WES7 / Win10 - Installation Manual 11/2018 Edition 8 3 Prerequisit es for Installation In Windows, t he station co mputer must be equipped wit h at least 2 GB memory with WES7, 32 - bit and 4 GB memory with W ES7 / Win10…
WES7 / Win10 - Installation Manual 11/2018 Edition
7
For station software version 7xx:
Operating system USB package Win10(7xx) V1.0, item no. [00117132-xx]
The bootable USB stick contains:
– SIPLACE WinPE for Win10-Restore V2018-1 (to start up the computer)
– SIPLACE Win10 Configurator V1.0.0 (current version for the computer configuration)
– Installation Manual "Operating Systems Windows Embedded Standard 7 / Windows 10 IoT",
item no. [00198622-xx]
– The following image file:
– SIPLACE_Win10x64_SIMATICMicroBox427D_V1.wim
– SIPLACE _Win10x64_iBaseABP402A_V1.wim
The individual packages are also available at the ASM Software Download Center.
WES7 / Win10 - Installation Manual 11/2018 Edition
8
3 Prerequisites for Installation
In Windows, the station computer must be equipped with at least 2 GB memory with WES7, 32-bit
and 4 GB memory with WES7 / Win10, 64-bit respectively. If necessary, station computers in the
field have to be exchanged or upgraded with a memory extension. Please refer to the Technical
Information TI2014-09E04.
3.1 Hardware Components of the Computer System for the
Station / Coplan / BulkFeeder X Computer
Overview Station computer types
X-series X-series
S
SX-
series
DX-
series
D-series TX-
series
CA4 CA4 V2 E by
SIPLACE
SIMATIC
BoxPC
627B/827B
WES7
32 bit
WES7
32 bit
WES7
32 bit
WES7
32 bit
SIMATIC
BoxPC
627C/827C
WES7
32 bit
WES7
32 bit
WES7
32 bit
WES7
32 bit
WES7
32 bit
WES7
32 bit
SIMATIC
BoxPC
627D/827D
WES7
32 bit
WES7
32 bit
WES7
64 bit
SIMATIC
MicroBox
427D
WES7
64 bit
WES7
64 bit
WES7
64 bit
iBASE ABP
102-A
WES7
32 bit
iBASE ABP
402-A
WES7
Win10
64 bit
WES7
32 bit
WES7
64 bit
Table 3-1: Overview Station computer types
Overview Coplan / BulkFeeder X computer types
Coplan BulkFeeder X
SIMATIC
BoxPC 627B
WES7
32 bit
SIMATIC
BoxPC 627C
WES7
32 bit
SIMATIC
BoxPC 627D
WES7
32-Bit
SIMATIC
MicroBox 427D
WES7
64 bit
Table 3-2: Overview Coplan / BulkFeeder X computer types
WES7 / Win10 - Installation Manual 11/2018 Edition
9
Name SIMATIC BoxPC 627B
CPU / clock frequency Core 2 Duo T7400 / 2.16 GHz
RAM 2 GB
Harddisk HDD
Serial interfaces 1
USB interfaces Yes
Network 2x 100 MBit
Table 3-3: SIMATIC BoxPC 627B
Name SIMATIC BoxPC 827B
CPU / clock frequency Core 2 Duo T7400 / 2.16 GHz
RAM 2 GB
Harddisk HDD
Internal DVD drive Yes
Serial interfaces 1
USB interfaces Yes
Network 2x 100 MBit
Table 3-4: SIMATIC BoxPC 827B
Name SIMATIC BoxPC 627C
CPU / clock frequency Intel® Celeron® P4505 / 1,87 GHz
RAM 2 GB
Harddisk HDD
Serial interfaces 1
USB interfaces Yes
Network 2x 100 MBit
Table 3-5: SIMATIC BoxPC 627C
Name SIMATIC BoxPC 827C
CPU / clock frequency Intel® Core(
TM
) i3 / 2.13 GHz
RAM 2 GB
Harddisk HDD
Serial interfaces 1
USB interfaces Yes
Network 2x 100 MBit
Table 3-6: SIMATIC BoxPC 827C
