GEM Manual for DEK Printers Introduction

Issue 1.6 January 22, 2018 Page 6 of 171

1 Introduction

GEM compatible screen printers manufactured by ASM Assembly Systems. are capable of

operating in co-operation with automatic loading systems and factory hosts. In this manual the

screen printer is referred to as the “equipment”.

This manual describes the host view of the GEM compliant interface provided with the system.

A detailed description of the equipment capabilities is followed by the implemented SECS II

streams and functions list.

The machine variables, alarms and event messages are then listed to enable remote process

control to be achieved.

References:

SEMI E4-91 - SEMI Equipment Communications Standard 1 Message Content (SECS-I)

SEMI E5-96 - SEMI Equipment Communications Standard 2 Message Content (SECS-II)

SEMI E30-95 - The GEM Standard

SEMI E37-0303 – High-Speed SECS Message Services (HSMS) Generic Services

SEMI W39-0703 – Object Services Standard: Concepts, Behaviour and Services

To order the SEMI Publications, contact:

SEMI,

Dept. 05607,

San Francisco,

CA 94139

GEM Manual for DEK Printers GEM Compliance Statement

Issue 1.6 January 22, 2018 Page 7 of 171

2 GEM Compliance Statement

The following tables show the fundamental requirements and additional capabilities

implemented on this equipment.

Fundamental GEM Requirement Implemented GEM compliant

State models Yes Yes

Equipment processing states Yes Yes

Host Initiated S1F13/14 scenario Yes Yes

Event notification Yes Yes

On-Line identification Yes Yes

Error messages Yes Yes

Documentation Yes Yes

Control (operator initiated) Yes Yes

Additional Capabilities Implemented GEM compliant

Establish communications Yes Yes

Dynamic event report configuration Yes Yes

Variable data collection Yes Yes

Trace data collection Yes Yes

Status data collection Yes Yes

Alarm management Yes Yes

Remote control Yes Yes

Equipment constants Yes Yes

Process program management Yes Yes

Material movement Yes Yes

Equipment terminal services Yes Yes

Clock Yes Yes

Limits monitoring Yes Yes

Spooling Yes Yes

Control (host initiated) Yes Yes

GEM Manual for DEK Printers Machine GEM Compliance

Issue 1.6 January 22, 2018 Page 8 of 171

3 Machine GEM Compliance

3.1 Equipment Constants (ECIDs)

ECID Name ID ECID Name ID

GemConfigConnect 1 ScreenSize 69

DeviceName 2 RollHeightHardware 70

GemEstabCommDelay 3 RollHeightMonitor 72

GemPollDelay 4 ConsumableAction 73

GemInitCommState 5 VacuumHoldTime 74

GemInitControlState 6 2DiMovementTuning 75

GemOfflineSubstate 7 CleanerVacuum 76

GemOnlineFailed 8 PasteTrails 77

GemOnlineSubstate 9 TransportWaitMode 78

received_mode 10 ClampType 80

inspect_rate 11 ToolingMonitoring 81

batch_limit 12 FiducialMonitoring 83

process_adjustments 13 FiducialSearch 84

MaxSpoolTransmit 14 RemoteBoardStopHardware 85

OverWriteSpool 15 BoardStopXOffset 86

spooling_enabled 16 CameraIdlePosition 88

TimeFormat 40 UnloadBoardStart 89

RunGEMRemote 41 MaintenanceMonitoring 95

CompoundProductFiles 46 MachineLocation 96

Make 50 AutoRailWidth 97

Model 51 ProductDirectory 98

StencilCleaningSystem 53 DataFileLocation 99

ApplicatorType 54 DownLineBoardStop 101

ConveyorType 55 FrontRtoLSpeed 104

TransportMode 56 FrontRtoLSpeed 105

MachineUnits 57 RearLtoRSpeed 106

UplineProtocol 58 RearRtoLSpeed 107

DownlineProtcol 59 FrontRtoLSpeed 108

TransferPeriod 60 FrontRtoLSpeed 109

PasteDispensePosition 61 RearLtoRSpeed 110

ToolingHardware 62 RearRtoLSpeed 111

FiducialReference 63

ProductBarcodeHardware 64

RemoteBarcodeHardware 65

AdvancedProFlow 66

PressureHardware 67

PasteDispenser 68
