GEM Manual for DEK Printers Machine GEM Compliance
Issue 1.6 January 22, 2018 Page 14 of 171
3.12 Equipment Specific Information Events (CEIDs)
Name CEID Name CEID
System power on 10002 New event log 31297
Line power on 31251 No cleaner paper 31301
Printer ready 31255 No cleaner solvent 31302
Head raised 31256 Inspection cycle complete 31316
Head closed 31257 Clock change request 31317
Cycle aborted 31260 Clock changed 31318
Cycle completed 31261 Remote barcode received 31457
Cleaning screen 31262 Evaluation dongle detected 40004
Parameter adjusted 31263 Valid dongle detected 40005
Setup started 31264 Dongle changed 40007
Setup ended 31272 Front print speed 40008
Start print cycle 31273 Rear print speed 40009
End print cycle 31275 ProFlow cassette low 40055
Board printed 31277 Configuration Parameter modified
31345
Operator log on 31278 Adjust Parameter modified 31347
Operator log off 31279 Fiducial setup entered 40126
Clear batch count 31280 Fiducial setup ended 40127
Start maintenance 31281 Diagnostics ended 40128
End maintenance 31282 Adjust entered 40129
Pressure re-calibrated 31283 Adjust ended 40130
Offset recalibrated 31284 Adjust while running entered 40131
X,Y scale recalibrated 31285 Adjust while running ended 40132
Theta recalibrated 31286 Item verification succeeded 40151
Configuration change 31287 Verification value reset 40153
Start diagnostics 31288 Verification value restored 40154
End diagnostics 31289 Batch/lot ID changed 40155
Camera reference reset 31291 Product ID verification succeeded
40156
Vision height reset 31293 Traceability data available 40177
Print height reset 31294 Fiducial Alignment Started 40191
Software updated 31296 Fiducial Alignment Complete 40192
Fiducial Alignment SW Fallback 40374
GEM Manual for DEK Printers Machine GEM Compliance
Issue 1.6 January 22, 2018 Page 15 of 171
3.13 Specific Material Movements (CEIDs)
Name CEID
Paste dispensing 31258
Paste cartridge empty 31259
Screen unloaded 31268
Screen loaded 31269
Tool change started 31270
Tool change completed 31271
Board received 31274
Printed board ready 31276
Board delivered / removed 31319
Vortex cassette replaced 40024
3.14 Limit Monitoring Status Events (CEIDs)
Name CEID
Humidity 31008
Temperature 31016
batch_count 31020
3.15 Discrete Data Variable Limit Events (CEIDs)
Name CEID
measured_cycle_time 32004
throughput_cycle_time 32005
front_print_pressure 32008
rear_print_pressure 32009
print_speed 32010
table_separation_speed 32011
board_stretch_error 32012
Xerr 32013
Yerr 32014
theta_err 32015
board_fiducial_1_score 32021
board_fiducial_2_score 32022
board_fiducial_3_score 32023
screen_fiducial_1_score 32024
screen_fiducial_2_score 32025
screen_fiducial_3_score 32026
ProflowPastePressure 32031
front_print_speed 32086
rear_print_speed 32087
GEM Manual for DEK Printers Machine GEM Compliance
Issue 1.6 January 22, 2018 Page 16 of 171
3.16 Host Specific Information Events (CEIDs)
Name CEID Name CEID
Process program directory request 31400
X forward offset adjusted 31430
Process program request 31401
Y forward offset adjusted 31431
Erase process program request 31402
Theta forward offset adjusted 31432
Rename process program request 31403
X reverse offset adjusted 31433
Load process program request 31404
Y reverse offset adjusted 31434
Download process program request
31405
Theta reverse offset adjusted 31435
Upload process program request 31406
Paste dispensed after host
command
31436
Download configuration request 31407
Screen cleaned after host command
31437
Upload configuration request 31408
Comms enabled 31438
Upload management data request 31409
Comms disabled 31439
Clear management batch data
request
31410
Paste kneaded after host command 31442
Clear management session data
request
31411
Paste conditioned after host
command
31443
Upload event log request 31412
Proflow pressure adjusted 31458
Clear event log request 31413
Comms - Adjust front print speed 40010
Comms - Start request 31414
Comms - Adjust rear print speed 40011
Comms - Stop request 31415
Host Command Start Failed 40325
Update mode request 31416
Host Command Stop Failed 40326
Communication error 31417
Host Command Pause Failed 40327
Parameter information uploaded 31418
Host Command Erase Log Failed 40328
Parameter information downloaded
31419
Host Command Erase Batch Failed 40329
Upload parameter 31420
Host Command Erase Session
Failed
40330
Comms - Status request 31421
Host Command Rename Product
Failed
40331
Comms - Rebuild process program
list
31422
Host Command Adjust Parameter
Failed
40332
Paste dispense rate adjusted 31423
Host Command Clean 1 Failed 40333
Print speed adjusted 31424
Host Command Clean 2 Failed 40334
Front squeegee pressure adjusted 31425
Host Command Paste Failed 40335
Rear squeegee pressure adjusted 31426
Host Command PP-Select Failed 40336
Print gap adjusted 31427
Host Command Change Screen
Failed
40337
Separation speed adjusted 31428
Host Command Knead Paste Failed
40338
Cleaning rate adjusted 31429
Host Command Save Product
Failed
40376
