INFINITY +,*+7+ 528*+387&2 19(<2502' 8/( 0(&+$ 1,&$/'( 7$,/ Chapter Issue 1 May 03 Technical Reference Manual 15.13 the stencil . The clamps are adj usted in height for dif ferent thicknesse …
INFINITY
+,*+7+528*+387&219(<2502'8/(
0(&+$1,&$/'(7$,/
15.12 Technical Reference Manual Chapter Issue 1 May 03
close to the board edge.
The adjustable snugger plate, rear rail guide and fixed snugger plates are
interchangeable with similar units to facilitate differences in board thickness.
This system caters for 0.8mm, 1.0mm and 1.6mm board thickness.
To clamp the board in position for the printing process, the board is gripped
between the fixed and adjustable snugger plates by action of the pneumatically
operated piston. Pneumatic operation utilizes the existing board clamp circuit,
(via a 24V switched solenoid 16SOL10 from the machine controller).
On completion of the print stroke the pneumatic solenoid is de-activated allow-
ing the actuator pistons (sprung loaded), to retract the adjustable snugger plate
away from the board.
Figure 15-9 Board Snugger Clamping Arrangement
Foil-less Clamps This option is used on thin boards which are populated with components too
close to the edge of the board for traditional board clamps. The board is
secured during the print stroke by the use of vacuum. The clamps are
perpendicular to the board maintaining a good gasket between the board and
Board
Adjustable Snugger Plate
Fixed Snugger Plate
Plan View of Print Station Rail (Showing Board Clamped)
Side View of Print Station Rail (Showing Board Clamping Action)
Pneumatic Piston Extended
Board
Moving Rail
Movement of Adjustable
Snugger Plate
Movement
of Board
Rear Rail Guide
(Cutaway View)
Adjustable Snugger Plate Board Gripped by
Snugger Clamp
INFINITY
+,*+7+528*+387&219(<2502'8/(
0(&+$1,&$/'(7$,/
Chapter Issue 1 May 03 Technical Reference Manual 15.13
the stencil. The clamps are adjusted in height for different thicknesses of board
by two grub screws.
Figure 15-10 Foil-less Clamps
Adjustment Grub Screw
Rail
Foil-less ClampBoard
Vacuum Box
INFINITY
+,*+7+528*+387&219(<2502'8/(
'5,9(6$1'6(16256
15.14 Technical Reference Manual Chapter Issue 1 May 03
DRIVES AND SENSORS
Sensors
Motors
Name Type Inputs Functional Description
Rail Lifted Left Through Beam Opto NextMove
Dig IN 3
Detects premature lifting of rail
Rail Lifted Right Through Beam Opto NextMove
Dig IN 4
Detects premature lifting of rail
Rail Home Through Beam Opto Stepper
Multiplexer
MUX2
Provides home position of moving rail thus
providing accurate board width settings
Board at Left Background Suppressed NextMove
Dig IN 16
Detects left side incoming/outgoing board
dependent upon machine pass through configuration
Board at Right Background Suppressed NextMove
Dig IN 17
Detects right side incoming/outgoing board
dependent upon machine pass through configuration
Left Auxiliary Rail Diffuse Opto M27PLC01-I/P1 Detects left side incoming/outgoing board
dependent upon machine pass through configuration
Right Auxiliary Rail Diffuse Opto M27PLC02-I/P1 Detects right side incoming/outgoing board
dependent upon machine pass through configuration
Name Type Functional Description
Moving Rail Drive Stepper Motor Moves the rear moving rail of the print station
conveyor in the Y direction
Front
Print Area Conveyor
Board Transport Belt Drive
DC Moving Coil Motor Turns the front transport belt, of the print station conveyor in the
clockwise or anti clockwise direction (dependent upon upline/
downline feed direction)
Rear
Print Area Conveyor
Board Transport Belt Drive
DC Moving Coil Motor Turns the rear transport belt, of the print station conveyor in the
clockwise or anti clockwise direction (dependent upon upline/
downline feed direction)
Front Left
Auxiliary Conveyor
Board Transport Belt Drive
DC Moving Coil Motor Turns the front transport belt, of the left auxiliary conveyor in the
clockwise or anti clockwise direction (dependent upon upline/
downline feed direction)
Rear Left
Auxiliary Conveyor
Board Transport Belt Drive
DC Moving Coil Motor Turns the rear transport belt, of the left auxiliary conveyor in the
clockwise or anti clockwise direction (dependent upon upline/
downline feed direction)
Front Right
Auxiliary Conveyor
Board Transport Belt Drive
DC Moving Coil Motor Turns the front transport belt, of the right auxiliary conveyor in the
clockwise or anti clockwise direction (dependent upon upline/
downline feed direction)
Rear Right
Auxiliary Conveyor
Board Transport Belt Drive
DC Moving Coil Motor Turns the rear transport belt, of the right auxiliary conveyor in the
clockwise or anti clockwise direction (dependent upon upline/
downline feed direction)
