GEM Manual for DEK Printers Alarms
Issue 1.6 January 22, 2018 Page 140 of 171
7.4 Board Transport Alarms
ALID
ALTX Comments Associated
CEID
51 Board stop stuck 31215
52 Board clamp stuck 31216
53 Board stuck in rails 31217
54 Upline transfer error 31225
55 Downline transfer error 31226
7.5 Process Alarms
ALID ALTX Comments Associated
CEID
71 Rail lifted error 31219
72 Alignment out of range 31233
73 Stencil aperture blocked 31309
74 Stencil smeared 31310
75 Insufficient paste on pad 31311
76 Bridging detected 31312
77 Paste/pad alignment error 31313
78 Paste volume alarm 31460
79 Knead pressure error (front) 40043
80 Knead pressure error (rear) 40044
81 Print pressure error (front) 40045
82 Print pressure error (rear) 40046
83 Board fiducial 1 not found 40048
84 Board fiducial 2 not found 40049
85 Board fiducial 3 not found 40050
86 Screen fiducial 1 not found 40051
87 Screen fiducial 2 not found 40052
88 Screen fiducial 3 not found 40053
89 Select mark not found 40054
90 Bad vacuum tooling 40056
92 Item not verified 40152
93 Product not verified 40157
7.6 Consumable Alarms
ALID
ALTX Comments Associated
CEID
101 No cleaner paper 31301
40071
102 No cleaner solvent 31302
103 Vortex cassette expired 40042
40024
104 Paste cartridge empty 31259
GEM Manual for DEK Printers Event Messages
Issue 1.6 January 22, 2018 Page 141 of 171
8 Event Messages
CONTROL MODEL 9.1
PROCESS MODEL 9.2
PROCESS PROGRAM MANAGEMENT 9.3
EQUIPMENT CONSTANT 9.4
ACKNOWLEDGE TERMINAL MESSAGE 9.5
ALARMS 9.6
SPOOLING 9.7
EQUIPMENT ERROR 9.8
EQUIPMENT SPECIFIC INFORMATION 9.9
MATERIAL MOVEMENT 9.10
HOST SPECIFIC INFORMATION 9.11
LIMITS MONITORING 9.12
SUGGESTED EVENT REPORTS 9.13
SIMULTANEOUS EVENTS (TIME) 9.14
MODIFIED PARAMETERS 9.15
GEM Manual for DEK Printers Event Messages
Issue 1.6 January 22, 2018 Page 142 of 171
8.1 Control Model Events
EVENT - CEID
DESCRIPTION
31450 Control State – Change to LOCAL.
31451 Control State – Change to OFF-LINE.
31452 Control State – Change to REMOTE.
31456 Operator command issued.
31550 GEM connected.
31551 GEM disconnected.
8.2 Process Model Events
EVENT - CEID
DESCRIPTION
90001 Equipment moved to Recovery state.
90002 Equipment moved to Setup state.
90003 Equipment moved to Ready state.
90004 Equipment moved to Maintenance state.
90005 Equipment moved to Waiting state.
90006 Equipment moved to Running state.
90007 Equipment moved to Down state.
8.3 Process Program Management Events
EVENT - CEID
DESCRIPTION
31265 Process program loaded.
31266 New process program created and loaded.
31267 Process program change.
31346 Product Data modified (with change details – see section 9.15).
32035 Operator deleted process program.
40416 Z-Lock Not Fitted Warning.
40417 Local Parameters changed to.
40418 Local parameters not loaded.
40419 Local Parameters not applied for print.
40420 Local Parameters not reinstated after print.
40421 Local Parameters not saved.
8.4 Equipment Constant Change Event
EVENT - CEID
DESCRIPTION
31440 Equipment constant change.
