1 Introduction 1.5 Tools required, measuring equipment and materials Service Manual SIPLACE TwinStar (Twin, Twin HF, Twin VHF) 07/2020 11 Materials Materials contained in the HMK: Item no. C08 Cable ties B=2.5mm, L=102mm…
1 Introduction
1.5 Tools required, measuring equipment and materials
10 Service Manual SIPLACE TwinStar (Twin, Twin HF, Twin VHF) 07/2020
Tools contained in the HMK: Item no.
T23 Combitips advanced 0.1ml blue 03070440-xx
T24 Combitips advanced 0.1ml black 03078990-xx
T25 Combitips advanced 0.1 ml yellow 03077923-xx
T26 Combitips advanced 0.1 ml green 03077924-xx
T29 Lubrication application tool for star bearing CPP 03078632-xx
T30 DP clamping ring for fitting the CPP front plate 03077754-xx
T32 Open-end wrench size 10 03109302-xx
T37 Tweezers for filter disk CPP 03046190-xx
T40 Combitips advanced 0.1 ml red 03118173-xx
T41 Silicone hose D=12 mm L=20 mm 03058392-xx
T42 CD marker Edding 8400 03070076-xx
T44 Torque screwdriver ESD 0.1 - 0.6Nm 00386132-xx
T46 Wrench socket size 8 - 1/4" 03122880-xx
T47 Torque screwdriver ESD 0.4 - 1.0 Nm 00386253-xx
T50 Tool to adjust torque screwdriver ---
T53 Tweezers angled 140 mm oval tips 00096487-xx
T57 Combitips advanced 10ml orange 03109540-xx
T66 Filter disk removal device C&P20P 03108641-xx
T76 Torque interchangeable blades 1.5 mm, hexagonal 00386135-xx
T77 Torque interchangeable blades 2 mm, hexagonal 00386136-xx
T78 Torque interchangeable blades 2.5 mm, hexagonal 03090019-xx
T79 Torque interchangeable blades 3 mm, hexagonal 03109522-xx
T80 Phillips interchangeable blades PH1 03075861-xx
In addition, you need the following tools which are not included in the HMK:
Tools not contained in the HMK: Item no.
Size 10 wrench from hexagonal socket wrench set 850‑8mm 03122880‑xx
Pipe/hose cutters Festo ZRS 7658 00381443‑xx
Open-end wrench 5.5mm; 15mm (flat version)
Allen key 0.9 mm 00096201‑xx
Allen key set 1.5 to 10 mm 00353832‑xx
Allen key with pin 3.0 mm
Tweezers 150mm bent
SIPLACE Head Care Station V2.3 assembly 03159555‑xx
Retrofit instructions "digital pressure control valve and new TH air filter" DE+EN:
00196286‑xx
Torque interchangeable blades, Pozidriv size 0 ---
Tools for removing/fitting and calibrating the head, if needed (see also the
service manual for your machine)
---
1 Introduction
1.5 Tools required, measuring equipment and materials
Service Manual SIPLACE TwinStar (Twin, Twin HF, Twin VHF) 07/2020 11
Materials
Materials contained in the HMK: Item no.
C08 Cable ties B=2.5mm, L=102mm Panduit 00308458-xx
C10 Lubcon Thermoplex ALN 1001/00, 50ml (blue) 03078556-xx
C11 ISOFLEX Topas 5051 50 ml (green) 03078517-xx
C12 Klueberoil GEM 1 220N 50 ml (yellow) 03079640-xx
C13 Klueberalfa DH 3-100, 50 ml (black) 03078928-xx
C15 Klueberoil LAMORA D 220 30ml (red) 03118539-xx
C17 Whiteboard cleaner 10 pcs. 03070074Sxx
C21 Maintenance labels C&P20 - pack of 10 03067486-xx
C22 Cotton swabs 00388764-xx
C28 SM reel of labels 9x5 black matt (200 dots) 00388802-xx
In addition, you need the following materials which are not included in the HMK:
Materials not contained in the HMK: Item no.
Loctite 243 00334892‑xx
Cotton swabs 00388764‑xx
Lint-free cloth, KM wipe 03082092-xx
Ethanol or isopropyl ---
Compressed air ---
1 Introduction
1.5 Tools required, measuring equipment and materials
12 Service Manual SIPLACE TwinStar (Twin, Twin HF, Twin VHF) 07/2020
