MODEL GXH-3JPH 0909-003 217 216 218 219 220 231 232 203 257 277 236 235 237 244 239 247 205 248 234 233 254 . 273 . 266 252 . 273 . 266 258 . 274 . 267 252 . 273 . 266 253 . 273 . 266 259 . 274 . 267 251 . 271 . 265 253 …

100%1 / 154
103 6301541990 MOTOR,AC-SERVO 1 M21 858CX-100-203 4M150241
105 6301536156 ENCODER(LIDA49M HEAD) 1 U21 858CX-100-005 23G40028
115 6301570068 BRACKET 1 858CX-100-215 211FC425
117 6301233840 PLATE 1 858CX-100-217 211D9273
118 6301233857 PLATE 1 858CX-100-218 211D9274
119 6301233864 PLATE 1 858CX-100-219 211D9275
120 6301534985 BRACKET 1 858CX-100-220 211FB861
121 6301667447 BRACKET 1 858CX-100-221 211FD609
124 6301663579 BRACKET 1 858CX-100-224 211FD555
125 6301663586 BRACKET 1 858CX-100-225 211FD556
131 6301621371 PLATE 1 858CX-100-301 211DD526
132 6301233567 BRACKET 1 858CX-100-302 211F7961
133 6301578682 BRACKET 1 858CX-100-303 211FC549
134 6301578705 BRACKET 1 858CX-100-304 211FC550
135 6301233949 PLATE 1 858CX-100-305 211D9276
136 6301233963 BRACKET 1 858CX-100-306 211F7974
137 6301249032 PLATE 1 858CX-100-307 211D9396
140 6301624112 BRACKET 1 858CX-100-310 211FD166
144 6301596891 BRACKET 1 858CX-100-314 211FC811
147 6301598499 BRACKET 1 858CX-100-317 211FC836
148 6301559209 BRACKET 1 858CX-100-318 211FC221
151 6300007527 BOLT,HEX-SCT 2 M3X10 858CX-100-501 221A0007
152 6300007602 BOLT,HEX-SCT 4 M4X6 858CX-100-502 221A0015
153 6300007619 BOLT,HEX-SCT 10 M4X8 858CX-100-503 221A0016
154 6300007626 BOLT,HEX-SCT 18 M4X10 858CX-100-504 221A0017
155 6300007633 BOLT,HEX-SCT 16 M4X12 858CX-100-505 221A0018
157 6300007657 BOLT,HEX-SCT 4 M4X16 858CX-100-507 221A0020
158 6300007756 BOLT,HEX-SCT 11 M5X12 858CX-100-508 221A0030
159 6300007763 BOLT,HEX-SCT 2 M5X16 858CX-100-509 221A0031
165 4111413902 WASHER V 3X7X0.5 2 858CX-100-515 221H0312
166 4111414008 WASHER V 4X9X0.8 51 858CX-100-516 221H0315
167 4111414107 WASHER V 5X10X1 13 858CX-100-517 221H0318
171 4111412806 WASHER SPR 3 2 858CX-100-521 221H0281
173 4111412905 WASHER SPR 4 48 858CX-100-523 221H0284
174 4111416705 WASHER SPR 5 13 858CX-100-524 221H0287
177 4111410307 NUT HEX 4 4 858CX-100-527 221F0082
MODEL GXH-3JPH
1004-004
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
CX-2
CX-2 list-1
MODEL GXH-3JPH
0909-003
217
216
218
219
220
231
232
203
257
277
236
235
237
244
239
247
205
248
234
233
254
.
273
.
266
252
.
273
.
266
258
.
274
.
267
252
.
273
.
266
253
.
273
.
266
259
.
274
.
267
251
.
271
.
265
253
.
273
.
266
254
.
273
.
266
258
.
274
.
267
255
.
273
.
266
254
.
273
.
266
254
.
273
.
266
253
.
273
.
266
253
.
273
.
266
222
224
225
273
258
.
274
.
267
254
.
273
.
266
BLOCK2
ビーム
X
部
BEAM X SECTION
Fig. CX-3
ケーブルラック
2 Cable Rack 2
CX-3 illust-1
203 6301541990 MOTOR,AC-SERVO 1 M21 858CX-100-203 4M150241
205 6301536156 ENCODER(LIDA49M HEAD) 1 U21 858CX-100-005 23G40028
216 6301570075 BRACKET 1 858CX-100-216 211FC426
217 6301233840 PLATE 1 858CX-100-217 211D9273
218 6301233857 PLATE 1 858CX-100-218 211D9274
219 6301233864 PLATE 1 858CX-100-219 211D9275
220 6301534985 BRACKET 1 858CX-100-220 211FB861
222 6301667492 BRACKET 1 858CX-100-222 211FD610
224 6301663579 BRACKET 1 858CX-100-224 211FD555
225 6301663586 BRACKET 1 858CX-100-225 211FD556
231 6301621371 PLATE 1 858CX-100-301 211DD526
232 6301233567 BRACKET 1 858CX-100-302 211F7961
233 6301578682 BRACKET 1 858CX-100-303 211FC549
234 6301578705 BRACKET 1 858CX-100-304 211FC550
235 6301233949 PLATE 1 858CX-100-305 211D9276
236 6301233963 BRACKET 1 858CX-100-306 211F7974
237 6301249032 PLATE 1 858CX-100-307 211D9396
239 6301624105 BRACKET 1 858CX-100-309 211FD165
244 6301596891 BRACKET 1 858CX-100-314 211FC811
247 6301598499 BRACKET 1 858CX-100-317 211FC836
248 6301559209 BRACKET 1 858CX-100-318 211FC221
251 6300007527 BOLT,HEX-SCT 2 M3X10 858CX-100-501 221A0007
252 6300007602 BOLT,HEX-SCT 4 M4X6 858CX-100-502 221A0015
253 6300007619 BOLT,HEX-SCT 10 M4X8 858CX-100-503 221A0016
254 6300007626 BOLT,HEX-SCT 18 M4X10 858CX-100-504 221A0017
255 6300007633 BOLT,HEX-SCT 16 M4X12 858CX-100-505 221A0018
257 6300007657 BOLT,HEX-SCT 4 M4X16 858CX-100-507 221A0020
258 6300007756 BOLT,HEX-SCT 11 M5X12 858CX-100-508 221A0030
259 6300007763 BOLT,HEX-SCT 2 M5X16 858CX-100-509 221A0031
265 4111413902 WASHER V 3X7X0.5 2 858CX-100-515 221H0312
266 4111414008 WASHER V 4X9X0.8 53 858CX-100-516 221H0315
267 4111414107 WASHER V 5X10X1 13 858CX-100-517 221H0318
271 4111412806 WASHER SPR 3 2 858CX-100-521 221H0281
273 4111412905 WASHER SPR 4 48 858CX-100-523 221H0284
274 4111416705 WASHER SPR 5 13 858CX-100-524 221H0287
277 4111410307 NUT HEX 4 4 858CX-100-527 221F0082
MODEL GXH-3JPH
1004-004
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
CX-3
CX-3 list-1
