4 Electrical Section
4-11
Address Bit No. Signal Name Address Bit No. Signal Name
000Eh 0 DLC LIGHT-ON A 0012h 0 Main Light for Scan Camera: Calibration Bit0
1 Beam Sensor Power On 1 Main Light for Scan Camera: Calibration Bit1
2 Light Select 2 Main Light for Scan Camera: Calibration Bit2
3 3 Main Light for Scan Camera: Calibration Bit3
4 4 Main Light for Scan Camera: Calibration Bit4
5 5 Main Light for Scan Camera: Calibration Bit5
6 6 Main Light for Scan Camera: Calibration Bit6
7 7 Main Light for Scan Camera: Calibration Bit7
000Fh 0 Light Adjustment Frequency A Bit0 0014h 0 Side Light for Scan Camera: Calibration Bit0
1 Light Adjustment Frequency A Bit1 1 Side Light for Scan Camera: Calibration Bit1
2 Light Adjustment Frequency A Bit2 2 Side Light for Scan Camera: Calibration Bit2
3 3 Side Light for Scan Camera: Calibration Bit3
4 4 Side Light for Scan Camera: Calibration Bit4
5 5 Side Light for Scan Camera: Calibration Bit5
6 6 Side Light for Scan Camera: Calibration Bit6
7 7 Side Light for Scan Camera: Calibration Bit7
0010h 0 Main Light for Scan Camera: Adjustment Bit0 0016h 0 Extra Light for Scan Camera: Calibration Bit0
1 Main Light for Scan Camera: Adjustment Bit1 1 Extra Light for Scan Camera: Calibration Bit1
2 Main Light for Scan Camera: Adjustment Bit2 2 Extra Light for Scan Camera: Calibration Bit2
3 Main Light for Scan Camera: Adjustment Bit3 3 Extra Light for Scan Camera: Calibration Bit3
4 Side Light for Scan Camera: Adjustment Bit0 4 Extra Light for Scan Camera: Calibration Bit4
5 Side Light for Scan Camera: Adjustment Bit1 5 Extra Light for Scan Camera: Calibration Bit5
6 Side Light for Scan Camera: Adjustment Bit2 6 Extra Light for Scan Camera: Calibration Bit6
7 Side Light for Scan Camera: Adjustment Bit3 7 Extra Light for Scan Camera: Calibration Bit7
0011h 0 Extra Light for Scan Camera: Adjustment Bit0
1 Extra Light for Scan Camera: Adjustment Bit1
2 Extra Light for Scan Camera: Adjustment Bit2
3 Extra Light for Scan Camera: Adjustment Bit3
4
5
6
7
■ Device 5
Address Bit No. Signal Name Address Bit No. Signal Name
0000h 0 Switch Lamp State Bit0 0002h 0 Front Cover Lock
1 Switch Lamp State Bit1 1 Enable Front-side Operation
2 Switch Lamp Address Bit0 2
3 Switch Lamp Address Bit1 3
4 Switch Lamp Address Bit2 4
5 Switch Lamp Address Bit3 5
6 6
7 7
■ Device 7
Address Bit No. Signal Name Address Bit No. Signal Name
0000h 0 Switch Lamp State Bit0 0002h 0 Rear Cover Lock
1 Switch Lamp State Bit1 1 Enable Rear-side Operation
2 Switch Lamp Address Bit0 2
3 Switch Lamp Address Bit1 3
4 Switch Lamp Address Bit2 4
5 Switch Lamp Address Bit3 5
6 6
7 7
4 Electrical Section
4-12
■ Device 9
Address Bit No. Signal Name Address Bit No. Signal Name
0000h 0 Board Stopper Up A 0005h 0
1 Main Clamp Up A 1
2 Buffer Stopper Up 2 Conveyor1 Rotation
3 Conveyor1 Sensor POWER 3 Conveyor2 Rotation
4 ANC A Open 4 Conveyor3 Rotation
5 ANC B Open 5
6 CFB(F) Lock 6
7 CFB(F) Unlock 7
0001h 0 CFB(R) Lock 0006h 0 Conveyor1 Speed Data Bit0
1 CFB(R) Unlock 1 Conveyor1 Speed Data Bit1
2
Feeder Bank Power Supply(F60) ON / Feeder Bank
Power Supply(F22) ON
2 Conveyor1 Speed Data Bit2
3
Feeder Bank Power Supply(R60) ON / Feeder Bank
Power Supply(R22) ON
3 Conveyor1 Speed Data Bit3
4 BOARD AVAILABLE Output 4 Conveyor1 Speed Data Bit4
5 READY Output 5 Conveyor1 Speed Data Bit5
6 Side Clamp ON 6 Conveyor1 Speed Data Bit6
7 Rear Clamp ON 7 Conveyor1 Speed Data Bit7
0002h 0 Main Clamp Down 0008h 0 Conveyor2 Speed Data Bit0
1 Entrance Shutter Close 1 Conveyor2 Speed Data Bit1
2 2 Conveyor2 Speed Data Bit2
3 3 Conveyor2 Speed Data Bit3
4 4 Conveyor2 Speed Data Bit4
5 MX-ST2 Clamp ON 5 Conveyor2 Speed Data Bit5
6 6 Conveyor2 Speed Data Bit6
7 7 Conveyor2 Speed Data Bit7
0004h 0 Conveyor1 Rotation Direction 000Ah 0 Conveyor3 Speed Data Bit0
1 Conveyor2 Rotation Direction 1 Conveyor3 Speed Data Bit1
2 Conveyor3 Rotation Direction 2 Conveyor3 Speed Data Bit2
3 3 Conveyor3 Speed Data Bit3
4 4 Conveyor3 Speed Data Bit4
5 Conveyor1 Alarm Reset 5 Conveyor3 Speed Data Bit5
6 Conveyor2 Alarm Reset 6 Conveyor3 Speed Data Bit6
7 Conveyor3 Alarm Reset 7 Conveyor3 Speed Data Bit7
■ Device 11
Address Bit No. Signal Name Address Bit No. Signal Name
0000h 0 MXR Hook Lock / MX-20 Relay Hook UP 0001h 0 LED State Bit0
1
MXR Pallet Bar Open / MX-20 Pallet Stopper Off in
Stocker
1 LED State Bit1
2 MX-20 Pallet Clamp Off on Shuttle 2 AUX OUT3
3 MXR Cover Lock / MX-20 Cover Lock 3 LED Control Address0
4 W-MXR SERVO Illumi. 4 LED Control Address1
5 W-MXR SETUP Illumi. 5 LED Control Address2
6 AUX OUT1 6 LED Control Address3
7 AUX OUT2 7 LED Control Address4
4 Electrical Section
4-13
Signal Input Map
■ DI Monitor
Address Bit No. Signal Name Address Bit No. Signal Name
4103h 0
4105h 0
UPS Under Backup
1
1
UPS Battery Low
2
2
Front Bank Cable Connection
3
3
Rear Bank Cable Connection
4
4
5
5
6
6
7
SERVO ON State
7
4104h 0
24V Voltage monitoring
4106h 0
Reserve DI
1
12V Voltage monitoring
1
Reserve DI
2
5V Voltage monitoring
2
Reserve DI
3
3
Reserve DI
4
4
Reserve DI
5
5
Reserve DI
6
6
Reserve DI
7
7
Reserve DI
