No. Part No. Part Name Qty Remarks Drawing Name Drawing No. 1 LG0-M58A0-00X SPRING 1 5264 2 LG0-M58A3-00X CYLINDER 1 3 LC0-M58K0-00X SV ASSY. 1 4 LG0-M58A5-00X SOLENOID VALVE 1 5 LG0-M58A9-00X SPRING 2 5162 6 LG0-M90AK-0…
No. Part No. Part Name Qty Remarks Drawing Name Drawing No.
8
LG1-M5608-00X SLIDER L 2
9
LG1-M5609-00X SLIDER R 2
10
LG1-M560A-00X BLOCK,NUT R 1
JEDEC TRAY LG1-M5600-000
MX-20D(Tray)
No. Part No. Part Name Qty Remarks Drawing Name Drawing No.
1
LG0-M58A0-00X SPRING 1 5264
2
LG0-M58A3-00X CYLINDER 1
3
LC0-M58K0-00X SV ASSY. 1
4
LG0-M58A5-00X SOLENOID VALVE 1
5
LG0-M58A9-00X SPRING 2 5162
6
LG0-M90AK-00X MUFFLER 2
7
LG0-M34H4-00X MICRO SWITCH 2
MX-ST2-ASSY LG0-M5800-000 1/2
LG0-M5800-000 1/2MX-ST2-ASSY
5 1
7
3 (4) 7 2
MX-ST2
No. Part No. Part Name Qty Remarks Drawing Name Drawing No.
1
KL4-M1718-00X KNOCK CYLINDER 1
2
LG8-M13K2-00X SAFETY SW ASSY. 1
COVER ASSY LG8-M1300-010
2 1
MXR-20(Cover)
