WES7 / Win10 - Installation Manual 11/2018 Edition
10
Name SIMATIC BoxPC 627D/827D
CPU / clock frequency Intel® Core(TM) i3 / 2,40 GHz
Exchange PC for 60x:
Intel® Celeron® G1820TE / 2,20 GHz
RAM 4 GB
Harddisk SSD
Serial interfaces 1
USB interfaces Yes
Network 2x 1000 MBit
Table 3-7: SIMATIC BoxPC 627D/827D
Name SIMATIC MicroBox 427D
CPU / clock frequency Intel® Core
(TM)
/ 1,6 GHz
RAM 4 GB
Harddisk SSD
Serielle Schnittstellen 1
USB interfaces Yes
Network 2x 1000 MBit
Table 3-8: SIMATIC MicroBox 427D
Name iBASE ABP 102-A
CPU / clock frequency Celeron® Dual Core T3100 / 1.9 GHz
RAM 2 GB
Harddisk HDD
Serial interfaces 1
USB interfaces Yes
Network 2x 1000 MBit
Table 3-9: iBASE ABP 102-A
Name iBASE ABP 402-A
CPU / clock frequency Intel® Celeron® CPU 1020E/ 2.2 GHz
RAM 4 GB
Harddisk SSD (SX), HDD (E by SIPLACE)
Serial interfaces 2
USB interfaces Yes
Network 2x 1000 MBit
Table 3-10: iBASE ABP 402-A
WES7 / Win10 - Installation Manual 11/2018 Edition
11
4 Installation
4.1 Overview
Choose computer configuration
SIPLACE WES7
Configurator
SIPLACE Win
10 Configurator
Install and calibrate Touchscreen
BIOS settings on the
Station
/
Coplan
/
BulkFeeder X computer
Perform BIOS settings
Back up the machine data
BIOS update
on the
Station /
Coplan
/
BulkFeeder X computer
Perform
BIOS
update
Install WES
7/
Win
10
(
DVD or USB stick
suitable for the
computer)
Restore the initial configuration
See section 4.2.
See section 4.2.
Installing the operating system, see section 4.3.
See section 4.3.3.
See chapter 5.
Figure 4-1: Installation
WES7 / Win10 - Installation Manual 11/2018 Edition
12
4.2 BIOS Update/Settings
A BIOS update shall only be performed if requested. No BIOS updates have to be performed on
the current computers at present.
► Perform the BIOS settings as follows.
The following steps have to be performed before installing Windows Embedded Standard 7:
► Press the F2 key to access BIOS after the computer has started.
► Press the F9 key (Setup Default) to set the default settings.
► Change the BIOS settings as described in the following section.
4.2.1 BIOS Settings for SIMATIC BoxPCs 627B / 827B
► Set the following values in BIOS:
Under Main / Hardware Options:
PCI-MPI/DP [ Disabled ]
Safecard Functions [ Disabled ]
Fan Control [ Enabled ]
Under Advanced / SATA/PATA Configuration:
SATA Controller Mode [ Compatible ]
Under Advanced:
Core Multi-processing [ Enabled ]
Under Boot the following boot priority sequence:
1: USB CDROM: 2: SATA0: xxxxxxxxxx 3: ......
Under Exit / Profile:
Profile: [User]
► Exit BIOS with Exit / Exit saving changes / Yes.
