GEM Manual for DEK Printers Event Messages
Issue 1.6 January 22, 2018 Page 141 of 171
8 Event Messages
CONTROL MODEL 9.1
PROCESS MODEL 9.2
PROCESS PROGRAM MANAGEMENT 9.3
EQUIPMENT CONSTANT 9.4
ACKNOWLEDGE TERMINAL MESSAGE 9.5
ALARMS 9.6
SPOOLING 9.7
EQUIPMENT ERROR 9.8
EQUIPMENT SPECIFIC INFORMATION 9.9
MATERIAL MOVEMENT 9.10
HOST SPECIFIC INFORMATION 9.11
LIMITS MONITORING 9.12
SUGGESTED EVENT REPORTS 9.13
SIMULTANEOUS EVENTS (TIME) 9.14
MODIFIED PARAMETERS 9.15
GEM Manual for DEK Printers Event Messages
Issue 1.6 January 22, 2018 Page 142 of 171
8.1 Control Model Events
EVENT - CEID
DESCRIPTION
31450 Control State – Change to LOCAL.
31451 Control State – Change to OFF-LINE.
31452 Control State – Change to REMOTE.
31456 Operator command issued.
31550 GEM connected.
31551 GEM disconnected.
8.2 Process Model Events
EVENT - CEID
DESCRIPTION
90001 Equipment moved to Recovery state.
90002 Equipment moved to Setup state.
90003 Equipment moved to Ready state.
90004 Equipment moved to Maintenance state.
90005 Equipment moved to Waiting state.
90006 Equipment moved to Running state.
90007 Equipment moved to Down state.
8.3 Process Program Management Events
EVENT - CEID
DESCRIPTION
31265 Process program loaded.
31266 New process program created and loaded.
31267 Process program change.
31346 Product Data modified (with change details – see section 9.15).
32035 Operator deleted process program.
40416 Z-Lock Not Fitted Warning.
40417 Local Parameters changed to.
40418 Local parameters not loaded.
40419 Local Parameters not applied for print.
40420 Local Parameters not reinstated after print.
40421 Local Parameters not saved.
8.4 Equipment Constant Change Event
EVENT - CEID
DESCRIPTION
31440 Equipment constant change.
GEM Manual for DEK Printers Event Messages
Issue 1.6 January 22, 2018 Page 143 of 171
8.5 Acknowledge Terminal Message Event
EVENT - CEID
DESCRIPTION
31441 Acknowledge terminal message.
8.6 Alarm Events
EVENT - CEID
DESCRIPTION
31253 Cover opened.
31254 Cover closed.
31314 Head left partly open.
31315 Head moved to safe state.
8.7 Spooling Events
EVENT - CEID
DESCRIPTION
31453 Spooling activated.
31454 Spooling deactivated.
31455 Spool transmission failure.
8.8 Equipment Error Events
EVENT - CEID
DESCRIPTION
10003 System power down.
31201 Pneumatic power down.
31202 Front squeegee error.
31203 Rear squeegee error.
31204 Rising table error.
31205 Print carriage error.
31206 Paste carriage error.
31207 Camera X axis error.
31208 Camera Y axis error.
31209 Rail width error.
31210 Screen XF error.
31211 Screen XR error.
31212 Screen Y error.
31213 Paste cartridge tilt error.
31214 Screen changer drive error.
31215 Board stop stuck.
31216 Board clamp stuck.
31217 Board stuck in rails.
31218 Unable to find fiducial.
31219 Rail lifted error.
