31 按 NEXT 之後，出現下列訊息視窗： CAUTION, The machine is now going to ( 注意 , 機器的 Z 軸和刮刀上下將 Move the Z TOWER and cycle 會移動 ) the SQUEEGEE UP and DOWN. Pr ess NEXT to Continue, or EXIT to Quit. ( 按 NEXT 繼續 , 按 EXIT 離開 ) 按 NEXT 之後，出現…
30
Hardware Required:
Squeegee Blades , Stencil , Tactile
This Utility will set the SQUEEGEE height.(使用測刮刀高度)
Press NEXT to Continue, or EXIT to quit. (按 NEXT 繼續, 按 EXIT 離開)
按 NEXT 之後，出現下列訊息視窗：
Please install a stencil now. (現在請放入鋼板)
The REAME CLAMPS will activate when(按 NEXT 之後,啟動鋼板固定夾)
you press NEXT.
Press NEXT to Continue, or EXIT to quit. (按 NEXT 繼續, 按 EXIT 離開)
按 NEXT 之後，出現下列訊息視窗：
You must now install the squeegee blade. (你現在必須安裝刮刀)
Press NEXT to Continue, or EXIT to quit. (按 NEXT 繼續, 按 EXIT 離開)
Squeegee
This Utility will set the SQUEEGEE height.
Press NEXT to Continue, or EXIT to quit.
Please install a stencil now.
The REAME CLAMPS will activate when
you press NEXT.
Press NEXT to Continue, or EXIT to quit.
You must now install the squeegee blade.
Press NEXT to Continue, or EXIT to quit.
31
按 NEXT 之後，出現下列訊息視窗：
CAUTION, The machine is now going to(注意,機器的 Z 軸和刮刀上下將
Move the Z TOWER and cycle 會移動)
the SQUEEGEE UP and DOWN.
Press NEXT to Continue, or EXIT to Quit. (按 NEXT 繼續, 按 EXIT 離開)
按 NEXT 之後，出現下列訊息視窗：
Press SELECT to find Stencil Height(按 SELECT 之後,再測一次鋼板高度
or NEXT to Bypass. 按 NEXT 之後,不測鋼板高度)
Press NEXT to Continue, or EXIT to Quit. (按 NEXT 繼續, 按 EXIT 離開)
按 NEXT 之後，出現下列訊息視窗：
Press SELECT to JOG the sensor clear of(按 SELECT 移動偵測感應器,勿
paste or stencil apertures 碰到鋼板上錫膏及鋼板上 PAD 孔)
CAUTION, The machine is now going to
Move the Z TOWER and cycle
the SQUEEGEE UP and DOWN.
Press NEXT to Continue, or EXIT to Quit.
Press SELECT to find Stencil Height
or NEXT to Bypass.
Press NEXT to Continue, or EXIT to Quit.
Press SELECT to JOG the sensor clear of
paste or stencil apertures
or press NEXT to CONTINUE.
Press SELECT or NEXT to Continue.
32
or press NEXT to CONTINUE. (按 NEXT 馬上開始在本位置偵測刮刀高度)
Press SELECT or NEXT to Continue. (按 SELECT 或 NEXT 繼續)
你按 SELECT 之後，出現下列訊息及視窗：
JOG ACTIVE…(移動現在刮刀行程位置)
SQUEEGEE STROKE -112.050
Press EXIT to quit. (按 EXIT 離開)
你按 NEXT 與 EXIT 之後，出現下列訊息及視窗並開始測前後刮刀高度：
(開始偵測刮刀高度。測前刮刀時,偵測感應器先下降碰到鋼板後,前刮刀下降,
第一次先壓平刮刀,第二次自動偵測前刮刀高度;測後刮刀時, 偵測感應器先
下降碰到鋼板後,後刮刀下降,第一次先壓平刮刀,第二次自動偵測後刮刀高
度)
(測完刮刀高度後,開始設定刮刀行程)
CAUTION：Auto height sensor in
JOG ACTIVE…
SQUEEGEE STROKE
Press EXIT to quit.
Leveling front blade.
Leveling rear blade.
