GEM Manual for DEK Printers Equipment Variables Issue 1.6 January 22, 2018 Page 136 of 171 PASTE CHECK ST ART OFFSET 20OZ 3095 PASTE CHECK ST ART OFFSET 3129 TRANSPORT MODE 5000 MACHINE UNIT S 5001 UPLINE PROT OCOL 5010 …
GEM Manual for DEK Printers Equipment Variables
Issue 1.6 January 22, 2018 Page 135 of 171
PASS THR BOARD WIDTH 1071
STINGER OFFSET X 1098
STINGER OFFSET Y 1099
STINGER HARDWARE 1100
PASS THR WIDTH CALIB 1105
GERBER DIRECTORY 1114
LASER CORRECTION 1147
SMA LEVEL MON 1150
VERIFICATION 1166
TRACEABILITY 1167
TRACEABILITY DRIVE 1168
TRACEABILITY NETWORK OUTPUT 1179
USC VAC SENSE 1180
STINGER LASER OFFSET X 1188
STINGER LASER OFFSET Y 1189
CUSTOM ADJUST PAGE 1195
LH SENSE EDGE OFFSET 1218
RH SENSE EDGE OFFSET 1219
AUTO CLEAN COUNT RESET 1244
DECEL OFFSET WINDOW 1251
LEVEL SETTING HEIGHT 1253
SETTING PLATE DEPTH 1254
LAST COPLANARITY HEIGHT 1255
HOME OFFSET 1256
E.E.LOGGING 1264
EVENT LOG HISTORY LIMIT 1287
UPDATE NETFILES 1291
BARCODEDUPLICATEHANDLING 1296
BARCODE INPUT BUFFER LIMIT 1301
PURGE STATION LOCATION 1303
TEMPERATURE OFFSET 1304
PURGEPOT RIGHT X 1313
PURGEPOT RIGHT Y 1314
PURGEPOT LEFT X 1315
PURGEPOT LEFT Y 1316
PURGE CYCLE COUNT 1320
PURGEPOT CAPACITY 1321
DOUBLE ALIGN MODE 1342
LONG MOVE THRESHOLD 1343
HAWKEYE BIRDGING 3016
LOCAL PARAMETERS 3031
PRODUCTIVITY COUNTERS 3033
EXTENDED DUAL LANE RAIL WIDTH 3041
FRONT STROKES 3067
REAR STROKES 3068
SQUEEGEE SPACING 3087
GEM Manual for DEK Printers Equipment Variables
Issue 1.6 January 22, 2018 Page 136 of 171
PASTE CHECK START OFFSET 20OZ 3095
PASTE CHECK START OFFSET 3129
TRANSPORT MODE 5000
MACHINE UNITS 5001
UPLINE PROTOCOL 5010
DOWNLINE PROTOCOL 5011
TRANSPORT WAIT MODE 5013
COMMS PROTOCOL 5020
EVENT RECORDING 5030
EVENT RECORDING 5035
TRANSFER PERIOD 5040
TOOLING HARDWARE 5050
CLAMP TYPE 5051
SNUGGER THICKNESS 5052
PRODUCT BARCODE H/W 5060
REMOTE BARCODE H/W 5065
NON VISION 5070
VISION OFFSET 5080
SCREEN SIZE 5090
SCREEN BARCODE H/W 5100
CHANGE MODE OPTION 5110
FIDUCIAL REFERENCE 5120
BAUD RATE 5133
PARITY 5134
WORD LENGTH : 5135
STOP BITS 5136
START CHARACTER 5140
NAME LENGTH 5150
START CHARACTER 5160
START CHARACTER 5165
NAME LENGTH 5170
NAME LENGTH 5175
BAUD RATE 5180
WORD LENGTH 5181
PARITY 5182
STOP BITS 5183
USER ID 5191
AUTO LOGIN 5194
LOCAL COPIES 5195
RECONNECT PERIOD 5196
TIMEOUT 5197
CLEANER HARDWARE 5201
PASTE DISPENSER 5202
PFLOW CONTACT POS. 5232
PFLOW DSTOP POS. 5233
DISPLAY TYPE 5300
FIDUCIAL MONITORING 5400
SCORE WARNING LEVEL 5401
GEM Manual for DEK Printers Equipment Variables
Issue 1.6 January 22, 2018 Page 137 of 171
VAR'N WARNING LEVEL 5402
AUTOMATIC RETRY 5403
BOARD STOP X OFFSET 6460
REMOTE BOARD STOP 6461
FIDUCIAL SEARCH 6465
AUTOSEARCH 6466
WINDOW SIZE 6467
CLEANER TYPE 6470
SPOOL BEFORE 1ST WET 6475
SOLVENT DISPENSE DURATION 6480
WET OVER BLADE 6490
DRY AFTER ONE WET 6500
DRY AFTER TWO WET 6510
WET AFTER WET 6520
DRY AFTER DRY 6530
CONSUMABLE ACTION 6535
KNEAD AFTER DISPENSE 6560
PASTE TRAILS 6570
DWELL HEIGHT 6581
DWELL SPEED 6582
IMAGE RECORDING 12069
VIDEO GAIN 13015
VIDEO OFFSET 13016
SCREEN LENGTH 14001
SCREEN WIDTH 14002
FRAME_FRONT 14003
FRAME REAR 14004
FRAME LEFT 14005
FRAME RIGHT 14006
2D INSPECTION 20017
MACHINE LOCATION 25000
PLACEMENT CONTACT 30013
PREPARATION HEIGHT 30015
HOPPER OPEN DELAY 30016
HOPPER CLOSE DELAY 30017
