Vacuum Tooling for HS-50 Retrofit Instructions / User Manual 9 Maintenance Edition 12/00 48 0 DLQWHQDQFH Resources required: – vacu um cleane r , – clean , lint-free cloth Vacuum plate (top plate of the tool): Clean/i …
Retrofit Instructions / User Manual Vacuum Tooling for HS-50
Edition 12/00 8 Spare Parts
47
6SDUH 3D UWV
1 Solenoid valve, Art. No. 00309936-01
1 Silencer, Art. No. 00047900-01
1 Venturi nozzle, Art. No. 00333438-01
Suction cups (in-house spare part, Motorola)
NOTE:
The procedure to be followed when exchanging these spare parts is not described here because
these jobs must be performed only by appropriately qualified personnel.
If such are not available, please contact Siemens SMD Service.
Vacuum Tooling for HS-50 Retrofit Instructions / User Manual
9 Maintenance Edition 12/00
48
0DLQWHQDQFH
Resources required:
– vacuum cleaner,
– clean, lint-free cloth
Vacuum plate (top plate of the tool): Clean/inspect contact surface and suction cups (suc-
tion openings) 9
:
Visually inspect the contact surface prior to starting the placement process.
:
Vacuum off the contact surface and the suction cups/suction openings (as also routine during
maintenance of the component tables).
If necessary, wipe off the surface afterwards with a clean, lint-free cloth.
Checking the silencer
:
Check the silencer for fouling at relatively long periods of time. If necessary, exchange the si-
lencer.
Suction cups
:
Exchange the suction cups of the tool when they become worn.
Retrofit Instructions / User Manual Vacuum Tooling for HS-50
Edition 12/00 10 Circuit Diagrams for Electrical System
49
&LUFXLW'LDJUDPVIRU(OHFWULFDO6\VWHP
