GEM Manual for DEK Printers Appendix A
Issue 1.6 January 22, 2018 Page 163 of 171
10 Appendix A
10.1 REMOTE COMMANDS
This appendix details the valid commands and parameters that may be sent using the Remote
Command SECS II transaction, S2F41.
The commands and parameter names passed in S2F41 are ASCII, while the parameter values
are numeric or ASCII depending upon the command. The following table lists the valid
commands RCMD for both S2F21 and S2F41.
S2F41 RCMD (ASCII) S2F21 DESCRIPTION
START 0 Start processing with the currently loaded process program.
STOP 1 Stop processing at the end of the current print cycle.
ERASE_LOG 2 Delete all event log data.
ERASE_BATCH 3 Clear all batch data in the management information file.
ERASE_SESSION 4 Clear all session data in the management information file.
RENAME_PRODUCT
5 Rename process program to parameter value.
See parameter table below.
ADJUST_PARAMETER 6 Set process program parameter to new value.
See parameter table below.
CLEAN 7 Clean screen type 1 according to current process program
parameters.
CLEAN_2 none Clean screen type 2 according to current process program
parameters.
PASTE 8 Add paste automatically.
PP-SELECT none Select process program for execution.
See parameter table below.
CHANGE_SCREEN none Load or unload the screen using the method specified by the
parameter. See parameter table below.
KNEAD_PASTE none Use the next board that arrives to perform a paste knead cycle.
PAUSE
SAVE_PRODUCT
none
none
Pause print cycle operation running printer. Remote command
START (S2F41) or 0(S2F21) will resume printing. Remote
command STOP (S2F41) or 1(S2F21) will stop processing at
the end of the print cycle.
Save changes made to current process program
The following commands can be rejected if the Verification option is enabled and a dependant
item has been enabled, but not been verified. The applicable items for each command are
tabulated below:
Command
Item
Paper
Vortex Cassette
Solvent
Print Medium Screen Squeegee Blades
Squeegee
Holders
ProFlow Head
Start
Clean/Clean_2
Paste
Change Screen
(load)
Knead Paste
GEM Manual for DEK Printers Appendix A
Issue 1.6 January 22, 2018 Page 164 of 171
Remote Command Parameters:
PP_SELECT Parameters
CPNAME (ASCII) DESCRIPTION CPVAL type min-max
RECEIVED_FILE_NAME Name of the process program to use. ASCII
RENAME_PRODUCT Parameters
CPNAME (ASCII) DESCRIPTION CPVAL type min-max
OLD_FILE_NAME The old name of the process program. ASCII
NEW_FILE_NAME The new name of the process program. ASCII
ADJUST PARAMETER Parameters
CPNAME (ASCII) S2F21 DESCRIPTION CPVAL
type
Range Resol.
ADJUST_PASTE 0 Adjusts paste dispense rate. F8, none 0-100 1
ADJUST_FRONT_SPEED 1 Adjusts front print speed. F8, mm/s 2-300
1
ADJUST_REAR_SPEED 2 Adjusts rear print speed. F8, mm/s 2-300
1
ADJUST_FRONT_P 3 Adjusts forward print pressure. F8, Kg 0-20 0.2
ADJUST_REAR_P 4 Adjusts reverse print pressure. F8, Kg 0-20 0.2
ADJUST_PROFLOW_PRESS 5 Adjusts Proflow print pressure. F8, Kg 0-20
0.2
ADJUST_GAP 6 Adjusts print gap. F8, mm 0-6 0.025
ADJUST_SEPARATE 7 Adjusts separation speed. F8, mm/s 0.1–20 0.1
ADJUST_CLEAN 8 Adjusts clean screen rate. F8, none
0−200 1
ADJUST_CLEAN_2 - Adjusts clean screen rate 2. F8, none
0−200 1
ADJUST_FWD_X 9 Adjusts forward X offset. F8, mm
±
1
0.004
ADJUST_FWD_Y 10 Adjusts forward Y offset. F8, mm
±
1
0.004
ADJUST_FWD_T 11
Adjusts forward
θ
offset.
F8, arcsec
±10
00
2
ADJUST_REV_X 12 Adjusts reverse X offset. F8, mm
±
1
0.004
ADJUST_REV_Y 13 Adjusts reverse Y offset. F8, mm
±
1
0.004
ADJUST_REV_T 14
Adjusts reverse
θ
offset.
F8, arcsec
±10
00
2
CHANGE_SCREEN Parameters
CPNAME =
“CHANGE_METHOD”
DESCRIPTION CPVAL type
CPVAL = “AUTO” Exchange the screen in the printer (if present) with one in
the autochanger. Load the new screen to the position
specified by the process program.
ASCII
CPVAL = “MAN_LOAD” Load the screen in the printer to the position specified by the
process program.
ASCII
GEM Manual for DEK Printers Appendix B
Issue 1.6 January 22, 2018 Page 165 of 171
11 Appendix B
Operator instructions for configuring and using GEM on DEK printers.
11.1 Network Configuration
The GEM IP Address for the machine must be set up in the DekSECSII.cfg file, this can be checked
and edited if necessary in the configuration file E:\Config\DekSECSII.cfg.
NOTE: for older versions of printer software, the location of the DekSECSII.cfg file may be
D:\Program Files\DEK\MachineControl\Printer.
Set the PASSIVE ENTITY IP ADDRESS to the printer’s IP Address.
The IP Address can be obtained by using the ipconfig command at the command prompt.
If there is more than one printer communicating with the GEM host, set the DEVICEID differently for
each printer. The default value is 0x109 (265). Alternate DEVICEID values should be chosen within
the range 0x0000 – 0x7FFF (0 – 32767).
