GEM Manual for DEK Printers Machine GEM Compliance
Issue 1.6 January 22, 2018 Page 12 of 171
3.9 Alarm Events (CEIDs)
Name CEID
Cover opened 31253
Cover closed 31254
Head left partly open 31314
Head moved to safe state 31315
3.10 Spooling Events (CEIDs)
Name CEID
Spooling activated 31453
Spooling deactivated 31454
Spool transmission failure 31455
GEM Manual for DEK Printers Machine GEM Compliance
Issue 1.6 January 22, 2018 Page 13 of 171
3.11 Equipment error events (CEIDs)
Name CEID Name CEID
System power down 10003
Lid bolt fault 31232
Pneumatic power down 31201
Alignment out of range 31233
Front squeegee error 31202
Comms error 31417
Rear squeegee error 31203
Barcode read failure 31303
Rising table error 31204
Barcode mismatch 31304
Print carriage error 31205
Screen couplings failed 31305
Paste carriage error 31206
Motion control timeout 31306
Camera X axis error 31207
Camera X failed to position 31307
Camera Y axis error 31208
Camera Y failed to position 31308
Rail width error 31209
Stencil aperture blocked 31309
Screen XF error 31210
Stencil smeared 31310
Screen XR error 31211
Paste on pad inspection error 31311
Screen Y error 31212
Bridging detected by
inspection system
31312
Paste cartridge tilt error 31213
Alignment error detected by
inspection system
31313
Screen changer drive error 31214
Event log disk file full 31321
Board stop stuck 31215
Proflow error 31322
Board clamp stuck 31216
CAN node down 31340
Board stuck in rails 31217
CAN node recovered 31341
Unable to find fiducial 31218
CAN bus down 31342
Rail lifted error 31219
CAN bus recovered 31433
Print pressure error 31220
Volume alarm 31460
File error 31221
Dongle error 40006
Unable to recover 31222
Cleaner detached from
camera
40146
Recovery started 31223
Recovered cleaner detached
from camera
40147
Recovered 31224
Ball escape detected 40150
Upline transfer error 31225
Verification item failed 40152
Downline transfer error 31226
Product ID verification failed
40157
Dual shuttle fault 31227
Advanced Adjust Entered 40300
Screen changer fault 31230
Cleaner Vacuum Sense Error 40320
GEM Manual for DEK Printers Machine GEM Compliance
Issue 1.6 January 22, 2018 Page 14 of 171
3.12 Equipment Specific Information Events (CEIDs)
Name CEID Name CEID
System power on 10002 New event log 31297
Line power on 31251 No cleaner paper 31301
Printer ready 31255 No cleaner solvent 31302
Head raised 31256 Inspection cycle complete 31316
Head closed 31257 Clock change request 31317
Cycle aborted 31260 Clock changed 31318
Cycle completed 31261 Remote barcode received 31457
Cleaning screen 31262 Evaluation dongle detected 40004
Parameter adjusted 31263 Valid dongle detected 40005
Setup started 31264 Dongle changed 40007
Setup ended 31272 Front print speed 40008
Start print cycle 31273 Rear print speed 40009
End print cycle 31275 ProFlow cassette low 40055
Board printed 31277 Configuration Parameter modified
31345
Operator log on 31278 Adjust Parameter modified 31347
Operator log off 31279 Fiducial setup entered 40126
Clear batch count 31280 Fiducial setup ended 40127
Start maintenance 31281 Diagnostics ended 40128
End maintenance 31282 Adjust entered 40129
Pressure re-calibrated 31283 Adjust ended 40130
Offset recalibrated 31284 Adjust while running entered 40131
X,Y scale recalibrated 31285 Adjust while running ended 40132
Theta recalibrated 31286 Item verification succeeded 40151
Configuration change 31287 Verification value reset 40153
Start diagnostics 31288 Verification value restored 40154
End diagnostics 31289 Batch/lot ID changed 40155
Camera reference reset 31291 Product ID verification succeeded
40156
Vision height reset 31293 Traceability data available 40177
Print height reset 31294 Fiducial Alignment Started 40191
Software updated 31296 Fiducial Alignment Complete 40192
Fiducial Alignment SW Fallback 40374
