SECS GEM Manual - 第125页

GEM Manual for DEK Printers Equipment Variables Issue 1.6 January 22, 2018 Page 125 of 171 FORW ARD X OFFSET 57 FORW ARD Y OFFSET 58 FORW ARD THETA OFFSET 59 REVERSE X OFFS ET 60 REVERSE Y OFFS ET 61 REVERSE THET A OFFSE…

GEM Manual for DEK Printers Equipment Variables

Issue 1.6 January 22, 2018 Page 124 of 171

6.6 Process Attributes

Name OBJID

SOFTWARE VERSION 1

PRODUCT BARCODE 2

SCREEN BARCODE 3

SCREEN ADAPTOR 4

SCREEN IMAGE 5

BOARD WIDTH 10

BOARD LENGTH 11

BOARD THICKNESS 12

FRONT PRINT SPEED 13

FLOOD SPEED 14

FLOOD HEIGHT 15

FRONT PRESSURE 16

REAR PRESSURE 17

PRINT GAP 18

SEPARATION SPEED 19

PRINT MODE 20

PRINT DEPOSITS 21

ALTERNATE DISP 27

ALTERNATE DISP RATE 28

PASTE DISPENSE RATE 30

PASTE DISPENSE SPEED 31

PASTE START 32

PASTE STOP 33

PASTE KNEAD PERIOD 34

KNEAD DEPOSITS 35

KNEAD BOARDS 36

CLEAN AFTER KNEAD 37

BOARD COUNT 38

PASTE WHILE CLEAN 39

SCREEN CLEAN RATE 1 40

SCREEN CLEAN MODE 1 41

SCREEN CLEAN RATE 2 42

SCREEN CLEAN MODE 2 43

KNEAD AFTER DISPENSE 45

STOP AFTER IDLE 46

ALIGNMENT MODE 50

FIDUCIAL 1 X 51

FIDUCIAL 1 Y 52

FIDUCIAL 2 X 53

FIDUCIAL 2 Y 54

FIDUCIAL 3 X 55

FIDUCIAL 3 Y 56

GEM Manual for DEK Printers Equipment Variables

Issue 1.6 January 22, 2018 Page 125 of 171

FORWARD X OFFSET 57

FORWARD Y OFFSET 58

FORWARD THETA OFFSET 59

REVERSE X OFFSET 60

REVERSE Y OFFSET 61

REVERSE THETA OFFSET 62

ALIGNMENT WEIGHTING 66

X ALIGN WEIGHTING 67

Y ALIGN WEIGHTING 68

BOARD STOP X 70

BOARD STOP Y 71

UNDER CLEARANCE 72

PRINT FRONT LIMIT 73

PRINT REAR LIMIT 74

TOOLING TYPE 80

DRY CLEAN SPEED 83

WET CLEAN SPEED 84

VAC CLEAN SPEED 85

FRONT START OFFSET 86

REAR START OFFSET 87

SEPARATION DELAY 89

PRINT AREA WIDTH 100

PASTE WITH BOARD 104

PRINT AREA LENGTH 105

DIST TO IMAGE 110

PRINT PASTE PRESSURE 115

IDLE PASTE PRESSURE 116

CUSTOM SCREEN 120

PASTE RIDGE REMOVAL 185

SEPARATE VAC DELAY 187

FLATTEN VAC DELAY 188

SCREEN TYPE 190

REAR PRINT SPEED 199

VORTEX SOLVENT RATE 223

VACUUM ON PERIOD 224

VORTEX VACUUM RATE 225

VORTEX VAC START 226

VORTEX VAC STOP 227

VORTEX CLEAN RATE 228

VORTEX CASSETTE LIFE 229

FRONT KNEAD PRESSURE 245

REAR KNEAD PRESSURE 246

FRONT KNEAD SPEED 247

REAR KNEAD SPEED 248

SELECT MARK TYPE 252

SELCT MARK WIDTH 253

SELECT MARK HEIGHT 254

GEM Manual for DEK Printers Equipment Variables

Issue 1.6 January 22, 2018 Page 126 of 171

SELECT MARK INNER CONTOUR 255

SELECT MARK OUTER CONTOUR 256

SELECT MARK ROUNDING 257

SELECT MARK ROTATION 258

SELECT MARK LEG WIDTH 259

SELECT MARK ACCEPT SCORE 260

SELECT MARK POLARITY 262

SELECT MARK X 267

SELECT MARK Y 268

FRONT PASTE RECOVERY 273

REAR PASTE RECOVERY 274

PASTE RECOVERY RATE 275

KNEAD BEFORE PRINT 276

KNEAD OFF 277

STENCIL PROTECTION 278

SYSTEM PRESSURE 280

TOOLING DEVIATION 284

SINGULATION 342

PALLET THICKNESS 346

FIRST PART TO EDGE 348

PITCH OF PARTS 349

PALLET WIDTH 350

PALLET LENGTH 351

NUMBER OF PARTS 352

VAC CLEAN START TIME 387

VIDEO MODEL TYPE BOARD FID 1 391

VIDEO MODEL TYPE BOARD FID 2 392

VIDEO MODEL TYPE BOARD FID 3 393

VIDEO MODEL TYPE SCREEN FID 1 394

VIDEO MODEL TYPE SCREEN FID 2 395

VIDEO MODEL TYPE SCREEN FID 3 396

VIDEO MODEL TYPE SELECT MARK 397

BOARD AT STOP RUN ON 399

KNEAD PASTE PRESSURE 428

KNEAD AFTER REPLENISH 429

CLEAN AFTER KNEAD 430

RWD END PRESSURE 431

RWD START PRESSURE 432

FWD END PRESSURE 433

FWD START PRESSURE 434

RWD END SPEED 435

RWD START SPEED 436

FWD END SPEED 437

FWD START SPEED 438

VACUUM SENSOR DELAY 451
