3 Mechanical Section 3-1 3 Mechanical Section
2 Periodical Checks
2-6
Teach Camera
Clean lens.
)
”Camera” in 3 Mechanical Section.
Scan Camera
Clean lens.
Clean mirror in front of camera.
)
”Camera” in 3 Mechanical Section.
Camera Illumination
Check movement and brightness.
Operation Switches
Check if all actuators work properly in the Signal I/O screen.
Check emergency stop switch.
Alarm Beacon
Check if all lamps light.
Make sure it is fixed securely.
Hazard Alarm
(continuous high-pitched
tone)
Check if alarm sounds.
Warning Alarm
(intermittent high-pitched
tone)
Check if alarm sounds.
Cameras
Execute “VISION TEST” and check result.
Pickup Coordinates
Check feeder banks.
Electrodes on Feeder Bank
Make sure there is no dirt and flaws on electrodes.
)
”Electrodes on Feeder / Feeder Bank” in 4 Electrical Section.
Placement
Make sure components are placed on specified places.
3 Mechanical Section
3-1
3
Mechanical Section
3 Mechanical Section
3-2
■ Vacuum Generator
ACTION: Breakdown Visually check the silencer element, and if it is excessively dirty, replace it with a new one.
Also measure the maximum air pressure to inspect whether the vacuum generator can generate vacuum
properly.) Inspection for Head/Nozzle Clogging and Solenoid Valve
● Inspection interval
Once a week
Part Name
Part No. Remark
SILENCER ELEMENT LG0-M71A8-00X Silencer element
GENERATOR,VACUUM LG0-M71A3-00X Vacuum generator
