GEM Manual for DEK Printers Appendix C
Issue 1.6 January 22, 2018 Page 169 of 171
12.4 ECIDs
To show a list of all of the ECIDs in the software, send an S2F29 with an empty list to request all
ECIDs.
Host initiated
Host to equipment: S2F29
Structure: L,0
GEM Manual for DEK Printers Modification Record
Issue 1.6 January 22, 2018 Page 170 of 171
14 Modification Record
Preliminary Issue 0.1 January 14, 2013 Paul Beeston
• Update of GEM manual, specifically for the Galaxy EX Platform.
• Support of TRS software version 09 SP08 (1397) which includes a set of functionality and defect
fixes that is a combination of:
o Functionality provided by 09 SP05 (1184 B05)
o DEK’s mainstream printer software evolution from SP06 to SP08 (new features and defect
fixes).
o Automated Process and Equipment Management functionality: 09 SP05 (1241 B02). Also
provides support for compound product files.
Preliminary Issue 0.2 January 17, 2013 Paul Beeston
• Update the CEID Events list to remove those that no longer exist in the code. Events removed are:
o Line power off (CEID 31252)
o User has enabled the Autoflex tooling (CEID 31330)
o User has disabled the Autoflex tooling (CEID 31331)
o System has enabled Autoflex tooling (CEID 31332)
o System has disabled Autoflex tooling (CEID 31333)
o Tooling data changed (CEID 31334)
o options.enb file attribute error (CEID 31459)
Preliminary Issue 0.3 June 04, 2013 Lee Russell
• CEID’s added
o Fiducial Alignment Started (CEID 40191)
o Fiducial Alignment Complete (CEID 40192)
o Fiducial Alignment SW Fallback (CEID 40374)
• DVID’s added
o PrintDeposits (DVID 2090)
o PrintSpeedDeposit1 (DVID 2091)
o PrintSpeedDeposit2 (DVID 2092)
o PrintSpeedDeposit3 (DVID 2093)
o PrintSpeedDeposit4 (DVID 2094)
o PrintSpeedDeposit5 (DVID 2095)
o PrintSpeedDeposit6 (DVID 2096)
o PrintSpeedDeposit7 (DVID 2097)
o PrintSpeedDeposit8 (DVID 2098)
o PrintSpeedDeposit9 (DVID 2099)
o PrintSpeedDeposit10 (DVID 2100)
o CleanRate1 (DVID 2151)
o CleanRate2 (DVID 2152)
o LastCleanType (DVID 2153)
GEM Manual for DEK Printers Modification Record
Issue 1.6 January 22, 2018 Page 171 of 171
• ECID’s added
o ConveyorType (ECID 55)
• ECID’s removed
o RCPOWCode (ECID 45)
o RHMOnFailureAction (ECID 71)
• Edited Appendix B, Network Configuration. The path to the DekSECSII.cfg file has been changed
to E:\Config\DekSECSII.cfg
Preliminary Issue 0.4 November 6th, 2013 Lee Russell
• LRUL-UK-00755 - Removed Single option from received_mode EC.
• LRUL-UK-00768 - Removed ADJUST_SPEED remote command and reordered the list of
ADJUST PARAMETER remote commands to match the code.
• LRUL-UK-00771 - Removed ADJUST_INSP_RATE and ADJUST_BATCH_LIMIT from the list
of ADJUST PARAMETER remote commands.
Preliminary Issue 1.1 March 20th, 2014 Matt Baker
• Sections renumbered
• 40416 to 40421 Event IDs added Section 9.6
Issue 1.2 May 9
th
, 2014 Lee Russell
• All headings renumbered
• Minor formatting changes
• ScreenSize changed from 256 to 265 LRUL-UK-01317
Issue 1.3 August 9
th
, 2017 Tom Russell
• Added DVIDs 2154 and 2155
• Added Cyclone Duo option to ECID 53
• Corrected Print speeds
• Added motor speed values
• Corrected clean rate values
• Added missing ECIDs
Issue 1.4 August 10
th
, 2017 Tom Russell
• Added Appendix C
• Updated Remote Command Parameters
Issue 1.5 October 19
th
, 2017 Tom Russell
• Added missing OBJIDs
Issue 1.6 January 22
nd
, 2018 Tom Russell
• Various ECID corrections
• Added S2F15 compatible column to ECID table
• Updated document branding and layout.
Issue 1.7 March 7
th
, 2018 Tom Russell
• Added OBJID 30160 and 3161
• Removed CEID 40404 and 40405
• Added CEID 40457, 40458, 40459, 40460, 40461, 40462
• Added Tooling Hardware ECID values 8 and 9
