GEM Manual for DEK Printers Capabilities

Issue 1.6 January 22, 2018 Page 41 of 171

4.6 Process Program Management

This capability provides the host with the ability to control process program (product)

distribution between DEK printers. This is achieved using the following functionality.

Each printer has a process program create / edit capability. When the operator creates a new

process program or modifies an existing one, a collection event report is generated (if enabled

by host). The host uses the event reports (3.2.1) to set up the techniques to link the machine

variables, pp_old_file_name and pp_change_status to the process program change event.

The host can upload and download, new / changed programs from and to printers. The host can

also delete and rename programs resident on a printer. It can also request a directory of

programs resident on a printer. Finally, the Equipment can upload and download new / changed

programs from and to the Host. See Appendix B for Operator procedures.

Using these functions, the host can maintain a master program library and force consistency

across multiple printers.

The DEK printer supports only unformatted process programs. Modification of the process

program is not permitted while the machine is running.

Note: Full process program management is only permitted when the machine is in the READY

machine state and in the ON-LINE:REMOTE control state. In the READY machine state and

ON-LINE:LOCAL control state, Host initiated process program management is limited to

Directory Request only.

Note: The printer normally allows limited adjustment of the process parameters, locally by the

operator or via the remote command “ADJUST_PARAMETER”. This can be altered by setting

the Equipment Constant “process_adjustments” to disable operator, remote or both.

Scenarios:

Operator creates / changes equipment process program:

Comments Host Equipment Comments

PPCHANGENAME / PPCHANGESTATUS are

updated.

<-- S6F11

[IF] CEID for process program change is enabled

[THEN] Send event report.

Event report acknowledged. S6F12 -->

Host-initiated process program upload:

Comments Host Equipment Comments

Process program request S7F5 -->

<-- S7F6 Process program data.

GEM Manual for DEK Printers Capabilities

Issue 1.6 January 22, 2018 Page 42 of 171

Equipment-initiated process program upload:

Comments Host Equipment Comments

<-- S7F1

[IF] Process program is multi-block [THEN] PP

Load Inquire

PP Load Grant S7F2 -->

[END_IF]

<-- S7F3 PP Send

PP Acknowledge S7F4 -->

Host-initiated process program download:

Comments Host Equipment Comments

[IF] PP is Multi-block PP Load Inquire S7F1 -->

<-- S7F2 PP Load Grant

[END_IF]

PP Send S7F3 -->

<-- S7F4 PP Acknowledge.

<-- S6F11

[IF] PP Validation = bad [AND] Bad Download

CEID

enabled [THEN] send Bad Download

event.

Event Acknowledge. S6F12 --> [END_IF]

Equipment-initiated process program download:

Comments Host Equipment Comments

<-- S7F5 PP Request

PP Data S7F6 -->

<-- S6F11

[IF] PP Validation = bad [AND] Bad Download

CEID

enabled [THEN] send Bad Download

event.

Event Acknowledge. S6F12 --> [END_IF]

Host-initiated process program delete:

Comments Host Equipment Comments

Delete PP send S7F17 -->

<-- S7F18 Delete PP Acknowledge. Process program

removed from non-volatile storage.

Process program directory request:

Comments Host Equipment Comments

Current EPPD Request. S7F19 -->

<-- S7F20 Current EPPD Data

See section 7-4.

GEM Manual for DEK Printers Capabilities

Issue 1.6 January 22, 2018 Page 43 of 171

Material Movement

Material tracking can be performed by enabling the following events. Event reporting is

covered in Section 7.

EVENT

CEID

DESCRIPTION REFERENCE

31258 Paste dispensing. Paste dispense cycle started.

31259 Paste cartridge empty. Paste cartridge detected empty.

31264 Setup started. Setup page has been entered.

31265 Process program loaded. Process program loaded into printer.

31266 New process program. New process program created and loaded.

31268 Screen unloaded. Screen just unloaded.

31269 Screen loaded. Screen just loaded.

31270 Tool change started. Tool Change page just entered.

31271 Tool change complete. Tool Change page just exited.

31272 Setup ended. Setup page just exited.

31273 Start print cycle. Print cycle/s just started.

31274 Board received. Board received at input sensor.

31275 End print cycle. Print cycle/s just completed.

31276 Printed board ready. Board at output sensor.

31277 Board printed. Board just printed.

31301 No cleaner paper. Cleaner run out of paper.

31302 No cleaner solvent. Cleaner run out of solvent.

31319 Board delivered / removed. Board has left the machine.

Scenario:

Material sent to / removed from equipment:

Comments Host Equipment Comments

<-- S6F11 Material movement CEID

Host acknowledges report. S6F12 -->
