5.0 mm 5.0 mm F8
Yerr 2014 32014 -5.0 mm 5.0 mm F8
theta_err 2015 32015 -1000 sec +1000 sec F8
board_fiducial_1_score 2021 32021 0 1000 U4
board_fiducial_2_score 2022 32022 0 1000 U4
board_fiducial_3_score 2023 32023 0 1000 U4
screen_fiducial_1_score 2024 32024 0 1000 U4
screen_fiducial_2_score 2025 32025 0 1000 U4
screen_fiducial_3_score 2026 32026 0 1000 U4
ProflowPastePressure 2031 32031 0 20 F8
GEM Manual for DEK Printers Equipment Variables
Issue 1.6 January 22, 2018 Page 124 of 171
6.6 Process Attributes
Name OBJID
SOFTWARE VERSION 1
PRODUCT BARCODE 2
SCREEN BARCODE 3
SCREEN ADAPTOR 4
SCREEN IMAGE 5
BOARD WIDTH 10
BOARD LENGTH 11
BOARD THICKNESS 12
FRONT PRINT SPEED 13
FLOOD SPEED 14
FLOOD HEIGHT 15
FRONT PRESSURE 16
REAR PRESSURE 17
PRINT GAP 18
SEPARATION SPEED 19
PRINT MODE 20
PRINT DEPOSITS 21
ALTERNATE DISP 27
ALTERNATE DISP RATE 28
PASTE DISPENSE RATE 30
PASTE DISPENSE SPEED 31
PASTE START 32
PASTE STOP 33
PASTE KNEAD PERIOD 34
KNEAD DEPOSITS 35
KNEAD BOARDS 36
CLEAN AFTER KNEAD 37
BOARD COUNT 38
PASTE WHILE CLEAN 39
SCREEN CLEAN RATE 1 40
SCREEN CLEAN MODE 1 41
SCREEN CLEAN RATE 2 42
SCREEN CLEAN MODE 2 43
KNEAD AFTER DISPENSE 45
STOP AFTER IDLE 46
ALIGNMENT MODE 50
FIDUCIAL 1 X 51
FIDUCIAL 1 Y 52
FIDUCIAL 2 X 53
FIDUCIAL 2 Y 54
FIDUCIAL 3 X 55
FIDUCIAL 3 Y 56
GEM Manual for DEK Printers Equipment Variables
Issue 1.6 January 22, 2018 Page 125 of 171
FORWARD X OFFSET 57
FORWARD Y OFFSET 58
FORWARD THETA OFFSET 59
REVERSE X OFFSET 60
REVERSE Y OFFSET 61
REVERSE THETA OFFSET 62
ALIGNMENT WEIGHTING 66
X ALIGN WEIGHTING 67
Y ALIGN WEIGHTING 68
BOARD STOP X 70
BOARD STOP Y 71
UNDER CLEARANCE 72
PRINT FRONT LIMIT 73
PRINT REAR LIMIT 74
TOOLING TYPE 80
DRY CLEAN SPEED 83
WET CLEAN SPEED 84
VAC CLEAN SPEED 85
FRONT START OFFSET 86
REAR START OFFSET 87
SEPARATION DELAY 89
PRINT AREA WIDTH 100
PASTE WITH BOARD 104
PRINT AREA LENGTH 105
DIST TO IMAGE 110
PRINT PASTE PRESSURE 115
IDLE PASTE PRESSURE 116
CUSTOM SCREEN 120
PASTE RIDGE REMOVAL 185
SEPARATE VAC DELAY 187
FLATTEN VAC DELAY 188
SCREEN TYPE 190
REAR PRINT SPEED 199
VORTEX SOLVENT RATE 223
VACUUM ON PERIOD 224
VORTEX VACUUM RATE 225
VORTEX VAC START 226
VORTEX VAC STOP 227
VORTEX CLEAN RATE 228
VORTEX CASSETTE LIFE 229
FRONT KNEAD PRESSURE 245
REAR KNEAD PRESSURE 246
FRONT KNEAD SPEED 247
REAR KNEAD SPEED 248
SELECT MARK TYPE 252
SELCT MARK WIDTH 253
SELECT MARK HEIGHT 254
