Operational Safety 2.1.1 Conventions for the use of safety instructions Safety Instructions User Manual JTF-MW on SIPLACE E 11 2 2 O p e r a t io n a l S a f e t y Operational Safety 2.1 2 . 1 S a f e t y I n s t r u c t…
Introduction
Important Notes about the User Manual 1.2.6 Abbreviations
10 User Manual JTF-MW on SIPLACE E
Operational Safety
2.1.1 Conventions for the use of safety instructions Safety Instructions
User Manual JTF-MW on SIPLACE E 11
2
2 Operational Safety
Operational Safety
2.1
2.1 Safety Instructions
Safety Instructions
2.1.1
2.1.1 Conventions for the use of safety instructions
Conventions for the use of safety instructions
This manual contains notes that must be observed to guarantee your personal safety and to avoid dam-
age to equipment. These notes are highlighted by warning triangles and are indicated as follows accord-
ing to the level of risk:
2.1.2
2.1.2 Staff Qualifications and Training
Staff Qualifications and Training
Qualified or adequately trained personnel means that these people are familiar with the setting up, op-
eration and maintenance and are suitably qualified, e.g.:
▪ Have been trained, instructed or authorized to switch on and off, isolate, earth and identify electrical
circuits and system components in accordance with normal safety standards.
▪ Have been trained or instructed in the upkeep and use of appropriate safety equipment in accord-
ance with normal safety standards.
▪ Have received first aid training.
2.1.3
2.1.3 Important Notes on Operational Safety
Important Notes on Operational Safety
The following points must be observed in order to maintain operational safety:
DANGER
Definition
For the purposes of this manual, this indicates that fatal or severe injuries or considerable dam-
age to property will occur if this hazard warning is not observed.
WARNING
Definition
For the purposes of this manual, this indicates that fatal or severe injuries or considerable dam-
age to equipment may occur if these warning instructions are not followed.
CAUTION
Definition
For the purposes of this manual, this indicates that minor injuries or damage to property may
occur if this caution is not observed.
NOTICE
Definition
For the purposes of this manual, this note provides information about the product or indicates
a part of the manual that requires particular attention.
Operational Safety
Safety Instructions 2.1.3 Important Notes on Operational Safety
12 User Manual JTF-MW on SIPLACE E
2.1.3.1
2.1.3.1 General
General
► Operational safety is only guaranteed during use of the user manual as prescribed.
► Always observe the applicable accident prevention regulations and the special safety regulations in
your country!
► Make sure that the warning labels are always clearly identifiable and always easily readable.
► Replace any damaged warning or notice labels. Replace any labels that are missing.
► The machine key for releasing the covers on the machine must be kept in a safe place where it is
only accessible to qualified personnel.
► If you need to work on the machine and you do not have adequately trained personnel at your com-
pany, always call in a service engineer from ASM Assembly Systems GmbH & Co. KG! ASM Assem-
bly Systems GmbH & Co. KG will not accept liability for any damage or consequential damage that
is the result of incorrect work!
► If particularly hazardous situations are identified while the module is in use, the module owner must
immediately notify the manufacturer in writing so that appropriate action can be taken to reduce the
potential danger.
► Wear safety glasses when using alcohol to clean the conveyor belt.
See also
2.1.4.2 Warning, Prohibition and Cautionary Labels [ ➙ 14]
2.1.3.2
2.1.3.2 Safety of Operators and Other Persons
Safety of Operators and Other Persons
► Module operators may only carry out work for which they have been adequately trained and with
which they are totally familiar!
► NEVER open one of the covers if you are not totally familiar with the use and functioning of the mod-
ule! Do not open the covers during operation unless you are told to do so in this Manual or in the
station software dialog!
► For your own safety, wear work clothes that conform to the guidelines of the professional associa-
tion, i.e. no wide sleeves etc.
► Reduce the risks by not wearing scarves, chains or ties at your work post.
► People with long hair must wear a protective head covering.
WARNING
Safe operation of module
In spite of all the safety precautions taken by the manufacturer, failure to use the module as
prescribed can result in severe physical injury and/or considerable damage to equipment! For
the module to be safe, it must be used correctly by qualified personnel and all warnings must
be observed. Some work requires training that goes beyond the scope of this Manual.
WARNING
Voltage
The module is electrically driven. When electrical devices are in use, certain parts carry a volt-
age of 24 V!
► Before performing any work to parts which conduct electricity, switch the machine off at the
main switch and unplug the Harting connector, to disconnect the power between the mod-
ule and the machine.
⇨ There is a risk of death, severe injury and/or considerable damage to equipment if these
instructions are not followed.
